The Difference Between High Speed Steel and Tungsten Steel, Clearly Explained

• 1
  High speed steel and tungsten steel at a glance
• 2
  What high speed steel and tungsten steel actually are
• 3
  Hot hardness, speed, and where each tool wins
• 4
  Machining high speed steel and tungsten steel parts
• 5
  Failure modes tell you which material was wrong
• 6
  Cost per part, not cost per tool
• 7
  How to specify the material on a drawing

High speed steel is a tool steel alloyed with tungsten, molybdenum, vanadium, chromium, and carbon. The name comes from its ability to keep hardness while running hot, which lets a cutting tool work at speeds that would soften plain carbon steel. Grade families such as M2 and M42 cover most shop use. M2 is the workhorse for drills and taps. M42 adds cobalt and holds an edge longer in stainless and high-tensile alloys.

Tungsten steel is the shop name for cemented tungsten carbide. It is not a steel in the metallurgical sense. Powdered tungsten carbide grains are sintered with a cobalt or nickel binder, typically 6–12% cobalt by weight. More binder means more toughness and less wear resistance. Less binder means a harder, more brittle insert. Grain size matters too: submicron grades take a keener edge, coarse grades resist shock.

The two materials are often confused because both contain tungsten and both are used for cutting. The difference is structure. HSS is a homogeneous hardened alloy that can be ground, welded, and heat-treated. Carbide is a composite that is formed to near-final shape and then ground with diamond. You cannot anneal and re-harden a carbide insert in a shop furnace.

That structural gap explains nearly every behavior difference later in this article. HSS deforms and dulls. Carbide fractures and wears. Different failure mode, different process window, different spare-parts plan.

Hot hardness is the single most useful number when you choose between these materials. An HSS drill starts to lose hardness around 540–600 °C. Push surface speed too high and the edge rounds off within minutes. Carbide keeps its hardness to roughly 800–1,000 °C, so the same hole can be drilled at three to five times the cutting speed without edge collapse.

That speed difference drives cost. On a CNC mill with rigid workholding, a carbide end mill at 100–150 m/min in mild steel removes far more metal per hour than HSS at 25–35 m/min. The carbide tool costs more, but cycle time drops and the tool change interval stretches. On a long production run, carbide usually pays back inside the first batch.

The picture flips on interrupted cuts, hand-fed drilling, and older machines with spindle play. Carbide has low fracture toughness. A chipped corner ruins the insert. HSS bends, dulls, and keeps cutting. For a maintenance shop drilling a few holes in a welded bracket, a HSS bit is the cheaper and calmer choice.

Taps and reamers are another HSS stronghold. Thread cutting puts torsional shock on a small cross-section. HSS absorbs that shock. Carbide taps exist, but they demand rigid holders, correct chamfer geometry, and strict speed control, or they snap in the hole.

• 1
  Choose carbide whenRigid setup, long run, abrasive or hard material, high spindle speed available.
• 2
  Choose HSS whenInterrupted cut, small-diameter tap or drill, mixed one-off jobs, manual feed.
• 3
  Watch the machineA worn spindle or weak fixture punishes carbide long before it hurts HSS.

In annealed condition, HSS machines much like other alloy tool steels. A hardness around 200–250 HB allows turning and milling with carbide tooling at moderate feeds. Rough with a 0.5–1.0 mm depth of cut, then leave 0.2–0.3 mm for finishing. Stress relief before final grinding prevents movement when the part is later hardened.

Hardened HSS is a different job. At HRC 62–67, only grinding, EDM, or hard milling with coated carbide and light passes will work. Wire EDM is the standard route for complex profiles in hardened HSS because it does not depend on tool pressure. Expect a recast layer of a few micrometres and plan a finishing pass.

Sintered carbide parts are usually supplied in near-net shape, then ground with diamond. Green machining of the pressed compact is possible before sintering, but shrinkage of roughly 15–25% must be built into the drawing. That is a tooling decision, not a shop-floor fix.

For machined parts that need wear resistance, many designs now use a steel body with a carbide or hardened insert instead of a solid HSS part. The body carries the load, the insert takes the abrasion. It is often cheaper to replace a small insert than to re-grind a whole component.

GreatLight machines tool steel, stainless, and alloy steel on 127 CNC machines, including 16 simultaneous 5-axis centers. We hold ±0.005 mm on critical features and inspect every part before shipment. If a design calls for a hardened insert pocket, we can machine the pocket to the tolerance the insert needs.

