  MDI vs MEMORY vs JOG: Which Mode for Which Task

The control on a CNC machine usually holds several modes: EDIT, MEMORY (auto), MDI, JOG, HANDLE and REF. In MEMORY the machine reads a stored program from its own memory and runs it start to finish. In MDI, or manual data input, you type a single block on the keypad and press cycle start. The control parses that block, moves the axes, then waits for the next entry.

The key difference is where the command lives. A MEMORY program is written to the control's storage and stays there after a power cycle. An MDI block is executed and then discarded. It never overwrites the active program, and it does not change the program number or the tool offsets unless the block itself is an offset command.

Internally the control treats an MDI block almost like the first line of a program. Modal states carry over from the last MDI entry, so the machine remembers G80, G90 or the active feed rate until you change them. That modal memory is useful and also the most common source of surprise, because operators assume each MDI block starts from a clean slate. It does not.

Because there is no program to scroll back through, MDI is best for short, verifiable actions: index the tool changer, spin the spindle at a set rpm, rapid to a known position, check a probe reading, or jog an axis to a datum. Anything longer than a few blocks belongs in a written program where it can be reviewed and reused.

• 1
  Single block onlyOne press of cycle start runs one block, not a sequence.
• 2
  No storageContent is dropped after execution; nothing is saved to the program library.
• 3
  Modal states carryG90/G91, G80, feed and spindle states persist between entries.
• 4
  Offsets stay untouchedMDI does not edit work offsets or tool offsets by itself.

The most common use is setup. After clamping a part you need to bring the spindle close to a face so you can touch off with a gauge block or a probe. Typing G0 G90 G54 X0 Y0 Z50 and pressing cycle start is faster than writing a program, and it does not disturb what is already loaded.

Tool change testing is another. If a pocket or an angle head has been sitting unused, an MDI entry like T12 M6 lets the operator confirm the arm swings clean and the taper seats before the real cycle starts. The same applies to spindle warm-up runs, which on a 12,000 rpm spindle are usually 20–30 minutes at stepped speeds.

MDI is also the standard way to call a probe or a measuring macro. On many controls the macro is stored under a fixed number, so an MDI line calls it directly and the result lands in a macro variable you can read on screen. No program edit is needed, and the measurement does not touch the part program.

Finally, MDI is how most operators stop a machine cleanly. After a feed hold, you enter M5 and M9 by hand to stop the spindle and coolant, then retract with a G91 G0 Z10 move. Short commands, immediate effect, no risk of an unplanned block running later.

• 1
  Touch-off and datum checksRapid near a face, then jog or probe to set the work offset.
• 2
  Tool change prove-outT12 M6 confirms the arm indexes and the taper seats before production.
• 3
  Spindle warm-up20–30 minutes at stepped speeds before a first production cut.
• 4
  Probe and macro callsInvoke a measuring macro without editing the stored program.

MDI is a hand tool, and like any hand tool it stops being safe past a certain length. If an operation needs more than about four or five blocks, the odds of a typo go up faster than the time you save. A missing decimal point turns X1.5 into X15, and on a machine with a 4,000 mm envelope that difference is measured in tool holders, not in scrap parts.

Production runs should never be driven from MDI. There is no restart-from-block, no program verification, no traceability. If quality wants to know which spindle speed was used on a lot, or if you need to re-run the same cycle next month, the command has to live in a program with a revision number.

Some controls limit what MDI can do at all. Certain safety interlocks, pallet change cycles and door-open conditions may be blocked in MDI even if they run fine in MEMORY. Tool life management and adaptive control loops usually only arm in automatic mode, so a speed override you test in MDI may not behave the same way in the real cut.

The other trap is modal carryover. If the previous MDI block left the machine in G91 incremental, your next block will move relative to the current position, not to the datum. Check the mode line on the screen before you press cycle start, every time.

• 1
  Keep it under five blocksLonger sequences belong in a written, reviewable program.
• 2
  Never drive production from MDINo restart point, no verification, no record for quality.
• 3
  Watch for blocked functionsPallet changers and safety interlocks may not arm in MDI.
• 4
  Confirm the modal stateRead G90/G91 and the active plane before cycle start.

Fanuc keeps MDI as a separate mode selectable from the mode switch. Typed blocks appear in a small buffer on the position screen and are cleared when you leave the mode. On Fanuc, M30 in MDI will reset the control and clear the modal state, which is a quick way to get back to a known starting point.

Siemens 840D treats MDI as a mode on the same softkey row as AUTO and JOG, and it supports a multi-line MDI buffer that you can edit before running. That is convenient, but it also means a leftover line from yesterday can still be sitting in the buffer. Clear it before you start.

Haas controls put MDI next to the jog and memory keys and show the current modal G-codes in a dedicated display. That display is worth reading, because it shows exactly which states will carry into your next block. Heidenhain calls the equivalent mode MDI as well, with positioning blocks entered in plain text.

The differences are mostly ergonomic. The underlying rule does not change: one block at a time, executed immediately, with modal state carried from whatever came before. Understand that rule and the mode behaves predictably on any control you step up to.

• 1
  FanucSeparate mode position on the switch; M30 resets and clears modal state.
• 2
  Siemens 840DMulti-line buffer on the softkey row; check for leftover lines.
• 3
  HaasDedicated modal display next to the entry field; read it first.
• 4
  HeidenhainPlain-text positioning blocks in MDI mode; same one-block rule.

Start every MDI session with the feed override low. Twenty percent is a reasonable default for a first move after a setup change. If the axis goes the wrong way, you have time to hit feed hold and the slide has not traveled far. Bump the override up only once the direction and distance are confirmed.

Keep one hand near the feed hold button, not on the keyboard. A block like G0 G91 G28 Z0 is a full retract to the machine reference; if a fixture or a vise sits in the path, no amount of fast typing will stop it. The feed hold button will.

Never type an MDI block with the door open unless the control explicitly allows it at reduced speed. On machines with an interlocked door, the control may pause a spindle command or ignore it, and a partial execution leaves you guessing which part of the block ran.

Log critical entries. If you use MDI to touch off a tool or set a datum, write the block and the resulting offset value on the setup sheet. The next operator can then reproduce the setup instead of re-deriving it, and a job that runs twice a year stops depending on one person's memory.

• 1
  Start at 20% feed overrideRaise it only after direction and distance check out.
• 2
  Hand on feed holdEspecially before any G28 or full retract move.
• 3
  Respect the door interlockA blocked spindle command leaves partial execution behind.
• 4
  Write it on the setup sheetNext operator reproduces the setup instead of guessing.
