The shortcut says the minor diameter of an internal thread equals the nominal diameter minus half the pitch. Put M6 × 1.0 into it and you get 5.5 mm. Put M10 × 1.5 in and you get 9.25 mm. Both numbers sit close enough to the tap drill chart that nobody questions the method. That is the trap. The formula is a curve fit, not a derivation.

The real geometry is a 60° V with a flat or rounded crest. For an internal thread the flat is P/8 at the major diameter and P/4 at the minor diameter. Once you account for the truncation, the minor diameter becomes D minus roughly 1.08P, not D minus 0.5P. The two answers only converge when the pitch is coarse relative to the diameter.

Take M3 × 0.5. The shortcut gives 2.75 mm. The geometric value lands near 2.46 mm. That 0.29 mm gap is larger than the whole tolerance band of a class 6H nut. A tap drill chosen from the shortcut will cut a thread that gauges loose or strips under load.

So the rule is not wrong because someone made an arithmetic error. It is wrong because it deletes the crest truncation and the pitch diameter from the model. Those two features carry the fit.

• 1
  ShortcutMinor diameter = D – 0.5P. Fits coarse pitches only.
• 2
  GeometryMinor diameter = D – 1.08P after truncation.

A thread is not located by its outside diameter. It is located by the pitch diameter, the imaginary cylinder where thread thickness equals groove width. Two parts can both measure 5.98 mm across the crests and still not assemble, because their pitch diameters differ by 0.05 mm.

That is why the gauging system uses GO and NO-GO ring or plug gauges. The GO gauge checks the maximum material pitch diameter, the NO-GO checks the minimum. The major diameter is inspected separately with a plain gauge, and it only has to clear the crest.

When a thread feels tight, the first instinct is to turn the OD down. That removes the crest, weakens the flank contact and moves nothing on the pitch diameter. The thread still will not gauge. We see this most often on 304 stainless and on titanium, where the material springs back after the pass.

Measure pitch diameter with the three-wire method on the shop floor, or with a thread micrometer when the size allows. Wires of the correct best size give a direct reading. On a 0.5 mm pitch the difference between a good and a bad thread is often under 0.03 mm.

• 1
  GO gaugeChecks maximum material pitch diameter.
• 2
  NO-GO gaugeChecks minimum material pitch diameter.

Rule three is the claim that thread depth equals 0.65 times the pitch. It is a flank-height figure, not a radial depth, and it ignores the root radius that a full-form insert leaves. On a 0.8 mm pitch the error is small. On a 3.0 mm pitch it changes the programmed depth by more than 0.1 mm, which is enough to break a small tap.

Rule four says the tap drill equals the nominal diameter minus the pitch. That is the same curve fit wearing a different hat. It works on M8 × 1.25 and fails on fine pitches, where the correct drill is closer to D minus 1.08P. Use the chart in the standard, or calculate from the minor diameter limit.

Rule five is the idea that thread height and thread engagement are interchangeable terms. They are not. Height is a geometry number. Engagement is how much axial length of full thread you actually have. A 6 mm deep hole with a bottoming tap may give only 3 mm of usable full thread.

Each of these rules survives because it is easy to remember. None of them survives a gauge. Replace them with the pitch diameter limits from ISO 965 and the drill sizes that follow from those limits.

• 1
  DepthFlank height is not radial depth.
• 2
  DrillD – P is a fit, not a geometry result.
• 3
  EngagementCount usable full thread, not hole depth.

On a lathe the thread is cut by a tool that follows a helix. The formula gives the depth, but the machine has to reach it without chatter. Depth of cut per pass, infeed angle and spindle speed decide whether the flank comes out clean. A perfect formula with a bad infeed schedule still produces a torn thread.

For a 60° thread we use a compound infeed around 29° to 30°, so the leading edge does most of the cutting and the trailing edge shaves the flank. Radial infeed is faster and works on short, rigid parts. On thin-wall tube, radial infeed pushes the wall outward and the pitch diameter drifts.

Pass count matters more than most people expect. For a 1.5 mm pitch in 4140 we typically spread the cut over six to eight passes, with the last two at a few hundredths of a millimeter. The finishing pass removes the material the roughing pass left and sets the surface.

Spring passes are not optional on stainless. Take one pass at the final depth with no additional infeed. It costs a few seconds and it removes the elastic recovery that makes a thread gauge tight.

• 1
  Compound infeedAbout 29° to 30° for a 60° thread.
• 2
  Spring passOne pass at final depth, no infeed.

The seventh rule is not a formula at all. It is the habit of reading a tap drill chart as a single number instead of a window. Every thread class has a minor diameter range, and any drill inside that range produces an acceptable thread. Outside it, no amount of skill saves the part.

ISO 965 defines those limits for classes 6H and 6g, the two default fits. A 6H internal thread is the normal choice for a nut. A 6g external thread gives a small clearance so plating or coating does not seize the assembly. If you anodize a thread, the coating adds roughly half its thickness per flank and the fit closes.

That is the engineering meaning of the whole exercise. A thread formula algorithm is a starting point for the CAM program, not a substitute for the drawing tolerance. The drawing, the standard and the gauge decide whether the part is good.
