Will CNC Machines Run Off Generator?

• 1
  What the CNC actually needs from the supply
• 2
  Sizing: kW, kVA and the inrush nobody counts
• 3
  Where the setup goes wrong
• 4
  Which machines tolerate generator power best
• 5
  How to verify a generator setup before production
• 6
  Machine class vs generator demand

A CNC does not draw a steady load. It draws a low idle current, then a spindle ramp of several times that, then short peaks every time an axis accelerates. The question of will cnc machines run off generator power comes down to whether the generator can follow that load profile without letting voltage or frequency move.

Servo drives and spindle drives have a DC bus behind a rectifier. If input voltage sags, the bus sags. The drive compensates by pulling more current, which sags the voltage further. On a weak generator this loop can run away until the drive trips on undervoltage. That is the first limit you hit, and it shows up as a fault code, not as a bad part.

Controls and encoders are a different problem. They draw little current but they need a clean waveform. Harmonic distortion on the supply can couple into signal lines and cause position errors that look like mechanical faults.

• 1
  Voltage windowMost industrial CNC controls tolerate ±5% on a steady basis and ride through a 10% dip for a few cycles.
• 2
  Frequency window50 Hz or 60 Hz nominal, ±1%. Spindle speed and feed sync scale with it.
• 3
  WaveformTotal harmonic distortion under 5% keeps drives and controls happy.

Add up the continuous loads first: spindle motor, axis drives, coolant pump, chip conveyor, hydraulic unit, cabinet cooling. That total is your running load. A small 3-axis vertical mill with a 7.5 kW spindle often lands around 12 to 15 kW running.

Then add the transient. When a spindle accelerates from zero to 12,000 rpm, the drive can pull three to six times its rated current for half a second to a few seconds. A generator sized only for the running load will drop voltage during every tool change and every spindle start.

Power factor matters too. Motors and drives run at a power factor below unity, often 0.8 to 0.9, so kVA is always higher than kW. Generators are rated in both, and the kVA figure is the one that limits you. A 30 kW / 37.5 kVA set is not the same as a 30 kVA set.

A practical starting point is running load plus 30 to 50% headroom, then check that the generator's transient recovery meets the drive's ride-through. If the machine has a large spindle or a hydraulic pump that starts under load, go higher.

• 1
  Running loadSum every motor and pump that can run at the same time.
• 2
  TransientSpindle ramp and axis acceleration, 3–6× for under 3 seconds.
• 3
  Power factorSize on kVA, not kW. Motors sit near 0.8–0.9.
• 4
  Headroom30–50% above running load as a floor, not a target.

Undersizing is the most common mistake. A generator that runs a machine at idle can still fail on the first heavy cut. The symptom is a voltage dip during acceleration, and the machine either faults out or, worse, keeps cutting with a position error.

The second mistake is ignoring waveform quality. A cheap set with a distorted output can run a drill press fine and still upset a servo drive. If the drive has an input filter it may mask the problem at light load and reveal it at full load.

Transfer switching is the third. On backup power, an open transition transfer switch drops the machine for 100 ms or more. Most CNC controls will fault and require a home cycle. A closed transition switch keeps the ride-through short enough for many controls, but not all.

Grounding and neutral bonding are the fourth. A generator with a floating neutral behaves differently from a bonded one, and drives with EMI filters can trip residual current devices. Get the bonding scheme right before the first power-up.

• 1
  Voltage dip on rampGenerator too small or governor too slow.
• 2
  Position error without a faultWaveform distortion coupling into encoder signals.
• 3
  Fault on transferOpen transition switch, control loses ride-through.
• 4
  Nuisance RCD tripNeutral bonding or EMI filter leakage, check the scheme.

Older machines with analog drives and simple controls are usually the most tolerant. They ride through voltage dips better because there is less digital logic to reset, and their drives have wider input windows. That does not make them accurate, but they keep running.

Modern machines with full digital drives and absolute encoders are less tolerant. They need a clean supply and they fault fast. The trade is worth it when the power is good, because the same drives deliver the position accuracy that lets us hit ±0.005 mm on tight work.

Spindle type matters as much as the control. A belt-driven spindle has less inrush than an integral motor spindle of the same power. A high-speed spindle with a small frame can still pull a big transient because the drive ramps it hard.

If you run a mixed shop, size the generator for the worst machine you will start, then add headroom for whatever runs at the same time. Do not average across the shop floor.

• 1
  TolerantAnalog drives, belt spindles, older controls, generous input windows.
• 2
  SensitiveFull digital drives, absolute encoders, high-speed integral spindles.
• 3
  Size forThe largest single machine start, plus concurrent running load.

Do not trust the nameplate. Load the machine and watch the voltage. Put a meter on the incoming supply and log it through a spindle ramp, a rapid traverse, and a heavy cut. If voltage stays inside ±5% and frequency inside ±1%, the supply is usable for most work.

Run a test part that exercises the machine. A circle interpolation at high feed shows following errors clearly. If the circle comes out lobed or out of round, the supply or the tuning is the cause, and you need to separate them before running customer parts.

Check the drive fault history after the test. Even if the part passed, a logged undervoltage event means the margin is thin. On a cold morning the generator makes slightly less power, and the margin can disappear.

For backup power, test the transfer with the spindle running. That is the worst case and the one that decides whether the setup is production-ready.

• 1
  Log the rampSpindle start and rapid traverse with a meter on the supply.
• 2
  Cut a test circleHigh-feed interpolation reveals following errors.
• 3
  Read the fault logAny undervoltage event means the margin is too thin.
• 4
  Transfer under loadTest the switch with the spindle running, not at idle.
