G-code is a list of instructions. Each line moves an axis, sets a feed rate, or switches a function on. G01 is a straight feed, G02 and G03 are arcs, G81 is a drilling cycle. An operator or CAM programmer writes these blocks, posts them for a specific machine, and proves them out on the first part.

That is why the question of what industry is CNC machining g used in has a broad answer. Every sector that buys machined metal is running G-code somewhere in its supply chain. The difference between sectors is not the language. It is the tolerance band, the material, the volume, and the amount of evidence the buyer wants with each shipment.

A quick example. An aluminium bracket for an automation frame and an aluminium bracket for a satellite panel may look identical in a CAD file. One ships with a dimensional report and a material cert. The other needs full traceability, first-article inspection, and a locked process. The G-code is similar. The surrounding work is not.

We run 127 high-precision CNC machines across three wholly-owned plants, including 16 simultaneous 5-axis machining centers. Programs are posted per machine, and the first article is inspected before the run continues.

• 1
  G01 / G02 / G03Linear and arc moves. Most profile milling and turning is built from these three.
• 2
  G81–G89Canned drilling and tapping cycles. They cut programming time on hole patterns.
• 3
  M-codesMachine functions: spindle on, coolant on, tool change, program stop.
• 4
  Work offsetsG54 to G59 set part zero. On multi-fixture setups each offset holds a different position.

Aerospace is the sector most people name first, and for good reason. Airframe brackets, engine mounts, actuator housings and interior hardware all have to hold shape under vibration and thermal cycling. Wall thickness is often 1.0–2.0 mm, and a thin rib that deflects during cutting will not pass inspection.

The materials push the process too. Ti-6Al-4V, 17-4PH stainless and 7075 aluminium all work-harden or move under heat. Tool paths need to keep radial engagement steady, and roughing passes often run at lower surface speed than the same feature in 6061. A programmer who has only cut aluminium will burn tools on titanium.

What separates aerospace from general machining is documentation. A typical job needs a material certificate tied to the heat number, a dimensional report, and often a first-article inspection report. Any process change after approval has to be re-verified. That is why suppliers in this sector hold a quality system built around traceability.

Parts that suit 5-axis work here are the ones with compound angles, deep pockets, or features on five faces of one block. If the part is a simple plate with holes, 3-axis milling is faster and cheaper. Do not buy 5-axis time for a part that does not need it.

• 1
  Typical tolerance±0.005 mm on critical bores and mating faces.
• 2
  Common materialsTi-6Al-4V, 7075, 17-4PH, Inconel.
• 3
  Watch forThin walls that spring back. Rough, stress-relieve, then finish.
• 4
  DocumentationMaterial certs, dimensional reports, first-article inspection on request.

Automotive work splits into two very different buckets. Prototype and low-volume jobs run like any other machine shop job: one fixture, one program, a handful of parts. Production jobs run on cycle time, and a few seconds per part decides whether the quote is competitive.

EV adds a newer set of parts. Battery module housings, busbar supports, motor end plates and inverter cold plates. Many of these need flatness control across a large face, and some need leak-tight sealing surfaces. A face that is flat to 0.05 mm over 300 mm is a different problem from a bore held to ±0.005 mm.

This is where IATF 16949:2016 matters. The standard is built around defect prevention and continuous improvement, not just inspection at the end. A supplier holding it has a documented process for control plans, error-proofing and corrective action. Buyers in this sector usually ask for it before the first PO.

Material choice is usually practical. 6061 and 6082 for housings, 4140 and 4340 for stressed shafts, ADC12 for die-cast parts that need secondary machining. Hardened steel parts often need a pre-hardened blank so the finished geometry survives heat treat.

• 1
  Typical tolerance±0.01 mm on bores, flatness 0.05 mm over 300 mm on sealing faces.
• 2
  Common materials6061-T6, 6082, 4140, 4340, ADC12.
• 3
  Watch forCycle time creep. A tool change added for convenience can cost seconds per part.
• 4
  DocumentationControl plan, PPAP-style records, capability data on key characteristics.

