A 3 axis machine moves the spindle in X, Y and Z while the part stays clamped. That is the whole geometry. If every feature on your part can be reached from one direction, or from a handful of setups, 3 axis will cut it at the lowest hourly rate on the floor.

Prismatic parts are the natural fit: brackets, plates, manifolds, heat sinks, control housings, fixture blocks, pump bodies. A 3 axis mill with a Ø400 mm rotary table still counts as 3 axis work, because the table indexes between setups rather than cutting continuously in five axes.

The limit shows up when you need a feature on a face you cannot reach without re-clamping. Undercuts, deep side pockets on four faces, and blended compound angles all push the part toward 4 or 5 axis. Re-clamping is not free: every new setup adds a datum error and a fixture cost.

A useful test before you send an RFQ. Count how many distinct tool approach directions the part needs. One or two means 3 axis. Four or more, or any feature that follows a curved surface, means you should ask for a 4 or 5 axis quote as well and compare total cost, not hourly rate.

• 1
  Good fitFlat or stepped geometry, through holes, pockets, slots, single-face features
• 2
  Workable with setupsParts with 3 to 4 machined faces and a clear datum scheme
• 3
  Poor fitCurved blades, deep undercuts, features that need continuous 5 axis motion

A quote is a technical document, not a price tag. Ask what tolerance the shop is quoting to, which machine the job is planned on, and how many setups they counted. If the answer is vague, the price is a guess and will move once production starts.

Compare the machine list against the part size. GreatLight runs 127 high-precision CNC machines, of which 27 are three-axis. Travels range from 500 × 310 × 200 mm on the compact frames up to 4,000 × 400 × 150 mm on the large ones. A part that fits a compact frame should not be quoted on a large machine.

Materials matter as much as geometry. Aluminum 6061-T6 and 7075 cut fast and hold ±0.005 mm without drama. Stainless 316L and 17-4PH move more under heat, so the shop needs a roughing and finishing pass with a stress-relief pause on thin walls. Titanium TC4 and Inconel raise tool wear and cycle time, and the quote should reflect that.

Ask about the finishing chain too. Anodizing, electroless nickel, black oxide, bead blasting and laser marking all change lead time and can change the critical dimensions. A factory that does finishing in-house controls both. GreatLight keeps those steps under one roof, so your part is not shipped out and re-qualified at a second vendor.

Finally, read the inspection clause. "100% inspection before shipment" means every part, not a sample. Raw material check, in-process monitoring and a final inspection report on request give you something to file when a customer audits you.

The ODM part of the relationship starts before toolpaths. A trusted partner reads your model, flags a wall that is too thin for the material, or a hole that will chatter at the depth you drew, and sends a DFM note back with the quote. That note is where most of the money is saved.

Engineering co-development means the supplier holds context across revisions. When rev C changes a boss height, the shop already knows which fixture and which datum carried rev B. A transactional shop re-quotes from zero and re-learns the part every time.

Confidentiality belongs in this section. If your drawings carry unreleased geometry, ask for an NDA and check how files are stored. GreatLight works to ISO 27001:2022 practice for information security, and uploads are treated as confidential by default.

Industry certificates should match your end market, not just look good on a page. Automotive and EV programs usually want IATF 16949:2016. Medical device work looks for ISO 13485:2016. General industrial and robotics work is normally satisfied with ISO 9001:2015. Ask which certificate covers the plant that will actually run your job.

Scale is the last piece. A partner that can take one prototype and then a 10,000-part run without a new supplier audit saves you a full qualification cycle. GreatLight quotes from one part upward with no minimum order quantity.

The first trap is comparing hourly rates instead of landed part cost. A shop with a low rate that needs three extra setups, or ships the part out for anodizing, will land higher than a factory that runs the whole chain in-house. Compare the delivered part, in spec, at your dock.

The second trap is an unclear datum. If your drawing does not name datum A, B and C, every shop will pick its own, and the parts will not assemble with the ones you already have. Put the datum scheme on the drawing before you send it.

The third trap is treating a certificate as a substitute for a process. A certificate says the system is audited. It does not say the operator on your job checked the bore before the part came off the machine. Ask what is measured, how often, and what happens when a dimension drifts.

The fourth trap is silence on lead time risk. Ask for the historical on-time figure in writing. GreatLight reports a late-delivery probability below 2%, with parts shipping in 3–5 days on released orders. If a supplier will not put a number on it, treat the schedule as open.

The fifth trap is a single-source finishing vendor. If the anodizer is a third party, your part leaves the controlled process and any scratch or dimension shift becomes a dispute. Keep as many steps as possible inside one plant.
