Most parts do not need five axes. A flat bracket with holes on one face is cheaper on a 3-axis mill, and that is the honest answer. The review gets interesting when a part has features on four or five faces, deep pockets at an angle, or a bore that must stay concentric with a face machined later.

On a 3-axis machine each new face is a new setup. Every setup adds a work offset, a clamping decision and a stack-up of positioning error. Five-axis work holds the part once and rotates it under the spindle, so the relationship between features comes from the machine geometry, not from how well an operator re-zeroed the vise.

At GreatLight the five-axis group is 16 simultaneous 5-axis machining centers, alongside 12 four-axis mills and 27 three-axis machines. That mix matters. A shop that quotes everything as five-axis is overcharging you, and a shop that has no five-axis will quietly add setups and fixtures to your quote.

Ask what a supplier would do differently if you removed the angled feature. If the answer is a shorter setup list and a lower price, they are choosing the process, not selling the machine.

• 1
  Use 5-axis whenAngled holes, contoured pockets, features on 4–5 faces, or tight true position between faces.
• 2
  Stay on 3-axis whenOne dominant face, prismatic geometry, loose position tolerance, high volume.
• 3
  Watch forQuotes that list extra setups with no explanation of what feature caused them.

±0.005 mm is a real number on a machined bore in aluminium. It is a different problem on a 1,200 mm steel weldment, where thermal drift and workholding deflection eat the budget before the cutter touches metal. A useful review separates the tolerance a shop can hold on a 100 mm part from the one it can hold on a 4,000 mm part.

Surface finish is usually underspecified. Ra 0.8–1.6 μm covers most functional faces. Sealing surfaces and sliding fits often need Ra 0.2–0.8 μm, which means a finishing pass, a sharper tool and slower feed. If your drawing says Ra 0.4 μm on a 300 mm deep pocket, expect a cost conversation, not a silent pass.

Measurement matters as much as the target. A tolerance is only proven with a method: CMM, bore gauge, micrometer, optical comparator. Ask which instrument is used, how often it is calibrated, and whether the report ships with the parts.

One practical test: pick the feature you care about most and ask how it is fixtured. If the answer is vague, the tolerance is a wish.

• 1
  Define the datumTight tolerances belong on the surfaces that locate the part, not on every edge.
• 2
  Finish by functionSeals and bearings need fine Ra. Brackets do not.
• 3
  Ask for the methodCMM report, gauge type, calibration interval.

A machine shop that only cuts aluminium will quote stainless steel anyway, then subcontract the anodizing and lose a week. The review question is simple: what is done in-house and what is sent out? Each handoff adds queue time and a chance for damage or mixed-up parts.

GreatLight machines aluminium grades 6061, 7075, 2024 and ADC12; stainless 303, 304, 316L, 17-4PH; steels including 1045, 4140 and 4340; copper and brass; titanium TC4 and Inconel. In-house finishing covers anodizing, plating, powder coating, black oxide, bead blasting and laser marking.

Laser marking has a practical limit: minimum character height 1.5 mm. If your part number is a 0.8 mm line of text on a small housing, the mark will not read cleanly, and you should move it to a label or a larger face.

Ask for a material certificate with the first article. It costs the supplier a few minutes and tells you whether the mill stock was traced.

• 1
  In-house finishingShorter queue, fewer handling steps, one point of contact for defects.
• 2
  Subcontracted workAsk who does it and how transit damage is covered.
• 3
  Marking limitsMinimum character height 1.5 mm for laser marking.

Minimum order quantity is a filter for who a shop wants as a customer. A 1,000 piece minimum tells you prototypes are a nuisance there. No minimum order quantity means one part and a 10,000+ part run are both normal work, which is what most product teams actually need across a development cycle.

Quoting speed is a proxy for internal process. A shop that returns a quote and a free DFM analysis within 12 hours has already read your model and thought about fixturing. One that returns a number in three days is often guessing.

Lead time should be broken into pieces: quote and DFM in 12 hours, production start within 24 hours, parts ship in 3–5 days. Ask what starts each clock. It is usually a purchase order, a confirmed drawing revision, or a material arrival.

Be careful with a shop that promises everything fast and cheap at once. Speed comes from scheduling discipline and available capacity, not from optimism.

• 1
  No MOQOne prototype to 10,000+ parts on the same process.
• 2
  12-hour quoteIncludes a free DFM analysis, not just a price.
• 3
  3–5 day shippingAsk whether that is machining time or total time.

Certificates are a starting point, not a quality guarantee. ISO 9001:2015, IATF 16949:2016, ISO 13485:2016 and ISO 27001:2022 each answer a different question. IATF 16949 fits automotive and EV programs. ISO 13485 fits medical devices. ISO 27001 covers how your files and data are protected.

The daily behavior matters more. Raw material check on arrival, in-process monitoring during the run, final inspection before shipment. Reports on request. If a shop inspects only the first article and the last one, a mid-run drift in a long cycle can ship unnoticed.

With no minimum order quantity, a prototype and a production run go through the same inspection route. That consistency is what makes a first article meaningful.

Ask for the last two inspection reports on a similar part. Not a sample from a brochure. The real ones show how the shop measures and what it does when a dimension drifts.

• 1
  Match the cert to the industryIATF for automotive, ISO 13485 for medical, ISO 27001 for file security.
• 2
  Inspection coverageRaw material, in-process, final, 100% before shipment.
• 3
  Reports on requestDimensional data, material certs, finish verification.

The first trap is comparing unit price on different assumptions. One quote includes material certificates and anodizing, another does not. Normalize the scope before you compare numbers, or you will pick the cheaper-looking quote and pay later in rework.

The second trap is treating a prototype quote as a production quote. Tooling, fixtures and inspection plans that made sense for five parts rarely survive a 5,000 part run without change. Ask how the process changes at volume.

The third trap is silence about DFM. If nobody has flagged a thin wall, a deep pocket with a tight corner radius, or a tolerance that cannot be measured, the feedback loop is missing. A free DFM analysis within 12 hours is the cheapest engineering review you will get.

The fourth trap is file handling. Design files move between email, cloud drives and machine controllers. Ask how uploads are stored and whether an NDA is available before you send the model.

• 1
  Normalize scopeSame material, finish, inspection and packaging across every quote.
• 2
  Re-quote at volumePrototype process and production process are not the same.
• 3
  Demand DFM feedbackIf no one questions the drawing, no one has read it closely.
