Wholesale large-scale CNC processing services

• 1
  Key takeaways
• 2
  What to compare before you award a wholesale large-scale CNC processing order
• 3
  Machine travel and part size: the first filter in wholesale large-scale CNC processing
• 4
  Tolerance and surface finish: reading the numbers correctly
• 5
  MOQ, batch size and where the unit cost actually comes from
• 6
  Certifications and documentation that fit your industry
• 7
  Lead time, quoting speed and late-delivery risk
• 8
  How to run a wholesale large-scale CNC processing RFQ in 6 steps

Size is the first thing that removes suppliers from your list. A machining center with 500 mm of X travel cannot cut a 1,200 mm frame no matter how good its tolerance is. When you screen for wholesale large-scale CNC processing, ask for the actual work envelope of each machine, not a general statement that the shop handles big parts.

GreatLight runs 127 high-precision CNC machines across three wholly-owned plants covering 7,600 m². The largest travel is 4,000 × 400 × 150 mm. For mid-size work there are envelopes of 750 × 1,150 × 550 mm and 600 × 600 × 600 mm, and compact cells at 500 × 500 × 450 mm and 500 × 310 × 200 mm. There are 16 simultaneous 5-axis machining centers and a Ø400 mm rotary table.

The practical question is not only whether the part fits. It is whether the part fits with the fixture, the tool holder and the clearance for approach angles. A 3,900 mm part on a 4,000 mm table leaves 100 mm for clamping and edge finding. That is often not enough.

If a part needs four sides machined and the envelope only allows one face at a time, you pay for four setups. Each setup adds alignment time and a new chance for stack-up error. Sometimes the right answer is a smaller part split into bolted sections, and that is a design decision worth making before you request quotes.

Every supplier will quote a tolerance. Fewer will tell you what it applies to. A general ±0.005 mm claim on a 2,000 mm part is not the same as ±0.005 mm on a 100 mm bore. Thermal growth, tool wear and fixture deflection all scale with length, so the achievable tolerance on a long part is usually a smaller number than the brochure suggests.

Ask which features carry the tight tolerance and which are free. On most large parts, only a handful of dimensions matter: a bearing bore, a mounting face, a pin hole pattern. If the drawing calls out a blanket tolerance across every surface, you are paying for capability you do not need.

Surface finish follows the same logic. Ra 0.2–0.8 μm is a fine finish that normally needs a separate finishing pass or a grinding operation. Ra 0.8–1.6 μm is a common high-quality machined finish. Ra 1.6–3.2 μm is as-machined and is fine for most structural faces. Specify the finish per surface, not per part.

One more point on large work: measurement matters as much as cutting. A ±0.005 mm result you cannot verify is a claim, not a fact. Ask how the shop inspects a 3,000 mm feature. CMM travel, laser tracking and portable arms all have different ranges, and the inspection method should appear in the quote discussion.

Wholesale pricing is often described as a volume discount. In practice, most of the saving comes from spreading fixed costs: programming, fixture design, first-article inspection and machine setup. A 10-piece run and a 1,000-piece run carry the same programming cost, so the per-unit figure moves a lot between them.

That is why a no-MOQ policy matters more than it sounds. It lets you order one prototype to prove the design, then scale to a 10,000+ part run on the same process. The alternative is a supplier who forces a 500-piece minimum before you have validated anything, which turns a design change into scrap.

Material choice moves the cost too. Aluminum 6061 and 7075 cut fast. Stainless 316L and 17-4PH are slower and eat tooling. Inconel and titanium TC4 (Ti-6Al-4V) are slower again and often need lower feed rates and more frequent tool changes. A quote that does not separate material from machining time hides where the money goes.

Ask for the price to be broken into material, machining, finishing and inspection. If a supplier will not split it, you cannot tell whether a cheaper quote is a better process or a thinner inspection plan.

• 1
  Fixed cost per orderProgramming, fixture, first article. Same at qty 1 and qty 1,000.
• 2
  Variable cost per partMaterial, cycle time, tool wear, finishing passes.
• 3
  Cost that scales with sizeLong cycle times, large stock removal, harder inspection.

Certification is not a ranking. It is a scope statement. ISO 9001:2015 covers a general quality management system and is the baseline for most industrial work. IATF 16949:2016 adds automotive-specific requirements on traceability, change control and defect prevention. ISO 13485:2016 is the medical device standard. ISO 27001:2022 covers information security.

GreatLight holds ISO 9001:2015, IATF 16949:2016, ISO 13485:2016 and ISO 27001:2022. If your part goes into a vehicle, the automotive certificate is the one that matters to your customer. If it goes into a medical device, the medical standard is the one your auditor will ask about. Match the certificate to the end use before you match the price.

Documentation matters as much as the certificate. For large parts, you usually want material certificates, dimensional reports and, where relevant, hardness or surface finish data. GreatLight inspects 100% before shipment and runs raw material checks, in-process monitoring and a final inspection, with reports on request.

Confidentiality is part of the same conversation. Uploads are treated as secure and confidential, and an NDA is available on request. For defense, medical or unreleased product work, sort the NDA out before the first STEP file leaves your server, not after the first invoice.

Lead time on large parts is driven by three things: material availability, machine availability and inspection. A standard aluminum plate may be in stock. A 4,000 mm titanium billet may not be, and that single item can dominate the schedule. Ask what is in stock and what has to be ordered.

Quoting speed is a useful signal. If a shop needs a week to return a number, the same shop will likely need a week to answer a question during production. GreatLight returns a quotation and a free DFM analysis within 12 hours, and production can start within 24 hours. Parts ship in 3–5 days on standard work.

Late delivery is the risk buyers underestimate. A supplier that misses a date on a large part usually misses it for a reason that was visible at the quote stage: an overloaded machine, an unclear drawing or a finishing step nobody scheduled. Ask how the shop tracks jobs and what happens when a machine goes down.

Historical data is worth asking for. GreatLight reports a late-delivery probability below 2% on its record. Treat any such figure as a question to explore, not a guarantee. Ask what the number covers and which jobs are excluded.
