A slow thread is not a thread cut at low speed for its own sake. It is a thread where the material removal per pass stays small enough that the tool, the wire, or the tap keeps its geometry. In wire EDM, that means more passes at lower energy. In thread whirling, it means more passes at lower feed per revolution. In hand tapping, it means more turns with less downforce.

The reason is heat and chip evacuation. When you push a single roughing pass to the limit, the eroded debris cannot leave the kerf fast enough. The wire drags, the discharge gap closes, and you get a short circuit or a break. Small bites keep the gap open and let the dielectric carry particles away.

The trade is time. A slow thread on a deep M6 hole in 17-4PH stainless may take three times the cycle of a single aggressive pass. That is acceptable when the alternative is a scrapped part or a broken tap in a finished housing. It is not acceptable on a high-volume bracket where a standard rolled thread would pass inspection.

So the first decision is not which parameters to use. It is whether the thread needs the slow route at all. Depth-to-diameter ratio above 2.5, material harder than 35 HRC, or a thread that must seal against gas usually says yes. A through thread in 6061 aluminium at 1.5 × D usually says no.

• 1
  Deep holesDepth above 2.5 × D is where chip packing starts.
• 2
  Hard or gummy stockOver 35 HRC, or 316L and titanium that work-hardens.
• 3
  Sealing threadsGas or hydraulic threads tolerate no torn crest.
• 4
  Thin wallsUnder 1 mm wall, radial force must stay low.

Wire choice comes first. For a thread under M4 or a slot narrower than 1 mm, use 0.20 to 0.25 mm brass wire. Above that, 0.30 mm is more stable and cheaper per part. Coated wire helps in tungsten carbide and Inconel, but it costs more and you should only switch when plain brass breaks twice in a row.

Set the upper flush nozzle 0.1 to 0.2 mm off the workpiece. Too far and the jet loses coherence; too close and the nozzle rubs and wears. Flush pressure between 10 and 14 bar at the upper head is a good starting band for 0.25 mm wire. If the machine alarms on poor flush during the rough pass, raise pressure by 1 bar before you touch the feed.

Wire tension is the parameter most people set once and forget. On a 0.25 mm wire, 8 to 12 N is typical. The value drifts as the wire heats and the spool pays out. Recheck it after the first 20 minutes of cutting. A tension drop of 1 N is enough to shift the kerf and leave taper on the thread flank.

For the rough pass, keep the discharge gap stable rather than chasing speed. A cut that finishes 0.03 to 0.05 mm under size leaves room for two skims. If the rough pass comes in at final size, the skims have nothing to remove and the surface stays rough.

• 1
  Nozzle standoff0.1 to 0.2 mm, checked with a shim.
• 2
  Rough offsetLeave 0.03 to 0.05 mm for skims.
• 3
  Tension checkRe-measure at 20 minutes, not per shift.

Thread whirling cuts a thread with a rotating ring of inserts while the bar turns slowly. It suits bone screws, spinal rods, and long small-diameter threads where a single-point tool would deflect. The slow part is the bar rotation. Keep it between 20 and 60 rpm for titanium and 60 to 120 rpm for stainless. Faster than that and the insert load spikes.

Feed per revolution of the workpiece controls chip thickness. For Ti-6Al-4V, start at 0.25 to 0.35 mm per revolution of the whirling ring. Too low and the insert rubs instead of cutting, which work-hardens the flank. Too high and you get chatter marks that look like a torn thread.

Coolant must reach the cutting zone under pressure, not flood it from above. Aim the nozzle at the insert exit side so chips leave the groove. On a 3 mm diameter thread, 40 to 70 bar through-tool or high-pressure coolant keeps the insert alive. Low-pressure flood coolant is the most common cause of insert chipping on these jobs.

Check the first part with a thread gauge and a profile projector before you run the rest. Whirling inserts wear on the flank, so the pitch diameter creeps. Measure every 50 parts on a long run and change the insert when the gauge starts to drag.

• 1
  Bar speed20 to 60 rpm in titanium, 60 to 120 rpm in stainless.
• 2
  Feed per rev0.25 to 0.35 mm, adjusted by chip form.
• 3
  Coolant40 to 70 bar aimed at the insert exit.

Wire breaks in the same spot every time usually mean flush, not feed. Check the upper nozzle for wear and confirm the standoff. If the break happens at a corner, the machine is accelerating faster than the gap can recover. Reduce the feed override at corners by 20 to 30 percent and keep the flush steady.

A thread that gauges tight at the start and loose at the bottom points to taper from lost tension. Re-measure tension mid-cut. On a worn wire guide, the wire sits off center and the kerf leans. Replace guides on the schedule the machine maker gives, not when the part fails.

Torn crests in whirling come from feed that is too low or coolant that never reaches the insert. Raise feed per revolution in small steps and move the nozzle. If the insert still rubs, the grade is wrong for the material and you should switch rather than keep tuning.

Broken taps in a blind hole are the classic slow-thread failure. Use a spiral-flute tap for blind holes, peck every 0.5 × D, and blow chips out with air between pecks. If the tap squeaks, stop. Squeak means it is rubbing, and the next turn usually snaps it.

• 1
  Repeat break at one spotCheck nozzle wear and corner feed override.
• 2
  Tight top, loose bottomLost wire tension or a worn guide.
• 3
  Torn crest in whirlingFeed too low or coolant missing the insert.

Skip the slow route when the thread is short. A through thread at 1.5 × D in 6061 or 1045 steel does not need multiple skims. A standard cycle holds Class 6H without the extra passes, and the time saved pays for the inspection you still need.

Skip it on high-volume parts where the tolerance is loose. If the print calls out a general-purpose thread and the part is a bracket, chasing a perfect flank costs cycle time for no functional gain. Save the slow cycle for sealing threads, fatigue-loaded threads, and anything under M4.

Skip it when the machine cannot hold the flush pressure the method needs. Below 8 bar at the upper head, a 0.25 mm wire in a deep hole is a break waiting to happen. Move the job to a machine with the right pump or change the method.
