A three-axis machine reaches a part from one direction. If the part has features on five faces, someone has to unclamp it, turn it and re-zero it four more times. Every re-clamp adds queue time, an operator hour and a chance of a datum error. That is where the calendar days go.

A simultaneous 5-axis center adds two rotary axes to the three linear ones. The tool can tilt and the table can rotate, so the part stays in one fixture while the tool reaches undercuts, deep cavities and angled holes. The cut itself may take a similar number of minutes. The five extra setups disappear.

For a buyer, this reframes the question. Instead of asking how fast a shop's spindle is, ask how many setups their process plan assumes. A shop that quotes five setups on a part you know is one-setup work is either quoting a three-axis route or padding the schedule. Both answers tell you something.

GreatLight runs 16 simultaneous 5-axis machining centers alongside 12 four-axis mills, 27 three-axis machines and 16 mill-turn centers. That mix matters at the quoting stage: a part only goes on a 5-axis machine when the geometry earns it.

• 1
  One-setup partsCurved surfaces, undercuts, angled ports, deep cavities with non-orthogonal walls.
• 2
  Multi-setup partsSimple prismatic blocks. Send those to a three-axis machine and save money.

Five-axis machining is not a quality upgrade you apply to every part. It is a geometry decision. If the part can be cut from three orthogonal directions with a couple of setups, a three-axis machine will usually be cheaper and just as accurate.

The geometry that pushes you to five axes is specific. Turbine blades and impellers have twisted aerofoil surfaces. Mold cavities have draft walls and deep ribs that a straight tool cannot reach. Orthopedic implants have organic contours and a surface finish requirement. Aerospace structural parts have pockets and bosses on non-orthogonal faces. Manifolds and hydraulic bodies have angled ports.

There is a second category that is less obvious: parts that are geometrically simple but need many operations. A housing with features on five faces may be easy to cut, but on a three-axis machine it becomes five setups, five datums and five inspection steps. Five-axis often wins on total lead time even when the cut itself is nothing special.

When five-axis is the wrong answer: flat plates, simple brackets, turned shafts with one cross-hole, and any part where a ±0.05 mm tolerance is acceptable and the budget is tight. Sending that work to a 5-axis center raises the hourly rate without shortening the route.

• 1
  Blades and impellersTwisted surfaces with a continuous tool path and no visible witness lines.
• 2
  Mold and die cavitiesDeep ribs, draft angles and radii that need a tilted tool to reach.
• 3
  Medical implants and instrumentsOrganic contours plus Ra 0.2–0.8 μm finishing on contact surfaces.
• 4
  Multi-face housingsFeatures on five sides, where setup count is the real cost driver.

A tolerance callout is a promise about the whole process, not just the machine. ±0.005 mm (±0.0002 in) requires a machine in good condition, a fixture that does not deflect, a temperature-stable shop and an inspection method capable of measuring the feature. Ask how the shop plans to verify the tightest dimension on your drawing.

Finish works the same way. Ra 0.8–1.6 μm is a normal machined finish on many alloys with a correct cutter and feed. Ra 0.2–0.8 μm usually means a separate finishing pass, sometimes a smaller step-over, and more cycle time. If a quote claims a fine finish at an as-machined price, check whether polishing is included or assumed.

Material changes the answer too. Aluminum 6061 and 7075 cut fast and hold tolerance well. 17-4PH stainless, Ti-6Al-4V and Inconel move under heat and wear tools faster, so a thin wall in titanium is a different schedule from the same wall in aluminum. Magnesium AZ31B and AZ91D cut easily but need chip handling discipline.

For reference, GreatLight holds ±0.005 mm, inspects 100% of parts before shipment, and reports a 99.99% qualification rate. Those numbers are useful only if the quote names the feature they apply to. A general tolerance note on a drawing is not the same as a controlled dimension on a critical bore.

