"Hiking" is not a product name. On the German machine-tool side it describes a carriage that walks along a bed in a slow, controlled stroke, the same motion a surface grinder or a honing head uses. The german green gehring hiking machine belongs to that family. It is a grinding platform, not a milling center, and it is bought for one reason: to hold geometry on long, hard parts.

The work happens with an abrasive wheel or a honing stone that traverses the workpiece in repeated passes. Depth of cut per pass is small, usually 0.005–0.05 mm. That is the whole point. Take off a few microns at a time and the heat goes into the chip instead of the part.

Where a mill leaves cutter marks and a heat-affected layer, this machine leaves a scratch pattern measured in fractions of a micron. Surface finish lands around Ra 0.2–0.8 μm on hardened steel when the wheel is dressed correctly. No polishing step is needed afterward.

The trade is speed. A hike stroke is far slower than a milling pass, so the machine earns its place on features where flatness, parallelism or roundness matter more than cycle time. Long guideways, spindle bores, hydraulic bores and hardened shafts are typical.

Every pass removes a thin chip. The abrasive grains cut rather than plough, provided the wheel stays sharp and the coolant reaches the contact zone. When the wheel glazes, the grains stop cutting and start rubbing, and the part heats up fast.

Heat is the enemy of tolerance. A 1,000 mm steel bar can grow about 0.012 mm per °C. If grinding raises the surface 10 °C above the bed, the measurement you take hot is wrong by more than the tolerance you are trying to hold.

The usual fix is a spark-out sequence. After the last roughing pass, the machine makes several passes at zero infeed until sparks stop. This lets the elastic deflection of the wheel and fixture relax, and the final size settles instead of springing back.

Coolant does two jobs: it cools and it flushes. Filtered coolant at 10–20 bar keeps the contact zone clear on deep cuts. Without filtration, swarf recirculates and scratches the finish you just produced.

The carriage follows the bed. If the bed is worn, the part inherits that error along its full length. On a long machine the guideway geometry matters more than the wheel, more than the control, and more than the operator.

Straightness is normally specified per unit length, then over the whole travel. A machine that holds 0.005 mm over 300 mm can still be out by 0.03 mm over 2,000 mm if the bed has a slope. Always ask for the full-travel number, not just the per-300 mm figure.

Thermal drift runs the same way. The bed warms from the hydraulic unit and the grinding zone. A machine that is accurate cold can walk 0.01–0.02 mm in the first hour of running. Warm-up passes and a stable coolant temperature cut that drift.

We keep our own grinding work inside ±0.005 mm and verify it with in-process gauging plus a final CMM report. If the geometry cannot be measured on the machine, it cannot be held on the machine.

Pick this process for hard, long, heat-treated parts that need a fine surface and tight geometry. Typical candidates are guide rails, hydraulic rods, spindle tapers, bearing bores, and die plates after hardening. Materials like 4140, 4340, D2, 440C and 17-4PH respond well.

Do not pick it for soft aluminium, thin-walled pockets, or complex 3D contours. An abrasive wheel cannot reach into a deep pocket or follow a curved surface the way a ball-nose cutter can. Those parts go on a 5-axis mill instead.

Do not pick it for one or two pieces in a rush either. Fixturing and wheel dressing take time, and the setup cost only pays back over a batch or on a part that no other process can hold.

A practical rule: if the drawing calls for flatness under 0.01 mm, a surface finish finer than Ra 0.4 μm, or a hardened bore with tight roundness, grinding is the right door. If it calls for pockets, ribs and cosmetic blends, it is not.

Wheel selection follows the material. For hardened tool steel, aluminium oxide in a vitrified bond at 46–60 grit is a common starting point. For stainless, a softer grade keeps the wheel cutting instead of loading. For carbide, diamond abrasive is the only sensible choice.

Dressing is where most finish problems start. A single-point diamond dressed too fast leaves a rough wheel face and a rough part. A slow, controlled dress with a small depth, around 0.01–0.02 mm per pass, opens the grains and keeps the wheel free-cutting.

Feed rate and depth of cut trade against each other. A common roughing setting is 0.02–0.03 mm depth at a table speed that keeps the wheel loaded but not buried. Finishing drops to 0.005 mm or less, followed by spark-out.

Coolant concentration matters more than most people expect. Too lean and the wheel loads; too rich and the mist becomes a nuisance. Keep it inside the supplier's range and check it weekly, not yearly.

Grinding produces a clean surface, so measurement is straightforward, provided the part is at room temperature. Measure cold. A part straight off the machine can read 0.01 mm small and then grow back as it cools.

For long parts, check straightness on a granite surface plate with a dial indicator, or on a CMM with the part supported the way it will be in service. How you support it changes the reading. This is not a detail you can skip.

Roundness on bores goes on a roundness tester or a CMM circle fit. Surface finish goes on a profilometer, measured across the lay, not along it. A reading taken along the scratch direction always looks better than it is.

We run raw material checks, in-process monitoring and a final inspection before shipment, and we send reports on request. If a drawing needs a specific report format, say so at quoting time.

Hardened steels are the natural fit: 4140, 4340, 4130, D2, 440C, and 17-4PH stainless. These hold their geometry after grinding because the heat treatment is already done and the abrasive does not soften them.

Softer materials can be ground, but they tend to load the wheel. Aluminium 6061 and 7075 smear rather than cut unless the wheel is very open and the coolant is right. For those, milling usually wins on cost and finish consistency.

Size range runs from small spindle bores up to long guideways. We work on parts up to 4,000 mm on our larger platforms, and we hold ±0.005 mm on the features the drawing controls.

If a part needs both milled pockets and ground faces, split the routing. Mill first, heat treat, then grind the critical faces. Doing it in that order avoids re-cutting hardened material and avoids scrapping a finished surface.
