  Which function controls which part feature

Interpolation is the function that decides how the axes move between two programmed points. Ask for a straight line and the control coordinates the axes so the cutter tracks that line; ask for an arc and it generates the intermediate points. The controller does this thousands of times per second, and the resolution of that calculation sets the floor on surface quality.

The two modes you will see most are G01 linear and G02/G03 circular. Older controls could only approximate arcs with short line segments, which leaves visible facets on a curved wall. Modern controls interpolate the arc directly, so a Ø40 mm bore comes off the machine round rather than polygonal. On a lens housing or a valve seat, that difference shows up on a profilometer, not just on a print.

Look-ahead is the part of this function that most people underestimate. The control reads ahead through the program block queue, anticipates corners, and slows the feed before the corner instead of after. A control with a short look-ahead buffer will overshoot at a sharp internal corner and leave a witness mark. A control with a deep buffer holds the corner.

Interpolation also covers helical and spiral moves, which matter for thread milling and for ramping into a pocket. If your part needs a tapered thread or a helical oil groove, the question to ask is whether the control supports helical interpolation in the same block as cutter compensation. Many mid-range controls do not.

The practical limit: interpolation accuracy is only as good as the mechanical repeatability underneath it. A control that resolves 1 μm cannot hold ±0.005 mm on a machine with 20 μm of backlash. Fix the mechanics first.

Feed control sets the commanded velocity along the path; acceleration control sets how fast the machine reaches that velocity. They are separate functions and they fail in different ways. If feed is wrong, the surface finish drifts. If acceleration is wrong, the machine overshoots at direction changes and the corners go soft.

Acceleration limits are usually set per axis, and the lowest axis wins. A 4,000 mm × 400 mm × 150 mm travel machine may have a fast X and a much slower Z. On a deep pocket with a lot of Z retracts, the Z acceleration dominates cycle time, not the spindle. When we quote cycle time, we look at the axis with the worst acceleration profile, not the fastest one.

Jerk control, sometimes called look-ahead smoothing, limits the rate of change of acceleration. Turn it off and the machine is marginally faster on long straight cuts but hammers the ballscrew on short moves. Turn it up and corners get rounder. For parts with tight internal radii, we keep jerk control moderate and accept a slightly lower feed.

On aluminium, a typical roughing feed sits between 2,000 and 5,000 mm/min with a 12 mm carbide end mill. On 17-4PH stainless, that drops to 400–900 mm/min. The control does not care what the material is; the programmer sets the ceiling. The function only enforces it.

Where this bites: high-speed finishing of a thin-wall aluminium housing. The control wants to accelerate out of every corner, and the wall deflects. We reduce acceleration on the finishing pass even though the control allows more. The function is capable; the part is not.

Tool management covers the tool table, the length and radius offsets, and the wear compensation that the operator updates between parts. This is the function that lets one program run on a machine with a different tool stick-out, or on the tenth part after the first nine wore the cutter down.

Cutter compensation, G41 and G42, shifts the path sideways by the tool radius so the programmer can draw the part at nominal size. The control handles the offset. When a Ø10 mm end mill wears to an effective Ø9.94 mm, the operator edits the radius offset and the next part comes back to size without touching the program.

Tool life management is a separate function on higher-end controls. It tracks cutting time or spindle load per tool and flags when a tool should be changed. For a 10,000-part run in 6061 aluminium, that flag is what keeps the last part as good as the first. Without it, tool wear shows up as a slow drift in a bore diameter.

The limit is that cutter compensation only works in the plane it is defined in. Compensating a 3D contoured surface with G41 is unreliable; the control cannot offset in the tool axis direction. For those surfaces we program the true toolpath with the actual radius and manage wear through the tool table instead.

On mill-turn centers, this function gets more complicated because the tool can be driven by either the milling spindle or the turning turret. The offset has to be applied in the right frame. Getting that wrong is one of the more common setup errors we see on first-article inspection.

The coordinate function maps program coordinates to machine coordinates. G54 through G59 are the usual work offsets; G92 shifts the current frame. On a 5-axis machine, you add rotary frames on top of that, and the order in which the control applies them matters.

For a part held in a trunnion, the control has to know where the rotary axis center sits relative to the workpiece. That is a kinematic model, and it is configured once per machine. If the model drifts, features machined at different rotary angles will not line up. We verify it with a test cut on a known artefact before a production run.

Subprograms and coordinate rotation are part of the same family. If you have eight identical bores on a bolt circle, the control can rotate the frame rather than repeat the code. That reduces the chance of a typo and makes the program shorter.

Scaling is a function most shops leave off. It looks convenient for shrinkage compensation, but it scales every axis including the tool radius, which is almost never what you want. We set scale to 1 and adjust the model instead.

The boundary here: work offsets assume the fixture is rigid and repeatable. If a vise jaw lifts 0.05 mm under clamping pressure, no coordinate function will fix it. The control measures what the machine does, not what the part does after the clamp releases.

Feedback is how the control knows where the axis actually is. A semi-closed loop reads the motor encoder; a full closed loop reads a scale on the slide. Full closed loop costs more but corrects for ballscrew pitch error and thermal growth, which is why it shows up on machines holding ±0.005 mm over long travels.

Pitch error compensation is a lookup table the control applies to correct for the ballscrew's natural inaccuracy. On a 4,000 mm travel machine, that table can be the difference between 30 μm of accumulated error and 5 μm. It is set at the factory and should be re-checked after a crash.

Thermal compensation is the other half. A spindle running at 15,000 rpm for four hours grows, and the Z axis drifts with it. Controls with thermal models adjust the commanded position based on spindle load and ambient temperature. Without it, the first part and the four-hundredth part differ by more than the tolerance.

Backlash compensation handles the small dead zone when an axis reverses direction. It is a fixed number the control adds or subtracts on reversal. It works well on a new machine; on a worn one the backlash varies along the travel and a single value over-corrects in some places and under-corrects in others.

These functions have a ceiling. They correct systematic error, not random error. If your measurement spread is random part to part, the problem is upstream: fixturing, material, or the tool. No amount of compensation will tighten a random distribution.
