CNC VMC Manufacturer Guide: 5 Checks Before You Quote

• 1
  Key takeaways
• 2
  VMC class by part size and geometry
• 3
  What to compare across three quotes
• 4
  What a CNC VMC manufacturer guide should tell you about machine travel
• 5
  Axis count and setup count for your part geometry
• 6
  Tolerance, surface finish and what the quote actually covers
• 7
  Lead time, MOQ and how to read a schedule
• 8
  Certifications, materials and finishing under one roof
• 9
  Five traps that cost engineers weeks
• 10
  Step by step: qualifying a CNC VMC manufacturer

Travel is the first number to compare because it is the one you cannot work around. If a shop's largest machine is 600 × 600 × 600 mm, a 900 mm rail will be split into two parts or sent elsewhere. Ask for the travel envelope of the specific machine that will run your job, not the largest machine on the floor.

Spindle reach matters as much as the X and Y numbers. A deep pocket in a 200 mm tall block can sit inside the travel envelope and still be unreachable with a short tool holder. Give the shop a section view with the deepest pocket dimension called out, and ask which holder they plan to use.

Rotary tables change the picture. A four-axis VMC with a Ø400 mm table loses usable Z height when the part is chucked vertically. That is fine for a shaft and wrong for a tall housing. Send the part orientation you expect, then let the shop confirm clearance.

One practical test: send the 3D model and a marked-up drawing with the critical features highlighted. A shop that comes back with a fixturing idea and a tool list is reading your part. A shop that only returns a price per piece is guessing.

Every extra setup adds re-fixturing error and queue time. A part with features on five faces means five setups on a three-axis machine, or one setup on a simultaneous five-axis center. That difference shows up in both unit price and positional tolerance between faces.

Five-axis is not automatically better. For a flat plate with holes on one face, a three-axis machine with a good vise holds ±0.005 mm all day at a lower hourly rate. Save the five-axis capacity for contoured surfaces, undercut features, and parts where datum transfer is the real risk.

Four-axis sits in the middle. Cross-drilled shafts, cam profiles and slotted cylinders are natural four-axis work because the part indexes rather than the tool tilting. The rotary table also gives you a repeatable angular datum, which a manual vise cannot.

Ask how the shop proves the rotary axes. A five-axis center that has never been ballbar-tested or probed on the table is a source of scrap on the first article. Request the alignment record before you release a tight-tolerance job.

• 1
  One face of featuresThree-axis with hard jaws is usually the cheapest route.
• 2
  Features on three or four facesFour-axis with a tombstone or indexer cuts setups.
• 3
  Contoured or undercut surfacesSimultaneous five-axis avoids hand blending.

A tolerance number without a size and a method is decoration. ±0.005 mm on a 20 mm bore measured with a bore gauge is one thing; the same figure across a 500 mm plate with a CMM is another. Ask for the tolerance per feature type and the gauge that will confirm it.

Surface finish follows the same logic. Ra 1.6–3.2 μm is normal as-machined aluminum. Ra 0.8–1.6 μm usually needs a finishing pass and a sharp tool. Ra 0.2–0.8 μm often means grinding or lapping after milling. If the callout is on a sealing face, say so, and the shop can plan the sequence.

Watch for a quote that lists a machining price with no inspection line. 100% inspection before shipment, with raw material checks, in-process monitoring and a final report, is what keeps a ±0.005 mm promise honest. Reports should be available on request, not treated as an extra project.

Material grade is the third hidden variable. 6061-T6 and 7075 machine differently, and 17-4PH in the H900 condition will fight a light finishing pass. Name the temper and the condition on the drawing so the cutting data is right the first time.

Lead time has three separate clocks: quote, production start, and shipping. A shop can be fast on one and slow on another. Ask for all three in writing. GreatLight quotes with a free DFM analysis within 12 hours, can start production within 24 hours of a frozen drawing, and ships parts in 3–5 days.

A low MOQ is a signal about how the shop is organized. No minimum order quantity, from one prototype to 10,000+ part runs, means the shop runs a prototype cell next to production machines. That matters when you need a revision before committing to a full run.

Do not confuse a fast first article with a stable process. The first part off a five-axis center is the easy one. Ask what happens on part 500: same fixture, same tool life policy, same inspection frequency? The answers tell you whether the schedule holds in month three.

Treat any schedule as conditional on drawing freeze. If your model changes after the first article, the production clock resets. Send a revision letter with every change so the shop can re-quote the affected operations only.

Certifications are a filter, not a score. ISO 9001:2015 covers basic quality management. IATF 16949:2016 is what automotive and EV programs ask for. ISO 13485:2016 matters for medical devices. ISO 27001:2022 covers information security, which is relevant when your CAD files leave your network.

Material range tells you how many phone calls you will make. A shop that machines 6061, 7075, 304, 316L, 17-4PH, Ti-6Al-4V, Inconel, PEEK and Delrin in-house can keep one process owner for the whole part. A shop that outsources titanium usually outsources the tolerance too.

Finishing is where schedules quietly slip. Anodizing, electroless nickel, zinc plating, powder coating, black oxide, bead blasting and laser marking are common hand-offs. Keeping them in the same quality system means one inspection record, one shipment, and no argument about who scratched the part.

Laser marking has a floor: minimum character height 1.5 mm. If your serial number or UDI is smaller than that, plan for a different marking method before you approve the drawing.

The first trap is quoting a part that is not manufacturable as drawn. A 0.5 mm internal corner on a 40 mm deep pocket needs a small tool with a long reach, and that tool will chatter. A DFM note during quoting catches this before you cut metal.

The second trap is a single global tolerance. If the title block says ±0.05 mm and one bore needs ±0.005 mm, that bore must be called out separately with its own datum. Otherwise the shop prices the whole part to the loose number and you get a surprise at first article.

The third trap is ignoring datum strategy. Five-axis work lives or dies on datum selection. If the drawing datums do not match how the part sits in the fixture, the shop will pick its own and the inspection report will not agree with your drawing.

The fourth trap is thin walls. A 1.5 mm wall on a 300 mm aluminum housing will move under clamp force and again when the material is relieved. Plan a roughing pass, a stress-relief pause if needed, and a light finishing pass.

The fifth trap is treating finishing as an afterthought. Anodizing adds a few micrometres and can shift a press fit. Call out masking, thread protection and the finish thickness range on the drawing.
