A cnc machining service for medical devices will quote ±0.005 mm, and most shops on your list will say they can hold it. The useful question is narrower. Ask which machine and which setup hold that tolerance on the specific feature you care about, whether it is a bone screw thread root, a lens bore, or a sealing face on a diagnostic housing.

Geometry decides the answer. A deep bore, a thin wall under 1 mm, or a feature on the far side of a 300 mm part behaves differently from a simple pocket. A shop running 16 simultaneous 5-axis machining centers and 16 mill-turn centers can often finish a complex part in one setup, which removes the re-fixturing error that eats tolerance on a 3-axis route.

Surface finish is part of the same conversation. Ra 0.8–1.6 μm covers most instrument bodies and non-implant hardware. Sealing faces, sliding bores, and fluid paths may need Ra 0.2–0.8 μm, which usually means a finishing pass or a separate polishing step. Get that written into the quote rather than discovered at first article.

• 1
  Ask for the setup countFewer setups means fewer datum shifts and less stack-up error.
• 2
  Name the critical featureTolerance on a drawing edge is not the same as tolerance on a functional surface.
• 3
  Separate as-machined from finishedRa 1.6–3.2 μm as-machined is fine for brackets, not for seal seats.

ISO 13485:2016 is the certificate most medical buyers look for, and it is a fair filter. A certificate alone does not tell you much. What matters is the scope statement: does it cover the machining processes you are buying, the finishing steps, and the inspection activity? If your part is anodized or passivated at a subcontractor outside that scope, you have added an uncontrolled step.

The same logic applies to the rest of the quality system. ISO 9001:2015 covers general quality management. IATF 16949:2016 is automotive-oriented but signals process discipline on high-volume runs. ISO 27001:2022 covers information security, which matters when you upload patient-adjacent CAD data and want it handled under a defined control set.

Ask for a copy of the certificate with the scope page, not just the logo. Then ask which of your process steps sit inside it and which are outsourced. A supplier that answers that question in one email is usually the one that has been through a real audit.

• 1
  Scope, not logoThe scope statement is the part that protects you.
• 2
  Watch the finishing stepAnodizing, plating, and passivation are common out-of-scope gaps.
• 3
  Data handling countsISO 27001:2022 is a reasonable signal for CAD confidentiality.

Medical parts live and die on material documentation. You want mill certificates tied to the heat number, and that heat number should appear on the inspection report for the parts made from it. If the shop cannot link the two, the paperwork is decorative.

Common alloys for this work include 316L and 17-4PH stainless for corrosion resistance and strength, Ti-6Al-4V (TC4) for implant-adjacent tooling and lightweight instruments, and 6061-T6 or 7075 aluminium for housings and fixtures. PEEK and POM show up for insulators, seals, and low-friction components. Each has its own cutting behavior, so the shop should be able to say which tools and feeds it uses.

Beryllium copper and some magnesium alloys need extra controls on chips and dust. If your part uses either, ask how the shop handles swarf and operator exposure. A blank answer is a real risk, not a paperwork problem.

• 1
  Heat number on the reportMill cert plus inspection report, linked.
• 2
  Match alloy to function316L for corrosion, 17-4PH for strength, Ti-6Al-4V for weight.
• 3
  Flag reactive or toxic alloysBeryllium copper and magnesium need a stated handling plan.

Lead time is where quotes quietly diverge. Split it into two numbers. The first is how long until you get a quotation and a DFM review. The second is how long until chips actually fly. A shop that quotes in 12 hours and starts production within 24 hours is telling you something about its scheduling, and it is worth verifying on a real job.

For production runs, ask what the historical late-delivery rate has been. A figure below 2% is a reasonable benchmark to ask about. Do not accept a promise; ask for the tracking method. Shops that measure on-time delivery usually have a system behind the number.

Prototype timing is a different animal. Parts that ship in 3–5 days are common for straightforward geometry on a 5-axis route. Parts needing custom fixturing, exotic alloy stock, or a finishing step will take longer. Get the shipping step listed separately so you can see where the days go.

• 1
  Two clocksQuote turnaround and production start are not the same number.
• 2
  Ask for the tracking methodA late-delivery percentage without a system is a guess.
• 3
  Separate shipping from finishingOutsourced steps add days that never show in a machining estimate.

Minimum order quantity decides how cheap your learning curve is. A shop with no MOQ lets you run one prototype, break it, revise the design, and run again without a penalty. The same shop should be able to scale to a 10,000+ part run on the same process route, because that is what keeps your first-article data valid.

Finishing is the step most often underestimated. Anodizing in clear, color, hardcoat, or conductive types changes dimensions slightly. Electroless nickel, zinc, silver, and gold plating each have their own thickness tolerances. Bead blasting, tumbling, brushing, and polishing change surface texture and can round edges. Laser marking has a minimum character height of 1.5 mm, so plan your UDI or lot code layout around that.

Inspection is the last gate. Ask for 100% inspection before shipment, with raw material checks, in-process monitoring, and a final report. Reports on request is a normal arrangement. The point is to know before you ask whether the data exists.

• 1
  No MOQ helps iterationOne prototype to a 10,000+ run on one route.
• 2
  Finishing moves dimensionsPlating and anodizing add or remove microns.
• 3
  Laser marking has a floorMinimum character height 1.5 mm for readable marks.
