Any shop can print ±0.005 mm on a website. The useful question is which machine holds it, on which feature, at what size. On a 6061-T6 bracket under 200 mm, a good 5-axis center holds ±0.005 mm all day. Stretch the same callout across a 3,000 mm weldment and thermal drift starts eating your budget.

So ask for the process split. Roughing removes bulk, then a semi-finish leaves 0.2–0.3 mm, then a light finish pass of 0.05–0.1 mm with a fresh tool. If a supplier cannot describe that sequence, the tolerance number is marketing.

Surface finish travels with tolerance. A ±0.005 mm bore is usually paired with Ra 0.8–1.6 μm. If your drawing asks for Ra 0.2–0.8 μm, expect a separate finishing operation and a higher price. Decide early which surfaces truly need it.

One more thing: datum strategy. A part held in a vise for three setups accumulates position error at each flip. Single-setup 5-axis work on complex geometry is often cheaper than holding tight tolerances across four operations.

• 1
  Name the featureTolerance on a flat face is cheap. On a deep bore or thin wall, it is not.
• 2
  Give a datum calloutWithout it, the shop guesses and you argue later.
• 3
  Separate cosmetic from functionalRa 0.2–0.8 μm everywhere triples finishing time for no gain.

The machine list tells you what the shop does every week. A house with 27 three-axis machines, 12 four-axis mills, 16 mill-turn centers and 16 simultaneous 5-axis centers can route a job to the right spindle instead of forcing it onto the only one available. That routing is where cost comes out.

Envelope matters more than people expect. Travel of 4,000 × 400 × 150 mm handles long rails and housings that would otherwise be split and bolted. Medium frames around 750 × 1,150 × 550 mm and 600 × 600 × 600 mm cover most enclosures and manifolds. Compact work down to 500 × 310 × 200 mm goes on the small, fast machines.

A Ø400 mm rotary table is the quiet workhorse. It lets a 4-axis job cut four faces in one setup, which removes three re-clamps and the position error that comes with them. For parts with features on every side, that single change often decides whether the quote is competitive.

Ask how many machines are actually running, not how many were bought. A list of 127 high-precision CNC machines means little if half sit idle for lack of operators.

• 1
  Match envelope to your partOversized machines cut slower and cost more per hour.
• 2
  Count the setupsEach extra setup adds position error and labor.
• 3
  Ask about the bottleneckThe constraint machine sets your real lead time.

Certifications are a filter, not a ranking. ISO 9001:2015 covers basic quality management and is the floor for any serious supplier. If your parts touch a vehicle, you want IATF 16949:2016 in the chain. Medical device work needs ISO 13485:2016. If you send sensitive CAD files, ISO 27001:2022 tells you the data handling has been audited.

Inspection is where the certificate becomes real. A shop running raw material checks, in-process monitoring and 100% inspection before shipment catches drift at the machine, not at the customer. Reports on request let your own quality team close the loop without a trip.

Ask what happens when a dimension fails. A leader quarantines the lot, tells you the same day, and proposes a fix. A weak shop ships it and waits for you to find out. The difference shows up in your incoming inspection hours.

Qualification rate is a useful number if the supplier tracks it honestly. 99.99% across shipped lots means scrap and rework stay inside the shop, where they belong.

• 1
  Match cert to industryISO 9001 alone will not satisfy an automotive audit.
• 2
  Ask for the FAIR planFirst article inspection on the first run, not the tenth.
• 3
  Request sample reportsOne page of real data beats a paragraph of promises.

Split lead time into three clocks: quote, start and ship. A useful benchmark is quotation with DFM analysis inside 12 hours, production starting inside 24 hours, and parts shipping in 3–5 days once material is on hand. If a supplier quotes three weeks for a 20-piece aluminium job, ask what is queued ahead of you.

MOQ is a structural question. Shops tooled for long runs push small orders to the back. A supplier set up for one prototype through 10,000+ part runs will give a prototype the same DFM attention as a production order. That matters when your design is still moving.

Read the quote line by line. Material grade, stock size, setup count, finishing and inspection should each appear. A single lump sum hides where the cost sits, and you cannot negotiate what you cannot see.

Historical late-delivery probability below 2% is a reasonable target to ask about. Any shop tracking that number knows its own bottleneck, which is a good sign by itself.

• 1
  Ask for stock statusMaterial procurement often dominates the schedule.
• 2
  Check the setup countIt should match the machine mix you were told about.
• 3
  Confirm NDA earlyGet it signed before you upload production CAD.

A leader in precision CNC machining services should not flinch at your material. Aluminium 6061, 7075, 2024 and ADC12 are routine. Stainless 303, 304, 316L and 17-4PH are routine. So are 4140, 4340 and tool steel. Titanium TC4, Inconel and magnesium AZ31B are harder and slower, and the quote should say so instead of pretending otherwise.

Plastics behave differently. POM and PEEK cut cleanly, ABS and PMMA are soft and mark easily, and carbon fibre eats tools. If the shop treats all plastics the same way, expect poor edges on the soft ones.

Finishing belongs in the same conversation. Anodizing in clear, colour, hardcoat or conductive; electroless nickel, zinc, silver and gold plating; powder coating and black oxide; bead blasting, tumbling, brushing and polishing. Keeping those in house means one owner when the surface spec is missed.

Laser marking has a practical floor: minimum character height 1.5 mm. Below that, the mark becomes unreadable and the operator will tell you so.

• 1
  Flag hard alloys earlyInconel and titanium need slower speeds and different tooling.
• 2
  Specify finish by areaCosmetic faces and sealing faces rarely need the same Ra.
• 3
  Check masking needsAnodize builds thickness; threads and bores may need protection.

The same part scores differently depending on the industry. Aerospace work leans on material traceability, single-setup 5-axis capability and inspection documentation. Automotive and EV buyers care about IATF 16949, PPAP-style records and repeatable cycle times at volume.

Medical devices shift the weight to ISO 13485, clean handling and surface finish control. Robotics and automation jobs usually need tight bore alignment across a housing, which is where the Ø400 mm rotary table and mill-turn centers earn their place.

Electronics work is often small, thin and cosmetic, so tool marks and burrs dominate the complaint list. New energy parts tend to be larger, with flatness and thermal stability driving the spec.

None of this changes the seven checks. It changes which rows you weight. Write your own weights before you open the quotes, or the cheapest number will quietly set them for you.
