Processing steel using CNC removes metal with a cutting edge that gets hot fast. Steel conducts heat poorly compared with aluminium, so much of the heat from the shear zone stays in the tool and the chip instead of leaving with the workpiece. That single fact drives most of the decisions that follow: lower surface speed, more coolant pressure, sharper edge geometry, and shorter tool life budgets.

Cutting forces are the second difference. A 4140 workpiece at 30 HRC pushes back roughly three times harder than 6061-T6 at the same depth of cut. The machine, the vise, and the fixture all feel that. A setup that holds fine on aluminium will chatter on steel unless the support is beefed up.

The third difference is springback and work hardening. Austenitic stainless such as 304 and 316L hardens under the cut, so a dull insert makes the next pass harder than the last. Feed per tooth has to stay above the work-hardened layer, typically 0.08–0.15 mm per tooth on a 12 mm carbide end mill.

None of this makes steel hard to machine. It makes steel unforgiving of shortcuts. Get the grade, the speeds, and the support right and a steel part holds ±0.005 mm as reliably as anything else on the floor.

Grade choice decides more of the outcome than any cutting parameter. Low-carbon 1018 machines cleanly and welds well, which suits brackets, plates, and prototype frames. It will not harden, so it cannot carry a wear surface. Medium-carbon 1045 takes more edge pressure and gives a better finish on turned shafts and pins.

Alloy steel 4130, 4140, and 4340 trade machinability for strength. Pre-hardened 4140 at 28–32 HRC is common for mould bases, hydraulic bodies, and stressed shafts. Cut it dry and it will tear; cut it with the right coated carbide and it produces a stable, predictable chip.

Tool steel is a different conversation. D2 and A2 are usually supplied annealed around 200–240 HB, and they machine like a stubborn alloy steel. Once hardened past 50 HRC, grinding or EDM becomes the honest answer, not milling.

A36 structural steel is cheap and weldable. It is also gummy in the cut and rarely holds a tight tolerance where a machined pad meets a flame-cut edge. Use it for weldments, not for bearing fits.

Speeds and feeds for steel sit in a narrow band compared with aluminium. Coated carbide on 1018 usually runs 120–180 m/min surface speed. On 4140 pre-hardened, drop to 80–120 m/min. On 304 stainless, expect 60–90 m/min and accept shorter tool life.

Depth of cut matters less than people assume, as long as the tool is not rubbing. A radial engagement of 30–40 percent of the cutter diameter with a 1×D axial depth keeps radial forces down and lets the machine hold size. Full-width slotting in steel is where chatter starts.

Coolant is not optional on stainless and alloy steel. Through-tool coolant at 30–70 bar clears chips from deep pockets and stops recutting, which is the fastest way to break a carbide insert. Flood coolant is adequate for open facing and turning work.

Rough with inserts, finish with a fresh edge. Reusing a worn finisher on steel is the most common reason a part comes off size. One finishing pass with a sharp tool beats two passes with a dull one.

Steel moves when you cut it. Cold-rolled and hot-rolled stock carries residual stress from the mill, and removing material from one side releases it unevenly. A long bracket milled on one face will bow. Rough both sides, let the part rest, then finish.

Thin walls are the visible version of the same problem. A 1.5 mm wall in 4140 will deflect under the cutter even with modest radial engagement. Support it from inside with a fixture, or leave a sacrificial web that is removed in a later op.

Thermal growth is the quieter issue. A steel part that measures on size at 25 °C will not measure the same at 35 °C if the tolerance is tight. For work at ±0.005 mm, let the part stabilize before final inspection rather than measuring straight off the machine.

On hardened or heavily cold-worked stock, a stress-relief anneal before finish machining removes most of the drift. It costs one process step and often saves a rework cycle.

Steel demands rigid support because the cutting forces are high. A standard milling vise is fine for a 100 mm block. Beyond that, bolt the part to a fixture plate or use a tombstone so the load path runs straight into the table.

Five-axis work helps here. On a simultaneous 5-axis center with a Ø400 mm rotary table, a part can be reached from five sides in one setup, which removes the re-fixturing error that accumulates across three or four separate operations. We run 16 simultaneous 5-axis centers for exactly this reason.

Deep holes in steel need peck drilling with full retract and through-coolant. A 10×D hole in 4140 without chip evacuation will snap a drill. Start with a stub drill, then go long.

Thread milling beats tapping on large steel threads and on any thread near a wall. It produces a better surface, controls the minor diameter, and does not risk a broken tap in a finished part.

On a stable setup with the right tooling, we hold ±0.005 mm (±0.0002 in) on critical steel features. That is a shop capability, not a default. Every feature called at that level needs a defined datum and a measurement method a CMM can reproduce.

Surface finish follows the tool and the feed. As-machined steel typically lands at Ra 1.6–3.2 μm. A finishing pass with a sharp edge and a light feed reaches Ra 0.8–1.6 μm. Below that, Ra 0.2–0.8 μm, you are into fine finishing or a secondary process.

Heat treatment changes size. If a part is machined, hardened, and then assembled without a post-hard grind, the fit will be wrong. Either leave grinding stock or specify the heat treat before the final finishing operation.

Every part we ship is inspected 100 percent before it leaves, with raw material checks upstream and in-process monitoring between operations. Reports go out on request. That inspection step is what makes a tight call on a print defensible.
