Cut metal and the chip shears. Cut plastic and the chip often bends first. Thermoplastics lose stiffness fast as tool temperature climbs, so the material at the cutting edge yields instead of fracturing. What stays behind is a thin flap of deformed polymer attached to the part edge. That flap is the burr.

The flap is not uniform. On one pass you get a soft rollover that wipes off with a fingernail. On the next you get a hard, glossy lip welded to the edge. Feed, spindle speed, tool sharpness and the glass or carbon filler content all shift which one you get. The same cutter in the same holder behaves differently in ABS and in 30% glass-filled PA.

This is why deburring CNC plastics cannot be treated as a fixed line item at the end of a router program. It is a consequence of the cut. A shop that only inspects edges after machining is inspecting the symptom, not the cause.

One more boundary matters. Plastics are poor heat conductors. Heat generated at the edge has nowhere to go, so it concentrates within a millimeter of the cut. A dull tool raises local temperature, softens the polymer further, and the burr grows. The feedback is fast.

• 1
  Softening temperatureThe closer the edge gets to it, the more the chip folds instead of breaking.
• 2
  Filler contentGlass and carbon fibers make the burr brittle but abrasive, and they dull tools faster.
• 3
  MoistureNylon and PEEK absorb water, which changes how the edge behaves on the same program.

POM and PMMA sit at the easy end. Both have a narrow softening window relative to their stiffness, so the chip breaks rather than stretches. A sharp two-flute cutter at 8,000–12,000 rpm and 0.05–0.1 mm per tooth usually leaves an edge that needs only a light pass with a ceramic fiber stick.

ABS and PC sit in the middle. They are tough and slightly ductile, so they produce a small, consistent rollover on the exit side of the cut. This is manageable with a controlled chamfer, but it will not disappear on its own. A 0.2 mm break edge is often enough for a mating face.

PP, HDPE and PEEK are the difficult group. They are soft or highly ductile at cutting temperature, and the chip tends to smear along the edge rather than leave. PEEK adds a second problem: it is expensive, so scrap from over-aggressive deburring hurts. On these materials the burr is best controlled at the source, with carbide tooling, sharp geometry and generous coolant or air blast.

Carbon fiber and glass-filled grades behave differently again. The polymer matrix folds, but the fibers stay stiff. The result is a fuzzy, abrasive edge that dulls hand tools quickly. Use diamond-coated cutters and expect a shorter tool life than on unfilled resin.

• 1
  Clean cuttingPOM, PMMA, and most filled grades when tools are fresh.
• 2
  Moderate burrABS, PC, PA. A defined break edge covers most cases.
• 3
  Smearing riskPP, HDPE, PEEK. Control at the cut, not after it.

Manual deburring with a ceramic fiber stick or a deburring blade is still the most common method for prototypes and low volumes. It gives the operator direct feel for how much material is coming off. The trade-off is repeatability. Two operators will not produce the same edge on the same part, and on a 500-piece run that shows up in inspection.

Mechanical tumbling and vibratory finishing suit parts with no fragile features. The media erodes the edge uniformly, which is exactly what you want for a deburring CNC plastics line running the same geometry repeatedly. The limit is geometry: deep pockets, thin walls and internal bores of small diameter may not see enough media action, or may see too much.

Thermal deburring, where a controlled gas mixture burns the burr off in a chamber, works on some thermoplastics but is risky. The process relies on the burr having a high surface-to-volume ratio so it oxidizes before the bulk part does. For heat-sensitive grades like PEEK or thin-walled PC, the margin is narrow.

For most production work, the effective answer is a combination. A controlled chamfer on the CNC, followed by light media finishing or a hand pass on critical edges. That keeps the burr small at the source and makes the finishing step predictable.

• 1
  Hand toolsBest for prototypes, one-off geometry and touch-up after inspection.
• 2
  TumblingBest for high volume and simple external geometry.
• 3
  CNC chamferBest when the edge is a functional sealing or mating face.

The first question is what the edge does. A cosmetic edge on an enclosure panel and a sealing edge on a fluid manifold are not the same requirement, and treating them the same either wastes money or creates a leak. Write the function down before you write the tolerance.

The second question is whether the burr is loose or attached. A loose flap will break off in service and end up somewhere it should not be, inside a valve or a bearing race. An attached rollover is a dimensional issue but not a contamination one. These need different acceptance criteria.

The third question is measurement. A visual standard is fine for cosmetic parts. For functional edges, a 0.1–0.3 mm break edge can be checked with a radius gauge or an optical comparator. If you cannot measure it, you cannot hold it across a production run.

Finally, consider the inspection cost. If a deburring CNC plastics step requires 100% visual inspection with a magnifier, that cost sits in the part price. Designing the edge so it can be checked with a go/no-go gauge keeps the process affordable at volume.

• 1
  Function firstCosmetic, sealing, sliding or safety edge. Each has a different limit.
• 2
  Loose vs attachedLoose flaps are a contamination risk, not just a finish issue.
• 3
  Measurable calloutA number in millimeters beats a note that says 'deburr all edges'.
