The part looks like a small perforated cover. In practice it is an acoustic filter, an EMI shield, a structural bracket, and a cosmetic surface in one. The microphone sits behind it, so every hole is a trade: open area lets speech through, but open area also lets in dust and electromagnetic noise.

Acoustic transparency depends on open-area ratio and hole depth. A 0.6 mm hole through a 1.0 mm wall behaves differently from the same hole through a 0.4 mm wall. Deep, narrow holes add air resistance and roll off high frequencies, which hurts voice-command recognition.

Shielding depends on how the metal surrounds the microphone. In a vehicle the housing sits near motor cables, DC-DC converters, and switching electronics, so the metal path has to stay continuous. That is why a plastic mesh with a conductive coating is a different product from a solid metal one.

Then there is vibration. The housing mounts to a trim panel or a bracket, and road input travels through it. Thin mesh sections crack at the hole ligament. Thick sections add mass. The prototype is where you find the wall thickness that survives both.

Three numbers decide which process can make the part: hole diameter, wall thickness, and hole angle relative to the surface. Straight holes normal to a flat plate are easy. Holes on a curved shell, or holes drilled at 30° to the surface, split the field fast.

A common EV design uses Ø0.5–1.2 mm holes on a 1.5–3.0 mm pitch, with a wall 0.4–1.2 mm thick. The ligament between holes is often narrower than the hole itself. That thin web is where burrs form, where heat builds up, and where a part fails inspection.

Angled holes matter because the microphone often sits off-axis to the driver. A swept or angled perforation pattern improves pickup without moving the microphone. On a 3-axis mill this needs multiple setups and long reach tools. On a simultaneous 5-axis machine it is one continuous path.

Undercuts and internal steps are the other constraint. If the housing has a recessed cavity for the microphone module plus a mesh face on a curved outer skin, the tool has to reach both without chattering. That is a fixturing problem as much as a cutting problem.

Aluminum 6061-T6 is the default for a machined housing prototype. It machines fast, holds thin ligaments, and takes anodizing. If the housing needs shielding plus low weight, 6061 with a conductive or hardcoat anodize covers most cases.

Stainless 304 or 316L is the pick when corrosion resistance or stiffness matters more than mass. It cuts slower and burrs more at the hole exits, so plan for a deburring step. 17-4PH gives higher strength if the housing doubles as a structural bracket.

Copper and beryllium copper appear when shielding effectiveness is the primary requirement. They are heavier and more expensive to machine, so they are usually reserved for a small shield can rather than the whole housing.

Coatings change hole size. Anodizing builds 5–25 μm depending on type, and hardcoat builds more. Electroless nickel adds a thin, uniform layer and keeps the acoustic path stable. If your prototype must match a production anodized part, machine the holes slightly oversize.

Hole diameter is the first check, and it is not a single number. Measure entry, exit, and mid-wall. A drill or an end mill can produce a barrel-shaped hole in thin walls, and the exit side often measures larger than the entry.

Ligament width is the second check. Calipers are not enough on a 0.3 mm web. Use optical measurement or a vision system on a sample of holes across the panel. Ligament variation is what predicts fatigue cracking, not the average hole size.

Surface finish inside the holes affects acoustic resistance. A burr at the exit adds turbulence and noise. Ra 0.8–1.6 μm on the mesh face is a reasonable prototype target; Ra 0.2–0.8 μm is achievable where the acoustic path is critical.

Finally, confirm the mounting features. Hole patterns that do not line up with the module bracket will stall the build even if the mesh is perfect. Inspect the datums, not just the mesh.

Ask what machine will run the job. Thick, angled perforations on a curved shell are not a 3-axis job, and a supplier who quotes it as one will either miss the angle or add setups that raise cost.

Ask how they hold a thin mesh panel. If the answer is a vise and a prayer, expect chatter and broken ligaments. Good fixturing is often custom and part-specific.

Ask for the inspection method on ligament width. A shop with only calipers cannot verify a 0.3 mm web. Optical or vision measurement is the practical answer.

Ask about material traceability and certification. For automotive work, IATF 16949:2016 matters. We also hold ISO 9001:2015, ISO 13485:2016, and ISO 27001:2022 for information security.

If the production part will be stamped sheet metal, a machined prototype still validates the acoustic and shielding design, but it will not predict springback or stamping burrs. Be clear about what you are validating.

If the mesh is a true lattice with thousands of tiny struts, DMLS is usually cheaper than machining. Machining a lattice means many small tools and long cycle times. Use printing for the lattice, then machine the mounting interface.

If the housing is a large flat panel with no curvature, laser cutting plus forming may be faster and cheaper. Machining wins on 3D geometry, tight tolerances, and features that need to be in one piece.

And if the requirement is purely cosmetic at this stage, a printed or vacuum-cast part may be enough. Save the machined version for the fit-and-function build.
