Plasma cutting melts metal with a constricted arc. Gas blows through a nozzle at high speed, the arc raises the workpiece above its melting point, and the gas jet pushes molten metal out of the kerf. The cut is electrically conductive by definition, so carbon steel, stainless steel, aluminum, and copper all work. There is no focused beam to align, which is why a plasma torch handles 20 mm plate the way a laser handles 2 mm sheet.

Laser cutting removes metal with a focused beam instead. CO2 and fiber sources both couple energy into a small spot, and the assist gas, usually oxygen or nitrogen, does the ejection. The beam stays narrow, so the kerf stays small. That small kerf is the reason a laser can cut a 2 mm hole in 3 mm stainless and a plasma torch cannot.

The practical split follows from those two mechanisms. Plasma is a high-energy, wide-kerf, high-heat process. Laser is a low-energy, narrow-kerf, low-heat process. Every other difference on this page, from edge finish to nesting efficiency, grows out of that one contrast.

A plasma cut leaves a slightly beveled top edge and a rougher face, with dross on the bottom of thicker plate. On 6 mm carbon steel the cut face typically sits around Ra 12–25 μm. That is fine for brackets, base plates, and weldments where the edge never gets seen or measured. It is not fine for a visible trim piece or a mating face.

Laser cut edges come off the table much cleaner. On 3 mm stainless with nitrogen assist you get a bright, oxide-free edge around Ra 3–6 μm, often good enough to leave as-is. Oxygen assist on carbon steel gives a slightly oxidized edge but still a square, consistent face.

Kerf width drives the rest. Plasma removes 1.5–3 mm of material per cut, so a part with a lot of internal cutouts loses more stock and nests less tightly. Laser removes 0.1–0.5 mm, which is why laser parts often need no deburring and why two laser parts can share a 0.6 mm gap on the nest.

Secondary operations follow the same logic. Plasma parts usually need grinding, filing, or a tumbling pass before powder coating, because dross and roughness show through a thin finish. Laser parts often go straight to the brake or the welder.

• 1
  Plasma edgeBeveled top, rougher face, dross on plate over 8 mm
• 2
  Laser edgeSquare and clean, nitrogen assist gives oxide-free stainless
• 3
  Kerf penaltyWide kerf means more stock loss and looser nesting

Thickness is the first filter. Plasma stays economical from roughly 6 mm up to 50 mm carbon steel, and it cuts stainless and aluminum in that same band, with a somewhat rougher edge. Below 3 mm, plasma becomes awkward: the arc is hard to keep stable, the kerf is a large fraction of the part feature, and heat distortion starts to matter.

Laser works the other way. It owns the range from 0.5 mm to about 6 mm, where speed is high and the edge is clean. Fiber lasers push carbon steel to 20 mm and stainless to 15 mm, but cutting speed drops sharply and the cost per meter climbs. At 12 mm stainless, a plasma torch is usually the cheaper cut.

Material matters too. Copper and brass reflect laser light at some wavelengths, so a fiber laser needs more power to cut them; plasma handles them without that concern. Aluminum forms a refractory oxide that resists laser cutting, so aluminum over 6 mm usually goes to plasma or waterjet.

One more point on thin stainless: plasma can leave a nitrided layer that complicates later welding or passivation. If the part is a medical or food-contact panel, that is a real reason to stay with laser.

Plasma puts a lot of heat into the plate. The heat-affected zone on 10 mm carbon steel runs 5–15 mm wide, and thin or long parts can bow or twist as they cool. You can manage it with a water table, faster travel, and smart sequencing, but you cannot remove it. A 1,500 mm long plasma-cut strip often needs a straightening pass before machining.

Laser heat input is much lower. The HAZ on 3 mm stainless is under 0.5 mm, and a well-nested thin part comes off flat. That is why laser is the default for enclosures, brackets with tight flatness, and any part that feeds a press brake.

Hole accuracy follows the same curve. Plasma gives a minimum hole around 1.5 times thickness, and the hole edge carries taper. Laser holds holes near 0.5 times thickness, so a 3 mm hole in 3 mm steel is routine. If your drawing calls for a 4 mm hole in 6 mm plate, plasma will need a drill pass and laser will not.

Tolerance is the last piece. Plasma on mild steel typically holds ±0.5 mm; laser holds ±0.1 mm on thin sheet. For parts that later get CNC machined to ±0.005 mm, that difference only matters in how much stock you leave for the finishing cut.

• 1
  Plasma HAZ5–15 mm on thick plate, watch long thin parts
• 2
  Laser HAZUnder 0.5 mm on thin sheet, parts stay flat
• 3
  Hole rulePlasma 1.5× thickness, laser 0.5× thickness

Cutting cost per meter is not a single number. It depends on thickness, material, gas, and how much of the nest is scrap. On 20 mm carbon steel, plasma wins clearly: lower energy per meter, faster travel on thick plate, and cheaper consumables. On 1.5 mm stainless, laser wins on speed and on the fact that no cleanup is needed afterward.

Volume changes the picture as well. For a one-off weldment base, plasma plus a deburring pass is usually the lowest total cost. For a 2,000-piece bracket run, the laser's tighter nest and cleaner edge often beat plasma on total cost even though the hourly rate is higher.

Nesting efficiency is easy to overlook. A plasma kerf of 2 mm forces wider part spacing and more skeleton scrap. A laser kerf of 0.3 mm lets you pack parts closer, which can recover several percent of sheet usage on a dense nest.

The honest answer is that the crossover point sits somewhere between 6 mm and 10 mm, and it moves with your part geometry. If you are unsure, quote both processes on the same drawing and compare the total, including secondary work.

Plasma and laser are not competitors on every part. A common pattern on heavy equipment is plasma for the thick structural plate and laser for the thin covers that bolt onto it. Each process cuts what it is good at, and the assembly still meets its tolerance where it matters.

Another pattern: laser for the blank, CNC machining for the critical features. Laser gives you a flat, accurate blank with a 0.3 mm kerf, then a 3-axis or 5-axis mill cuts the bores, faces, and slots to ±0.005 mm. This is how a lot of our work arrives, and it removes the hand-fitting step that rough plasma blanks usually need.

For prototypes, laser is the safer default. We run no minimum order quantity, from one prototype to 10,000+ part runs, and a laser blank reaches the mill faster than a plasma blank that needs straightening first.

If the final part needs a fine finish, remember the edge you start with. Anodizing, powder coating, and plating all show the surface underneath. A laser edge takes a thin coating evenly; a plasma edge often needs a mechanical prep pass first, which adds a step to your routing.
