Medical parts rarely fail because a shop cannot machine a simple profile. They fail on the features that carry function: a press-fit bore, a sealing face, a pivot hole that must stay round after heat treatment. When you ask for medical related CNC machining services, the first useful question is not 'what is your tolerance' but 'what can you hold on this feature, in this material, at this size'.

GreatLight works to ±0.005 mm (±0.0002 in) on critical features. That figure is a capability, not a promise for every dimension on the drawing. A 300 mm long titanium shaft and a 12 mm stainless collar do not behave the same way. Thermal growth, tool deflection and fixture stiffness all move the result. A shop that answers with a single global number is telling you it has not thought about your part.

Ask how the feature will be inspected. A tolerance you cannot measure is a tolerance you cannot ship. For holes and bores, a coordinate measuring machine or an air gauge gives you a number you can trend. For a sealing face, you need both the flatness and the finish, because Ra 0.8–1.6 μm on a wavy surface still leaks.

One more point on drawing practice. If a dimension is not functional, do not tolerance it tightly. Tight tolerances add cost, add inspection time and add scrap risk. Engineers who mark only the functional features usually get lower quotes and fewer arguments at first article.

ISO 13485:2016 is the quality management standard written for medical devices. It tells you the shop has documented controls for design transfer, traceability, process validation and corrective action. It does not tell you the shop cleans parts to your bioburden limit, and it does not replace your own supplier audit.

GreatLight holds ISO 13485:2016, ISO 9001:2015, IATF 16949:2016 and ISO 27001:2022. Each one answers a different question. ISO 9001 covers general quality. IATF 16949 covers automotive-style process control, which is useful when a medical part runs in high volume. ISO 27001 covers information security, which matters when you send patient-linked or proprietary CAD data.

For a buyer, the practical step is to request the certificate and read the scope. A certificate with a narrow scope may not cover the process you need. Check the expiry date too. An expired certificate in a tender pack is a warning sign about document control.

If your part is implantable or contacts tissue, the machining supplier is one link in a longer chain. Cleaning, passivation, packaging and sterilization sit downstream. A good supplier will tell you where its scope ends instead of implying it covers everything.

• 1
  Read the scopeA certificate only covers the processes listed on it.
• 2
  Check the dateExpired documents point to weak document control.
• 3
  Ask about traceabilityLot numbers should link material, machine and inspection records.

The material list on a quote tells you how seriously the shop read your drawing. For medical work the common families are stainless, titanium, cobalt chrome and engineering polymers. Each one fails in its own way.

316L stainless is the workhorse for instruments and housings. It machines cleanly but work-hardens if the tool rubs, so feeds and speeds matter. 17-4PH (SUS630) gives higher strength after aging, and it moves during heat treatment. Plan a finishing cut after aging if the tolerance is tight. 420 and 440C take a keen edge and are common in cutting instruments, but they are harder on tooling.

Ti-6Al-4V (TC4) is light, strong and biocompatible, and it is also the material that punishes poor process control. It conducts heat poorly, so heat concentrates at the cutting edge. It springs back against the tool. Thin walls deflect. A shop that machines titanium well usually has the right tooling, the right coolant strategy and a rigid setup.

PEEK and POM appear in insulators, seals and disposable device bodies. They are dimensionally stable when machined dry and annealed, but they absorb moisture and move. If a polymer part has a tight fit, say so early so the shop can plan a stress-relief step.

• 1
  Name the grade316L is not the same as 303 or 17-4PH.
• 2
  Watch heat treatmentAging and hardening move dimensions; leave stock.
• 3
  Plan for polymer creepAnnealing before the final cut reduces movement.

GreatLight runs 127 high-precision CNC machines across three wholly-owned plants in Dongguan and Singapore, with 7,600 m² of floor space and 150 technicians. The mix matters more than the total: 16 simultaneous 5-axis machining centers, 16 mill-turn centers, 12 four-axis mills, 27 three-axis machines and a Ø400 mm rotary table.

Five-axis work helps when a part has features on several faces or an organic contour that would need multiple fixtures on a 3-axis machine. Every re-fixture adds stack-up error. For a surgical instrument with an angled boss and a mating bore, cutting both in one setup is often the difference between a fit and a rework.

Size range runs from compact work at 500 × 310 × 200 mm up to 4,000 × 400 × 150 mm on the largest travel. If your housing is longer than that, say so at RFQ. It is better to learn early than to redesign after the quote.

Mill-turn centers handle parts that are mostly turned but carry milled flats, slots or cross-holes. For a shaft with a keyway and a cross-drilled hole, one mill-turn cycle removes the second operation and the concentricity risk that comes with it.

A machined surface is not automatically a medical surface. Finish affects wear, friction, cleanability and how a part seats against a seal. GreatLight can hold Ra 0.2–0.8 μm on fine finishes, Ra 0.8–1.6 μm on high-finish work and Ra 1.6–3.2 μm as-machined.

Reach for the tighter band only where it does work. A sliding seal face, a bearing journal or a fluid path usually justifies Ra 0.8–1.6 μm. A bracket that never touches anything functional does not. Tightening finish across a whole drawing raises cost without changing performance.

Finishing options include anodizing in clear, colour, hardcoat and conductive types, electroless nickel, zinc, silver and gold plating, powder coating, black oxide, bead blasting, tumbling, brushing and polishing. Laser marking is available down to 1.5 mm character height, which is useful for UDI-style marks and lot codes.

Cleaning before packaging is the step buyers most often forget to specify. Machining leaves coolant residue, fine chips and handling oils. If your incoming inspection includes a cleanliness check, tell the supplier before production, not after the parts arrive.

GreatLight quotes with a free DFM analysis within 12 hours, and production can start within 24 hours of approval. Parts typically ship in 3–5 days. Historical late-delivery probability sits below 2%. Those numbers describe the shop's normal rhythm, not a guarantee for a part with an unusual process step or a material on allocation.

There is no minimum order quantity. The same shop runs one prototype and a 10,000+ part run. That matters for medical programs because the process you validate on a prototype should carry into production. If a supplier outsources the prototype and then moves to a different line for volume, your validation data may not transfer.

Read the quote structure carefully. A useful quote separates material, machining, finishing, inspection and freight. A single lump sum hides where cost lives, and it makes a design change hard to price. Ask what the DFM report will cover: wall thickness, tool reach, tolerance stack and any feature that will need a second setup.

Confidentiality should be settled before you upload drawings. Uploads are handled as secure and confidential, and an NDA is available on request. For device work, confirm who inside the shop can see the files and how long they are retained.

• 1
  12-hour quoteFree DFM analysis with the quotation.
• 2
  24-hour startProduction can begin after approval.
• 3
  3–5 day shippingTypical for standard medical part runs.

GreatLight inspects 100% of parts before shipment, with a raw material check, in-process monitoring and a final inspection. Qualification rate is 99.99%. Inspection reports are available on request. The point of asking is not to collect paper. It is to know which dimensions are checked, how often and with what instrument.

For a first article, a full dimensional report against the drawing is standard practice. For a production run, agree on which features get checked on every part and which are sampled. A critical bore may need 100% gauging. A cosmetic edge may need only a visual check.

Traceability is the thread that ties a delivered part back to its heat. Ask how lot numbers link material certificates, machine records and inspection data. If a field issue appears six months later, that thread is the only way to bound the problem.

Keep the documentation boundary clear. Machining records, material certs and inspection data belong to the supplier. Sterilization records, bioburden testing and clinical evaluation belong to you or your contract manufacturer. A supplier that overstates its scope is harder to audit than one that states limits.