Medical work is a mix of instruments, implant trials, surgical tooling and device housings. The parts are often small, with features that a human hand will touch or that will sit inside a patient. Surface finish and edge condition get more attention than raw tolerance in many jobs.

Stainless dominates: 303 and 304 for general parts, 316L where corrosion resistance matters, 17-4PH where strength is needed. Titanium TA2 and TC4 show up in instruments and trial implants. These materials smear rather than chip if the feed is too light, so a programmer has to keep the chip load up.

Cleaning and handling are part of the process, not an afterthought. Burrs on a surgical guide are a functional defect. Deburring, tumbling, bead blasting and passivation all have to be scheduled, and the finished part needs to stay clean through packing.

ISO 13485:2016 is the quality system most buyers in this sector expect. It governs design control, traceability and corrective action for medical devices. If a job needs it, ask early, because it affects how records are kept from the first cut.

• 1
  Typical tolerance±0.005 mm on mating features, Ra 0.2–0.8 μm on contact surfaces.
• 2
  Common materials303, 316L, 17-4PH, TA2, TC4.
• 3
  Watch forBurrs on internal edges. Specify deburring on the drawing, not in an email.
• 4
  DocumentationMaterial certs, finish reports, cleaning and packing method stated.

This is the broadest bucket and the one most job shops live in. Robot arm links, end-effector plates, gearbox housings, linear stage brackets, sensor mounts, conveyor components. Volumes range from one prototype to a few thousand units a year.

Designs here change often. A bracket that was fine on revision C may need a new hole pattern on revision D. That favors shops that can turn a quote and a DFM note around quickly rather than ones that need a long setup window. It also favors modular fixturing, because a new fixture for every revision eats the margin.

Materials are mostly practical: 6061 and 7075 aluminium for weight, 1018 and 1045 steel for wear parts, 304 for washdown areas, POM and PEEK for insulators and low-friction guides. Finishing is often anodizing for aluminium and black oxide for steel.

The engineering question here is usually stiffness versus weight. A robot arm link that is too flexible shows up as vibration at the tool tip. Adding material fixes stiffness but raises inertia, which costs motor torque. Machining lets you put material only where the bending moment is high.

• 1
  Typical tolerance±0.01 mm to ±0.02 mm, with tighter bands on bearing bores.
• 2
  Common materials6061, 7075, 1018, 1045, 304, POM, PEEK.
• 3
  Watch forRevision churn. Freeze the interface dimensions before cutting metal.
• 4
  DocumentationDimensional report on critical features; full inspection on request.

Electronics work covers heat sinks, RF housings, connector bodies, test fixtures and thermal spreaders. Many parts are flat and thin, which makes them hard to hold. A 1.5 mm thick copper spreader will bow if the vise clamps it flat and then releases.

Copper and brass are common here: C101 and C110 for conductivity, C36000 for machinability, beryllium copper where spring properties matter. Copper is gummy and grabs the tool, so sharp edges and generous coolant flow matter more than raw spindle speed.

New energy overlaps heavily. Battery tray components, busbars, cooling plates, inverter housings and charging connector parts. Aluminium and copper dominate, and many parts need a conductive or insulating finish. Hardcoat anodizing is non-conductive; conductive anodizing or a masking step keeps the ground path.

Flatness and burr control are the two recurring problems. Vacuum fixturing or a sacrificial backing plate usually beats vise clamping on thin stock. Deburring has to be planned, because a burr inside a connector body can short a contact.

• 1
  Typical tolerance±0.02 mm on thickness, flatness 0.05 mm on thin plates.
• 2
  Common materialsC101, C110, C36000, 6061, 5052.
• 3
  Watch forClamping distortion on thin stock. Use vacuum or low-pressure fixturing.
• 4
  DocumentationFlatness measurements, finish type and masking notes on the drawing.
