Wichita's industrial identity comes from aircraft manufacturing. That history set the local habit of asking how a part fails, not just how it looks on a screen. When a Kansas shop sends work to a machining partner, the useful question is not who owns the newest machine. It is who can hold the drawing through five or six operations without losing position.

A Wichita CNC machining expert starts with datum strategy. If the drawing calls out a datum on a thin wall or on a surface that will be coated later, the setup plan has to change before the first cut. GreatLight reviews this at the DFM stage. We return a quotation and a free DFM analysis within 12 hours, which usually surfaces datum and wall-thickness problems before metal is ordered.

Machine count matters less than fit. Our 3 plants run 127 high-precision CNC machines, of which 16 are simultaneous 5-axis machining centers. That mix matters for Wichita work because aerospace and industrial brackets often need five faces in one setup, while simple housings are cheaper on a three-axis mill.

The last check is inspection access. A feature that cannot be reached by a CMM probe or a micrometer is a feature nobody can verify. We plan inspection before machining, not after. That single habit prevents most of the disputes that show up two weeks before a build.

Five-axis machining adds two rotary axes to the usual X, Y and Z. The cutting tool can approach a part from an angle instead of straight down. For a part with undercuts, deep pockets or compound angles, that means one setup instead of three or four. Every setup removed is a datum transfer removed, and datum transfer is where most of your tolerance disappears.

The arithmetic is simple. A three-axis process with four setups can stack four positional errors, plus four fixture errors. A five-axis process with one setup stacks one. With our tolerance of ±0.005 mm (±0.0002 in), the difference decides whether a bore-to-bore relationship holds at the far end of a long part.

There is a cost. Five-axis toolpaths are longer to program and slower to prove out, and rigid setups get harder because the part hangs off a rotary table. Short, stiff parts with simple geometry usually run cheaper on a three-axis machine. We keep 27 three-axis machines for exactly that reason.

Rotary table size is the practical limit. Our largest rotary table is Ø400 mm. A part that needs to swing past that diameter has to be repositioned, which reintroduces the setup you were trying to avoid. Send the part envelope early and we will tell you whether one setup is realistic.

Big parts are not just heavy. They sag, they spring back after clamping, and they move when the material is removed. GreatLight machines up to 4,000 mm maximum processing size on the large travels, with 4,000 × 400 × 150 mm on the longest bed. Medium travels cover 750 × 1,150 × 550 mm and 600 × 600 × 600 mm, and compact travels cover 500 × 500 × 450 mm and 500 × 310 × 200 mm.

Long, thin parts such as aircraft stringers behave differently from a solid block. Roughing releases internal stress, so the part bows. The fix is a stress-relief step or a rough, wait, finish sequence, not a tighter tolerance on the drawing. If you specify ±0.005 mm on a 2,000 mm aluminium extrusion without a stress-relief note, no shop can hold it reliably.

Material choice drives the same decision. Aluminium 6061 and 7075 cut fast and hold tight tolerance. Titanium TC4 (Ti-6Al-4V) and Inconel 625 or 718 cut slowly and generate heat at the edge, so wall thickness and tool reach matter more than spindle speed. Stainless 17-4PH sits in between and machines well in the H1025 condition.

We quote a process, not a wish. When a feature is outside what the geometry allows, the DFM note says so and offers a change: relax the tolerance, split the part, or add a finishing operation after heat treatment.

A finish callout of Ra 0.2–0.8 μm is a different process from Ra 1.6–3.2 μm as-machined. The fine range usually needs a smaller stepover, a sharper tool and often a separate finishing pass on a second machine. That is time, and time is money. Put the callout only where the function needs it: sealing faces, bearing bores, sliding surfaces.

Ra 0.8–1.6 μm covers most mating faces and is reachable in a normal finishing pass. As-machined Ra 1.6–3.2 μm is fine for brackets, covers and non-contact surfaces. Marking the whole drawing at Ra 0.4 μm will roughly double the cycle time and add nothing to the assembly.

Coating changes the number. Anodizing builds 5–25 μm depending on the type, so a bore that is on size before coating will be undersize after it. Hardcoat anodizing grows more than clear anodizing. State the finish on the drawing and let the shop compensate the pre-plate dimension.

Deburring is part of the finish. A laser-marked edge or a bead-blasted surface hides small burrs but does not remove them. If the part touches a human hand or a seal, say so and we will add a tumbling or brushing step.

Aluminium covers most of the volume: 6061, 6061-T6, 2024, 5052, 5083, 6063, 6082, 7075 and ADC12 for castings. 6061-T6 is the default for machined brackets. 7075 gives higher strength but machines with more spring and is harder to anodize evenly.

Stainless shows up on food, medical and marine work: 303, 304, 316, 316L, 420, 430, 431, 440C and 17-4PH. 303 machines freely but is not ideal for welded assemblies. 316L is the choice for corrosion, and it work-hardens if the tool rubs instead of cuts.

Steel grades are 1018, 1045, 4130, 4140, 4340, A36 and tool steel. 4130 and 4140 are common in aerospace and motorsport fixtures. Both need a pre-hardened or normalized condition decision before roughing, or the part moves after heat treatment.

Titanium and nickel alloys stay a smaller share but take the most planning: TA1, TA2, TC4 (Ti-6Al-4V), Inconel, plus magnesium AZ31B and AZ91D. Magnesium needs chip control and a fire-safe routine. Copper, brass and beryllium copper cover electrical and thermal parts, and plastics from POM and PEEK to carbon fibre cover housings and insulators.
