A 5-axis quote is a stack of hours, not a single rate. Setup, programming, fixturing, roughing, finishing and inspection each carry their own time. Two shops can quote the same STEP file and land far apart because they made different assumptions about how many setups the part needs and how much hand work it will take.

The first split is setup count. A part with features on five faces can run in one clamping on a simultaneous 5-axis center with a Ø400 mm rotary table, or in three or four clamps on a 3-axis mill. The 5-axis route carries a higher hourly rate but removes re-fixturing, and every re-clamp adds a datum shift. On complex geometry that shift is where tolerance stacks up.

The second split is stock. A quote that assumes bar stock and one operation looks cheap until the shop discovers the part must be carved from a 300 × 300 × 120 mm billet with 70 percent material removal. Ask what stock size the number assumes. If the answer is vague, the quote is a placeholder.

The third split is inspection. Some shops quote machining only and measure a few critical dimensions with calipers. Others hold ±0.005 mm and run a full dimensional report. Both are legitimate, but only one will pass an aerospace or medical receiving inspection without a second invoice.

• 1
  Ask for setup countOne clamping versus four changes the price more than spindle speed does.
• 2
  Ask for assumed stockMaterial removal percentage explains most of the gap between low and high quotes.
• 3
  Ask what is measuredA quote without an inspection line is a quote without a quality claim.

5-axis earns its rate on parts with compound angles, deep pockets, or features on non-orthogonal faces. Impellers, turbine housings, medical bone plates and structural brackets with angled bosses all fall into this group. If the geometry needs a fourth or fifth orientation to reach, the machine pays for itself by removing setups and hand blending.

It also wins on thin walls and long reach. A 5-axis center can tilt the tool to keep a constant contact angle, which reduces chatter and lets you take lighter, faster passes. On a 4,000 mm long part with a 150 mm tall section, that control matters more than raw spindle power.

Plain prismatic work is a different story. A plate with holes on two faces, a shaft with a keyway, a simple housing — these run faster and cheaper on a 3-axis mill or a mill-turn center. Quoting them on 5-axis adds setup and programming time for no gain. A good supplier will tell you this instead of upselling.

Volume changes the answer too. From one prototype to a 10,000-piece run, the per-part cost curve is not linear. At low volume the fixture and CAM time dominate. At high volume the shop may move the part to a 4-axis or dedicated fixture, and the 5-axis hours drop. Ask how the quote changes at 100 and at 1,000 pieces.

• 1
  Use 5-axis for compound anglesTwo or more non-orthogonal faces in one clamping.
• 2
  Use 3-axis for flat prismatic partsFewer setups, lower hourly rate, same result.
• 3
  Re-quote at volume breaksCost per part is not a straight line from prototype to production.

A blanket note like "machined to drawing" is not a tolerance. Usable 5-axis quotes state a general tolerance band plus any tighter callouts, and they name the datum scheme. Without datums, two shops can measure the same part and disagree about whether it is in spec.

For size, ±0.005 mm (±0.0002 in) is the fine end of general machining and should be reserved for fits that need it. Applying it to every dimension raises inspection time and scrap risk. A better approach is to flag five or ten critical dimensions and leave the rest at a looser band that the shop can hit on a normal pass.

Surface finish behaves the same way. As-machined at Ra 1.6–3.2 μm covers most functional faces. Ra 0.8–1.6 μm is a controlled finishing pass. Ra 0.2–0.8 μm usually needs a separate operation, sometimes hand polishing, and it should be quoted per surface rather than as a single line.

Watch for finish clauses that hide a second vendor. If the shop subcontracts anodizing or electroless nickel, the finishing lead time sits outside their machining schedule. Ask whether finishing is in-house and how many days it adds.

• 1
  Demand a datum schemeGeneral tolerance without datums is not measurable.
• 2
  Tighten selectivelyFlag critical fits only; loose dimensions cut cost and scrap.
• 3
  Quote finish per surfaceOne Ra note across a whole part is a pricing trap.

Lead time has three parts: quote turnaround, production start, and the shipping window. A supplier that returns a quotation and DFM analysis within 12 hours is fast on paper. What matters next is when chips actually fly. Production start within 24 hours is achievable when material is in stock and the fixture design is simple.

Typical machined parts ship in 3–5 days once production starts. Anything with a subcontract finishing step, a custom fixture, or a material the shop has to order will run longer. Ask the supplier to break the number into these stages instead of giving one date.

MOQ is the term that kills prototype programs. A shop with no minimum order quantity lets you buy one piece, then scale to 10,000+ part runs on the same process. If a supplier quotes a 500-piece floor for a bracket you need in threes, that quote is not for your project.

Certifications decide whether the quote is even usable. ISO 9001:2015 covers general quality management. IATF 16949:2016 applies to automotive and EV work. ISO 13485:2016 is the medical device standard. ISO 27001:2022 covers information security, which matters if you are sending unreleased CAD. Match the certificate to your industry before you compare price.

• 1
  Split the lead timeQuote, production start and ship date are separate commitments.
• 2
  Confirm MOQ in writingA floor of 500 pieces is not a prototype service.
• 3
  Match certification to industryIATF 16949 for automotive, ISO 13485 for medical.

Capacity is the quiet variable. A shop with 16 simultaneous 5-axis machining centers can absorb a rush job without pushing your date. A shop with two machines and a full queue cannot, no matter what the quote says.

Look at the machine envelope against your part. Travel sizes matter: 4,000 × 400 × 150 mm for long parts, 750 × 1,150 × 550 mm and 600 × 600 × 600 mm for mid-size work, and 500 × 500 × 450 mm or 500 × 310 × 200 mm for compact parts. A 4,000 mm maximum processing size is a real constraint, not a marketing number. If your part is longer, the quote is fiction.

Material range is another signal. A supplier that stocks 6061, 7075, 17-4PH, Ti-6Al-4V and Inconel has a supply chain built for engineering work. One that quotes anything but buys per order will add material lead time to your schedule.

Finally, check the confidentiality terms. Unreleased drawings should move under an NDA, with secure uploads and access control. ISO 27001:2022 is the certificate that backs this up. If a supplier hesitates on an NDA for a prototype, that tells you how they handle production files later.

• 1
  Count the 5-axis centersCapacity determines whether the lead time survives a busy month.
• 2
  Check travel against your partA 4,000 mm envelope is a hard limit.
• 3
  Confirm NDA before uploadSecure handling should be standard, not a favor.
