A slot is a channel cut into a solid body. On a 3-axis mill the tool spins on a vertical axis and travels along the slot path, so the bottom of the slot is flat and the two walls are parallel. The cutter diameter sets the slot width. If you need a 6 mm slot, you normally use a 6 mm end mill and take it in one pass, or a smaller cutter and walk it around the profile.

The second method is common on wider slots, above roughly 12 mm, where a full-width cutter would need too much spindle torque. Here the tool follows a trochoidal or zig-zag path and clears the slot in layers. It removes material faster on soft aluminium, but leaves a visible step on the wall unless the finishing pass is light. A 0.2 mm radial finishing pass at higher spindle speed cleans that up.

Depth is where the trouble starts. Every end mill bends under cutting force. A 6 mm carbide cutter with 30 mm of stick-out can deflect 0.02 mm or more in a deep slot, and that deflection shows up as a tapered wall: narrow at the top, wider at the bottom, or the reverse depending on direction. That is why depth-to-width ratio, not slot length, is the number to watch.

• 1
  Slot width = cutter diameterFor widths under 12 mm, a full-width end mill keeps the wall parallel and the floor flat.
• 2
  Wide slots need a pathAbove about 12 mm, clear with a smaller tool and finish with a light radial pass.
• 3
  Deflection scales with stick-outKeep tool overhang under 4× diameter when the slot is deeper than 3× width.

For a standard carbide end mill in aluminium, a slot up to 3× the cutter diameter deep is routine. At 5× you are still machining, but expect to slow the feed and accept more cutter wear. Past 8× the tool becomes a boring bar with flutes, and chip evacuation is the real problem: chips pack into the bottom of the slot and get recut, which heats the edge and dulls it fast.

Harder materials shift those numbers down. In 316 stainless or Ti-6Al-4V, a slot at 4× diameter is already a careful job. The material work-hardens if the cutter rubs instead of cuts, so feeds must stay high enough to bite. We usually run stainless slots with air blast or high-pressure coolant and take multiple depth passes of 0.3–0.5× diameter rather than one deep cut.

There are workarounds. A lollipop cutter reaches under a shoulder and cuts a T-slot or dovetail in one setup. A slitting saw cuts a narrow, deep slot faster than an end mill but only in a straight line. Wire EDM cuts a 0.2 mm slot through 50 mm of hardened steel with no cutter force at all, at the cost of speed and a conductive workpiece.

• 1
  Aluminium: up to 5× diameterRoutine to about 3×; slow the feed above that and clear chips aggressively.
• 2
  Stainless and titanium: 3–4× diameterTake 0.3–0.5× diameter depth passes and keep the edge cutting, not rubbing.
• 3
  Past 8× diameter, change processUse a slitting saw, lollipop cutter, or wire EDM instead of a long end mill.

On a rigid setup in aluminium, a slot width can hold ±0.005 mm and a wall can hold ±0.01 mm. That is the tight end and it assumes a short cutter, a stable fixture, and a finishing pass that removes only 0.1–0.2 mm. Push the tool deeper and the tolerance loosens on its own, because deflection changes with depth of cut.

Position matters as much as size. The centerline of a slot can be located to ±0.01 mm on a machine with a good ballscrew and thermal stability. Slot-to-slot spacing on a bolt pattern is usually held to ±0.02 mm across a 300 mm part, since thermal growth over that distance eats into the budget. We verify with a CMM or optical comparator and can supply the report on request.

Surface finish inside a slot is harder to control than on an outside face. Chips drag along the wall, and a dull cutter leaves a smeared band near the bottom. For a sealing groove that needs Ra 0.8–1.6 μm, we use a fresh coated end mill, climb milling, and a light finishing pass. Ra 0.2–0.8 μm is possible on aluminium with a finishing pass and a polished cutter, but it costs cycle time.

• 1
  Width: ±0.005 mm achievableShort cutter, rigid fixture, light finishing pass in aluminium.
• 2
  Position: ±0.01 mm typicalSpacing across long parts widens to about ±0.02 mm from thermal drift.
• 3
  Finish: Ra 0.8–1.6 μm standardRa 0.2–0.8 μm on aluminium adds cycle time and tool cost.

A slot with a radiused bottom and rounded corners is easy. The cutter plunges, follows the path, and lifts. A slot with sharp internal corners is not, because the corner radius equals the cutter radius. If your drawing calls for a 0.5 mm corner in a 10 mm slot, no end mill can leave it, and you either accept the radius or add a second operation.

Blind slots need a way in. A slot that stops inside the part leaves a scallop where the cutter ramps down and lifts. We can reduce that with a ramped entry and a smaller cutter, but the floor will not be perfectly flat at the end wall. If the end wall is a locating face, tell us and we will approach it from a different direction.

Thin walls are the other trap. A 1 mm wall between two slots will chatter and can bend under cutting force. A rule of thumb: keep the wall at least 0.5× the slot depth, or add a supporting rib. On parts we quote, we flag wall thickness under 1.5 mm in the DFM notes before cutting starts.

• 1
  Corner radius = cutter radiusDesign the smallest internal radius you can accept, not the sharpest one you want.
• 2
  Blind-slot end wallsExpect a small scallop unless the wall is machined from a separate direction.
• 3
  Thin walls chatterKeep the wall at least half the slot depth, or add a rib.

Milling wins for slots in small and medium parts, in most metals and plastics, at tight tolerance. It loses when the slot is very narrow and very deep, when the material is hardened above about 45 HRC, or when the part is a thin sheet where cutter force would bend it. In those cases, wire EDM or laser cutting does the job with no mechanical force on the part.

Laser cutting is fast and cheap for through-slots in sheet, but it leaves a heat-affected zone and a taper of roughly 0.05–0.1 mm on thicker plate. It also cannot hold a tight width tolerance in 10 mm steel. Waterjet cuts thick material with no heat, but the kerf tapers and the edge is rough. Both are 2D processes; neither will cut a blind slot or a slot with a stepped floor.

Broaching and shaping cut a keyway or internal slot in one stroke and are unbeatable for a straight, deep slot in a bore. They need a dedicated tool and a high volume to justify it. For one prototype and ten production parts, milling is almost always the faster route, even if the cycle time per part is longer.

• 1
  Milling: best for width and toleranceMost metals and plastics, blind or through, tight limits.
• 2
  Wire EDM: narrow and deepNo cutter force, hardened steel OK, slow and needs a conductive part.
• 3
  Laser and waterjet: 2D onlyFast for sheet, but taper and heat-affected zone limit precision.
