A CNC controller executes G-code: a list of coordinates, feed rates, spindle speeds, and tool changes. SVG stores none of that. It stores shapes as mathematical paths — move, line, curve, close. Vector data, yes. Machine motion, no. The controller needs to know where the tool goes, how fast, and how deep. SVG says none of it.

So do CNC machines use SVG files? Not natively. Something has to translate the path into motion. That translator is CAM software, and the translation step is where most SVG headaches start. A path that looks perfect on screen can produce a toolpath that cuts air, doubles back, or dives deeper than expected.

The gap is dimensional. SVG lives on a flat plane with X and Y. Milling and turning need a third axis, and often a fourth or fifth. An SVG can describe a pocket outline, but it cannot tell you the floor depth, the corner radius in Z, or whether the feature is a through slot or a 3 mm engraving.

None of this makes SVG useless. It makes SVG a front-end format. Design in SVG, then let CAM assign the machining data. The file you send a shop is usually the output of that step, not the SVG itself.

CAM software parses the SVG path data and rebuilds it as a chain of line and arc segments. Cubic and quadratic Bézier curves get flattened into many short lines. Tighter flattening tolerance means smoother curves and a heavier program. A 0.01 mm chord tolerance is fine for most engraving. Loosen it to 0.1 mm and small radii start to look faceted.

Once the chain exists, CAM applies a toolpath strategy. For a 2D contour it offsets the path by the tool radius, then adds lead-in and lead-out moves. For pocketing it generates a series of stepovers. For engraving it runs the tool center straight down the path. Each strategy needs data the SVG never carried: tool diameter, stepover, depth per pass, feed rate, spindle speed.

Stroke width matters more than most people expect. CAM often treats the stroke centerline as the cut line, so a 0.5 mm stroke and a 5 mm stroke can produce the same toolpath. Many shops ask for hairline strokes — around 0.001 mm — so there is no ambiguity about intent. Filled shapes are a separate case; CAM may treat a fill as a pocket rather than an outline.

Curve count is the other quiet issue. A file with thousands of tiny splines will post a huge program and slow the controller on look-ahead. Simplifying nodes before export usually cuts cycle time without changing the part.

• 1
  Flattening tolerance0.01 mm for smooth curves; 0.1 mm is visible on small radii
• 2
  Hairline strokeAbout 0.001 mm so CAM reads the centerline, not the stroke edge
• 3
  Node countFewer nodes, smaller G-code, faster look-ahead on the controller

SVG shines on flat, 2D work where the outline is the part. Signs, plaques, engraved nameplates, panel cutouts, gaskets, stencils, and inlay pockets all fit. If the drawing is essentially a shape to be cut or marked on one face, SVG carries everything CAM needs except the machining parameters.

Laser cutting and waterjet are even better matches. Both are inherently 2D, both consume path geometry directly, and both care about kerf width more than Z depth. Router work on plywood, acrylic, or MDF follows the same logic. The toolpath is a contour or a pocket, and the SVG outline defines it cleanly.

Engraving is the sweet spot for metal parts. A logo or part number engraved on an aluminum housing starts life as a vector outline. CAM converts it to a shallow toolpath — typically 0.2 to 0.5 mm deep with a 30° or 60° V-bit or a 1 mm flat end mill. Vector data keeps the edges crisp at small sizes, which raster formats cannot do.

SVG is also handy for quick iteration. Designers can edit it in Inkscape or Illustrator, and a shop can re-post the toolpath in minutes. For one-off fixtures and shop aids, that loop is faster than a full CAD remodel.

Anything with depth needs more than SVG. A pocket with a specified floor, a counterbore, a stepped boss, a thread callout — none of that survives in a 2D path file. You can draw the top view, but the Z information has to come from somewhere else: a dimensioned drawing, a STEP model, or a written note.

Tolerances have no home in SVG either. There is no way to attach ±0.005 mm to a hole or a datum to a face. Shops work to a general tolerance by default, and a general tolerance is not the same as a specified one. If the feature is critical, the tolerance needs to live in a drawing or a 3D model.

Text is a recurring trap. SVG text elements depend on the font being installed on the reading system. If it is not, the text reflows or reverts to a default face. Convert all text to paths before export. The file gets slightly larger; the geometry stops moving.

Finally, SVG has no material or finish information. The same outline in 6061-T6 and in 316L stainless needs different speeds, feeds, and tooling. That data belongs in the quote request, not the vector file.

DXF is the usual alternative for 2D. It is older, less pretty, and better understood by CAM and CAD tools. Units are explicit, layers are conventional, and most shops have a DXF import that behaves predictably. If your part is flat and you want the fewest surprises, DXF is the safer default.

STEP is the answer for anything 3D. It carries solids, surfaces, and true geometry in X, Y, and Z. A STEP file lets CAM derive toolpaths directly from the model, which removes the reinterpretation step that SVG requires. For a milled bracket, a turned shaft, or a 5-axis housing, STEP is the format to send.

The practical rule: SVG for 2D marking and cutting, DXF for 2D parts that need clean CAD data, STEP for anything with depth or tolerance. Many shops will accept SVG for engraving and still ask for a STEP or PDF drawing as the controlling document.

Conversion is not lossless in either direction. SVG to DXF can drop curve fidelity if the exporter flattens aggressively. DXF to SVG can lose layer structure. Check the converted file in a viewer before sending it, and compare a few key dimensions against the original.
