Most turning quotes look alike on the first page. The difference sits in the details: which machine runs the part, how the tolerance is called out, and what happens to the part after it leaves the spindle. Two suppliers can quote the same drawing at 30% apart and both be honest, because they plan different routes.

Start with the tolerance callout. A diameter of Ø25 mm with a general tolerance of ±0.1 mm can run on any 2-axis lathe. The same diameter at ±0.005 mm needs a machine in good condition, a stable material, and a temperature-controlled floor for long runs. On a part with an L/D ratio above 8, deflection at mid-length pushes the achievable tolerance wider even on a good lathe.

Then look at the second operation. A turned part with cross-drilled holes, milled flats or slots needs live tooling. If the shop has no live tooling, the part goes to a mill, gets a second setup, and picks up positional error. That is not a defect, but it belongs in the price and in the lead time.

Finally, ask what is measured and how. A first article report on the critical diameter costs the shop an hour. A full CMM report with a layout drawing costs more. Neither is free, and neither should be missing on a part that has to fit an assembly.

• 1
  Tolerance callout drives machine choiceGeneral ±0.1 mm and tight ±0.005 mm are different production plans.
• 2
  Live tooling removes the second setupCross holes and flats on the lathe keep position error low.
• 3
  Length-to-diameter ratio sets the limitAbove 8:1, plan for a steady rest or accept a wider band.
• 4
  Reports are a line itemFirst article, CMM layout and material certs are separate from the part price.

Aluminium 6061 and 6082 turn fast and hold a good finish. With sharp tooling and the right feed, Ra 0.8–1.6 μm comes off the machine without a polishing step. Brass C36000 is the easiest of all: free machining, good chip control, and threads that gauge cleanly on the first pass.

Stainless 303 behaves well on a lathe, which is why it is the default for turned fittings. Grades 304 and 316 work too, but they work-harden. A light cut with a dull insert hardens the surface and the next pass cuts worse. On 316L, keep the depth of cut above the work-hardened layer and use coolant at pressure.

Titanium TC4 (Ti-6Al-4V) and Inconel turn slowly. Tool life is short and heat stays in the cutting zone, so feeds and speeds drop and cycle time rises. If the drawing allows it, a 17-4PH part in the H1025 condition is cheaper to turn than the same part in Inconel, and it often meets the strength callout.

Plastics need their own approach. POM and PA turn cleanly with sharp tooling and air blast. PEEK is abrasive and expensive, so a scrapped part hurts more. ABS and PC are soft enough that chuck pressure alone can mark the OD, so use soft jaws or a collet.

• 1
  6061, 6082, C36000Fast cycle, good finish, predictable threads.
• 2
  303, 304, 316LWork-hardening control is the whole game.
• 3
  TC4, InconelShort tool life, long cycle, higher part cost.
• 4
  POM, PEEK, PCSharp tooling and low chuck pressure to avoid marks.

A turned part is rarely finished when it leaves the spindle. Threads are rolled or cut, bores are honed, flats are milled, and the surface may need anodizing or plating. Each step adds a setup, a fixture, or an outside vendor, and each one can move the tolerance stack.

Threads deserve a note. Cut threads on a lathe are fine for most fittings, but rolled threads have a stronger grain flow and a smoother root. For a high-cycle fastener, rolled is the better call. For a one-off adapter, cut threads are cheaper and just as functional.

Surface finish is specified as a number, not a feeling. Ra 3.2 μm is a normal as-machined finish and needs no extra work. Ra 0.8–1.6 μm usually comes off a good lathe with a finishing pass. Ra 0.2–0.8 μm takes a separate operation, and the part should be priced that way.

Coating and anodizing change dimensions. Hardcoat anodizing builds roughly half the coating thickness per surface, so a bore that gauges at the low limit before coating may not fit after. Call out pre-plate dimensions on the drawing and let the shop plan the allowance.

• 1
  Threads: cut or rolledRolled roots resist fatigue; cut threads are cheaper for one-offs.
• 2
  Finish as a numberRa 3.2, 1.6 and 0.8 μm sit in different cost brackets.
• 3
  Coating grows the partHardcoat and plating need a pre-finish dimension callout.
• 4
  Every extra feature adds a setupGroup features so one setup can reach them.

Machine list is the first filter. A shop with only 2-axis lathes will struggle with a part that needs cross holes and a tight true position. A shop with Swiss-type lathes can hold ±0.005 mm on small, long parts that a standard lathe cannot touch. Ask which machine will run your part, not which machines the shop owns.

Inspection is the second filter. A certificate on the wall says the system was audited. A CMM report on your part says the parts are correct. Ask for the report on the first article and on a sample from the run. If the shop cannot produce a report for a tight diameter, the tolerance claim is a hope, not a plan.

Certifications matter by industry. ISO 9001:2015 covers general quality. IATF 16949:2016 applies to automotive and EV work. ISO 13485:2016 is the medical device standard, and ISO 27001:2022 covers information security, which matters when drawings are confidential.

Capacity and lead time close the picture. Thirty 2-axis lathes on the floor support volume, but a single tight-tolerance part may need one specific machine. Ask for the machine and the week, not a general delivery promise.

• 1
  Machine list, not machine countMatch the machine to the feature, not the brochure.
• 2
  Report on your partFirst article plus a sample from the run.
• 3
  Certification by industryISO 9001, IATF 16949, ISO 13485, ISO 27001.
• 4
  Named machine and weekSpecific capacity beats a general delivery claim.
