Every supplier page claims precision. The useful question is which machine holds the tolerance and how the shop proves it. A ±0.005 mm callout on a 300 mm aluminum bracket is routine for a simultaneous 5-axis center. The same callout on a deep pocket with a 3 mm tool is not. Ask for the machine class and the inspection method in the same answer.

Surface finish runs on the same logic. As-machined surfaces sit around Ra 1.6–3.2 μm. Fine finishes reach Ra 0.2–0.8 μm and usually need a separate operation, slower feed rates, or a finishing pass on a dedicated tool. If a quote lists Ra 0.4 μm at the as-machined price, the number is decorative.

Material changes the picture too. 6061-T6 cuts clean and holds tight tolerances when the fixture is rigid. Inconel and Ti-6Al-4V move under cutting heat, so the shop needs to plan roughing and finishing passes with a stress-relief window. A supplier who quotes titanium at the same price as aluminum has not machined much titanium.

So the first check is simple. Ask which machine will run the part, what tolerance it holds on that geometry, and how they measure it. A shop that answers with a machine class and a CMM is worth a second conversation.

• 1
  ±0.005 mmAchievable on 5-axis centers with rigid fixturing and in-process checks.
• 2
  Ra 0.8–1.6 μmA common high-finish band for sealing faces and sliding surfaces.
• 3
  Ra 0.2–0.8 μmFine finish, normally a second operation, not a default.

Size decides which supplier can even quote. A 4,000 mm frame needs a machine with a 4,000 × 400 × 150 mm travel envelope. Most job shops top out well below that and will quietly split the part or send it out. Splitting a part adds a joint, a fixture, and a second alignment error.

The middle band is where most work lives. Travels of 750 × 1,150 × 550 mm and 600 × 600 × 600 mm cover pump housings, brackets, and manifolds. Compact travels of 500 × 500 × 450 mm and 500 × 310 × 200 mm fit smaller sensor bodies and connector plates. A Ø400 mm rotary table adds 4-axis indexing when the part has features on several faces.

One setup matters more than the size itself. A part machined in a single 5-axis setup keeps its datum. The same part run across three machines accumulates alignment error at each move, and the last operation usually reveals it.

Before you send the file, check the diagonal of the part envelope, not just the longest side. Shops quote on the longest dimension and then discover the part will not clear the enclosure.

A minimum order quantity is a business model, not a technical limit. A shop with no MOQ can quote one prototype and the same part at 10,000+ pieces without changing the process plan. A shop with a 5,000-piece floor is telling you it only wants production programs, and your prototype will sit in a queue.

Ask how the price steps between quantities. The interesting numbers are at 1, 50, and 1,000 pieces. At low volume, setup and programming dominate the cost. At high volume, cycle time and material yield dominate. If the unit price barely moves between 100 and 1,000 pieces, the shop is not re-planning the process for volume.

Prototype quantities carry a different risk. When you order 3 parts, you are also buying information. A supplier who flags a feature that will not hold tolerance at volume is more useful than one who simply ships the parts.

Watch for the reverse trap as well. A quote that drops sharply at 10,000 pieces but shows the same cycle time as the 100-piece quote is probably a guess. Volume pricing should come from a change in method, not a change in mood.

Lead time is three separate clocks: quoting, production start, and shipping. A supplier who quotes in 12 hours and can start production within 24 hours removes most of the waiting. Parts that ship in 3–5 days are normal for well-planned small runs, but only when material is in stock and the finishing line is not booked out.

The breaks happen at handoffs. If the shop machines in house and sends parts to a third party for anodizing, the finishing queue is invisible to you. In-house anodizing, plating, powder coating, bead blasting, and laser marking keep the schedule under one roof.

Material is the other hidden delay. Standard grades like 6061, 304, and 1018 usually sit in stock. Inconel, beryllium copper, and PEEK often do not. Ask whether the quoted lead time includes procurement or assumes the bar is already on the floor.

A useful check: ask what happens if the first article fails inspection. A shop that re-machines without a new purchase order has buffer in its schedule. One that goes quiet does not.

• 1
  QuotationFree DFM analysis within 12 hours is a fair baseline.
• 2
  Production startWithin 24 hours when material is in stock.
• 3
  Shipping3–5 days for small runs is typical.

Certificates are only useful when the auditor on the other side recognizes them. Automotive programs look for IATF 16949:2016. Medical device work looks for ISO 13485:2016. A general quality system such as ISO 9001:2015 covers the shop floor but will not satisfy a customer audit in those two industries.

Two more matter in practice. ISO 27001:2022 covers information security, which is what your legal team will ask about before sending CAD files. An ISO 13485 shop also tends to keep traceability records by lot, which helps if a field failure ever needs investigation.

Read the scope on the certificate, not just the logo. A certificate can cover a trading office while the machining happens elsewhere. If the scope statement does not name the machining and finishing site, the document does not tell you much.

Certifications also expire. A quick date check on the certificate saves a procurement headache later, especially for programs that run across several years.

Inspection is where a cheap quote usually hides its cost. 100% inspection before shipment, with raw material checks, in-process monitoring, and a final pass, is the standard you want on functional parts. Reports should be available on request rather than priced as an extra.

Finishing is a separate engineering decision. Anodizing comes in clear, color, hardcoat, and conductive types, and each changes the surface in a different way. Hardcoat adds wear resistance but can shift a tight bore. Conductive anodizing is a different bath entirely. Plating options include electroless nickel, zinc, silver, and gold, plus powder coating and black oxide.

Laser marking needs its own check. Minimum character height is 1.5 mm in most setups. If your part number does not fit at that height, the marking will smear or drop out, and you will find out after the parts are finished.

The practical question is who owns the finishing step. In-house finishing keeps the tolerance stack and the schedule in one place. Outsourced finishing adds a transport step and a second quality system between you and the finished part.

A quote that only lists a price is hard to audit. The useful version states the material grade, the machine class, the tolerance band, the finish, the inspection plan, and the lead time. If a supplier cannot name the material grade in the quote, they may not have checked stock either.

Send a drawing with a deliberate hard feature and see what comes back. A shop that returns a DFM note about tool access, thin walls, or a tolerance that will not hold is doing engineering work. A shop that returns only a number is passing your file to a machine operator and hoping.

Confidentiality belongs in the same conversation. Secure uploads and an NDA available on request are standard for programs with proprietary geometry. Ask before you send the file, not after a design leak.

Finally, check the contact path. You want a named engineer or a direct messaging channel, not a generic sales inbox. The person who answers your pre-sale question is usually the person who handles your change order.

• 1
  Quote must listMaterial grade, machine class, tolerance, finish, inspection, lead time.
• 2
  DFM feedbackA real note on manufacturability, not just a price.
• 3
  NDA on requestSigned before files move, not after.
