Every machined part starts as a CAD model. CAM software turns that model into G-code, a list of coordinates, feed rates and spindle speeds. The machine does not read your model. It reads the code. If the CAM setup picks the wrong tool or leaves too little stock for a finishing pass, the machine will execute that mistake perfectly and repeat it 400 times.

The first thing a CNC machine runs is the program itself, loaded into the control. On a Fanuc or Siemens control, the operator checks tool offsets, work offsets and the active coordinate system before the first cut. A wrong offset in Z is the most common way a first article gets scrapped. Most of the setup time on a job sits here, not in the cutting.

Post-processors matter more than most buyers expect. The same CAM file posted for two different machines produces different code, because each control handles arcs, canned cycles and high-speed look-ahead differently. A program that runs clean on a 3-axis mill may alarm on a mill-turn center until the post is tuned.

What this means for you: send a STEP file plus a 2D drawing with tolerances. If a critical feature depends on the control's look-ahead behavior, say so. We can quote and run a DFM check within 12 hours, and flag program-level risks before metal is cut.

A CNC machine runs on the cutting tool, and the tool has to match the material. Aluminium 6061 cuts clean at 3,000–10,000 rpm with 2- or 3-flute carbide and generous rake. The same cutter in 316 stainless will chatter, work-harden the surface, and burn through inserts in minutes. Tool geometry is not a preference. It is a constraint.

Coatings do part of the work. TiAlN and AlTiN hold up in dry or near-dry cuts on steel and stainless. Uncoated polished carbide is often the better call for aluminium, because coatings can drag and smear on soft alloys. For 17-4PH or Inconel, expect slower surface speeds, heavier coolant, and more frequent tool changes.

Rigid tapping, thread milling and boring heads solve specific problems. Thread milling costs more per hole but survives a broken-tool crash better than a tap, and it works on large diameters where taps are not made. On a Ø400 mm rotary table, boring with a single-point tool holds size better than helical interpolation on deep bores.

Spindle taper sets the ceiling. A BT30 spindle is fine for small aluminium parts but struggles with a 50 mm face mill in steel. HSK and BT40 machines carry heavier radial loads. If your part has deep pockets in 4140, ask which spindle the shop will run it on before you accept the quote.

Almost any machinable stock can run on a CNC machine, but machinability changes everything downstream: cycle time, tool life, achievable finish, and the risk of distortion after heat treat. Free-machining grades exist for a reason. Brass C36000 and 12L14 steel cut fast and leave good finishes; they are also weaker or harder to weld.

Aluminium is the default for prototypes and enclosures. Grades 6061 and 7075 machine well and hold ±0.005 mm on tight features. 7075 gives higher strength but is less weldable and more prone to stress relief movement after heavy material removal. Thin walls under 1 mm need light finishing passes and sharp tooling.

Stainless 303 machines far better than 304 or 316, but it is not the right choice for a part that sees chloride exposure. 17-4PH in the H900 condition machines at roughly half the speed of 303 and needs carbide with strong edge geometry. Titanium TC4 (Ti-6Al-4V) is worse still: low thermal conductivity, high tool wear, and a real fire risk if chips are not cleared.

Plastics behave differently again. POM holds tolerance and cuts clean. PEEK needs sharp, polished tools and slow feeds to avoid melting. Carbon fibre reinforced polymer is abrasive and delaminates if the tool pushes rather than shears. On any of these, the machine is the easy part; the process window is the hard part.

A machine runs on whatever holds the part. Soft jaws, vacuum plates, magnetic chucks and custom fixtures all do the same job: locate the stock repeatably and resist cutting forces. Get this wrong and the machine cuts air on pass one and gouges the part on pass two. For thin plates, a vacuum plate with a support grid beats clamping at four corners.

Five-axis work changes the answer. A Ø400 mm rotary table with a tombstone lets you machine five faces in one setup, which removes stack-up error from re-fixturing. That is the main reason 5-axis holds ±0.005 mm on parts with features on multiple faces. It also lets the tool reach undercuts and blended radii that a 3-axis machine cannot touch without a custom angle fixture.

In-process probing catches drift before the part is finished. After roughing, a probe can verify stock condition; after semi-finishing, it can confirm a critical bore before the finish pass. This is standard on long runs and on any part where one feature drives assembly.

Final inspection is dimensional and documented. We inspect 100% of parts before shipment, with raw material checks, in-process monitoring and final reports on request. If your drawing calls out a CMM report or a first article inspection, ask for it at the quote stage, not after the parts ship.

Machine configuration is a cost and capability decision. A 3-axis mill cuts three faces, requires multiple setups for the rest, and is the cheapest per hour. A 4-axis mill adds an indexer so you can rotate around one axis and machine four faces in two setups. A 5-axis center machines five faces in one setup and reaches compound angles. A mill-turn center does turning and milling without moving the part between machines.

For prismatic parts with all features on one side, 3-axis is the right answer and 5-axis just adds cost. For a housing with bores on two perpendicular faces, 5-axis usually wins because the alternative is two fixtures and a stack-up tolerance that eats your ±0.005 mm budget. For a turned shaft with cross holes and flats, mill-turn removes a whole operation.

Size matters too. Our travel envelope runs from 500 × 310 × 200 mm on compact machines up to 4,000 × 400 × 150 mm for long parts. If your part fits in the small envelope, running it on a large machine wastes cycle time and money. If it does not fit, no amount of clever fixturing helps.

One practical check: ask how many setups the shop plans. Fewer setups means less stack-up error and usually faster delivery. On a 5-axis job we can often start production within 24 hours of quote approval, with parts shipping in 3–5 days.