When a tool or part fails early, the fracture pattern usually names the wrong material. A HSS drill that turns blue and rounds its edge ran too fast or lost coolant. The fix is speed, feed, or coolant, not a harder grade. A carbide insert that chips at the corner took an impact it could not absorb. The fix is a tougher grade, a hone, or a lighter entry.

A carbide tool that wears evenly on the flank but never chips was simply run too slow or too long. Carbide rewards speed; babying it produces built-up edge and poor finish. If the chips are thin and the edge is rubbing, increase feed per tooth until the tool cuts rather than pushes.

HSS taps fail by torsion, not wear. A snapped tap in a blind hole usually means a chip jammed in the flute or the hole was drilled undersize. Use the correct drill size, form taps where possible, and peck to clear chips. The material choice rarely causes the break.

Wear on a carbide wear pad looks like polished metal and a rounded edge. That is normal and predictable. Track the wear rate and replace on a schedule rather than on failure. A wear pad that chips instead of wearing has too little cobalt for the load.

One practical test: if the failure is gradual, the material is too soft for the job. If the failure is sudden, the material is too brittle. That single distinction resolves most arguments about high speed steel and tungsten steel on the shop floor.

• 1
  Blue edge on HSSHeat, not wear. Reduce surface speed or improve coolant flow.
• 2
  Chipped carbide cornerImpact. Use a tougher grade or a honed edge.
• 3
  Snapped tapChip jam or wrong hole size. Check drill diameter and flute clearance.

A HSS end mill may cost a fraction of a comparable carbide tool, and that price tag is what many buyers compare. The number that matters is cost per part. If carbide cuts cycle time by half and lasts five times longer, the higher sticker price is irrelevant on a run of thousands.

Short runs and one-offs favor HSS for a different reason: setup risk. A single chipped carbide tool can stop a job and add a day of waiting for a replacement. A HSS tool can often be re-ground on site and put straight back into the spindle. That resilience has real value in a maintenance or prototype shop.

Re-grinding is a hidden cost line. HSS tools can be sharpened many times on standard aluminum oxide or cubic boron nitride wheels. Each re-grind removes a small amount of material and changes the geometry slightly. Carbide needs diamond grinding, and each pass is more expensive. For a small shop without diamond capability, HSS keeps the sharpening loop in-house.

There is also the holder and machine side. Carbide cutting speeds require spindle RPM that older machines cannot reach. If a shop runs a 6,000 rpm spindle, carbide tooling will never hit its recommended surface speed in small diameters. HSS is then the practical choice regardless of tool price.

• 1
  Long run, rigid machineCarbide. Cycle time dominates the cost equation.
• 2
  Short run, mixed workHSS. Low setup risk and easy re-sharpening matter more.
• 3
  Low spindle speedHSS. Carbide cannot reach its cutting window.

A drawing that says only tool steel invites a guess. Name the grade, the hardness range, and the heat-treat condition. For HSS, write something like M2, hardened to HRC 62–64, stress relieved before final grind. For carbide, name the grade, the cobalt content, and the grain size if wear resistance is critical.

State the function of the feature, not just the dimension. A pin that must resist abrasion and a pin that must absorb shock can share a diameter and need different materials. Adding a one-line note such as wear surface, no impact or shock load, replaceable insert saves a revision later.

Tolerances on hardened parts should account for grinding stock. Hold the pre-hardened dimension loose, then finish after heat treatment. Trying to hold ±0.005 mm before hardening and expecting it to survive the quench is a common and expensive mistake.

For prototype quantities, a machined HSS or steel body with a purchased carbide insert is often faster than a solid carbide part. The insert is a catalog item with a known grade. The body is simple turning or milling work. GreatLight quotes and returns a DFM analysis within 12 hours, and production can start within 24 hours on approved drawings.

If the part must be a single piece of carbide, expect diamond grinding time and plan the budget accordingly. That is a capability question, not a price negotiation.

• 1
  Name the gradeM2, M42, or a specific carbide grade with cobalt content.
• 2
  Name the hardnessHRC range for steel, HRA range for carbide.
• 3
  Name the functionWear surface, shock load, or replaceable insert.
• 4
  Leave grinding stock0.2–0.3 mm on surfaces finished after heat treatment.