• 1
  As-machinedRa 1.6–3.2 μm. Normal for brackets, plates and non-sealing faces.
• 2
  Fine machinedRa 0.8–1.6 μm. Sealing faces, bearing seats, sliding surfaces.
• 3
  Polished or lappedRa 0.2–0.8 μm. Contact surfaces on implants and optical housings.

Lead time splits into three parts: quoting, production start and shipping. A shop that quotes in 12 hours but cannot start for a week has not solved your problem. Ask for all three numbers. GreatLight gives a quotation and free DFM analysis within 12 hours, can start production within 24 hours, and ships parts in 3–5 days.

Historical performance is the honest number. Any shop can promise a date. Ask what fraction of past orders shipped late. GreatLight reports a historical late-delivery probability below 2%. That is a track record, not a guarantee, and it is more useful than a promised date.

MOQ filters out shops that do not want your prototype. If a supplier has a 100-piece minimum, your one-off bracket goes to the back of the queue behind production runs. No minimum order quantity means the same line handles one prototype and a 10,000+ part run, which is what most engineering teams need in the design phase.

Certifications answer audit questions, and each one covers a different scope. ISO 9001:2015 is the general quality baseline. IATF 16949:2016 is what automotive and EV programs ask for. ISO 13485:2016 covers medical devices. ISO 27001:2022 covers information security, which matters when you upload CAD files. Check the certificate scope, not just the logo on the homepage.

Confidentiality belongs in this filter too. Ask whether uploads are encrypted and whether an NDA is available before you send the model. GreatLight offers an NDA on request and treats all uploads as secure and confidential.

• 1
  Automotive and EVIATF 16949:2016, PPAP-style documentation on request.
• 2
  Medical devicesISO 13485:2016, material traceability, inspection reports.
• 3
  Any regulated programISO 27001:2022 for file handling and data security.

The lowest unit price is not the lowest total cost. A quote that splits your part across three suppliers to get a better rate on each operation adds shipping, requalification and a week of coordination. One shop with one setup on one machine is usually cheaper once you count your own engineering hours.

Compare quotes on the same basis. Ask each supplier to state the number of setups, the machine type, the inspection method, the finish as measured, and whether programming and fixturing are included. Five numbers, and the comparison becomes objective.

Watch for a quote that assumes a looser tolerance than your drawing. If a supplier prices a bore at ±0.05 mm when you called ±0.01 mm, the price is real but the part is not. That conversation is better held before the chips fly.

Tooling is the other hidden line. Custom fixturing can add days to the front of a schedule even when the cut is short. For prototypes, ask whether the fixture is soft jaw, modular or a dedicated plate. For a 10,000-part run, a dedicated fixture amortizes fast and protects tolerance over the whole batch.

• 1
  Ask for setup countOne number that predicts lead time better than any promise.
• 2
  Ask what is includedProgramming, fixturing, inspection reports, finishing, packaging.
• 3
  Ask for the inspection planWhich features are measured, with what instrument, at what frequency.

The first trap is the vague file. A STEP model with no tolerance callouts, no material spec and no surface requirement forces the shop to quote assumptions. The quote comes back fast and wrong. Send the model, the 2D drawing with GD&T, the material grade and the finish callout.

The second trap is the compressed schedule. If you need parts in three days and the route needs heat treatment, anodizing and laser marking, the calendar does not bend. Sequence the operations early and tell the shop which deadline is real.

The third trap is treating certification as decoration. If your program needs ISO 13485 or IATF 16949, confirm the certificate covers the site that will make your part. A group certificate that excludes the production plant does not help you pass an audit.

The fourth trap is ignoring the second operation. A 5-axis center can produce a complex form, but a ground bore or a tapped hole may still need a separate step. Ask how the shop handles post-machining operations and whether they are in-house or subcontracted.

• 1
  Incomplete RFQNo drawing, no material grade, no finish callout, no quantity.
• 2
  Unrealistic dateSchedule ignores finishing, heat treatment or inspection time.
• 3
  Certificate mismatchThe certificate scope does not include the producing site.
• 4
  Hidden second operationGrinding, honing or EDM assumed but never quoted.
