CNC: Totally Change Your Production

• 1
  Key takeaways
• 2
  What the extra rotary axes actually change
• 3
  Why setup count, not cutting speed, sets the cost
• 4
  Where multi-axis machining pays off, and where it does not
• 5
  How we decide between 3-axis, 4-axis and 5-axis
• 6
  How you verify that the change actually happened
• 7
  How a part moves from quote to finished shipment
• 8
  3-axis, 4-axis or 5-axis: which one fits the part

A 3-axis mill moves the tool in X, Y and Z. The work stays where the fixture put it. A 5-axis machine adds two rotary axes, usually A and C on a trunnion table or A and B on a swivel head. The tool can now tilt and the part can rotate under it. That single change is what lets a cutter reach five faces in one setup instead of five.

The practical effect is geometric, not cosmetic. On a curved surface, a ball nose cutter that runs at a fixed angle leaves a scallop pattern. Tilt the tool so the cutting edge meets the surface at a shallow angle and the same stepover produces a flatter floor. Tool marks drop. On many surfaces we can hold Ra 0.8–1.6 μm straight off the machine and skip a second finishing operation.

The second effect is reach. Undercuts, deep pockets with drafted walls, and ports that meet a bore at an angle are all reachable when the tool can lean. On a 3-axis machine these features need a special cutter, an angled fixture, or an EDM step. Each of those adds a setup, and each setup adds a chance to lose position.

None of this is free. Rotary axes add stack-up error, and a trunnion table takes up work envelope. A 5-axis machine also needs more careful programming to avoid collisions. That is why the decision should follow part geometry, not the machine brochure.

• 1
  Rotary axes move the part or the headTrunnion tables rotate the work; swivel heads rotate the spindle.
• 2
  One setup keeps one datumPosition between features comes from the machine, not from a fixture re-clamp.
• 3
  Tilt angle controls surface finishA shallow contact angle spreads the cut and flattens the scallop.

Ask most shops what drives cost and they say spindle time. On complex parts that is usually wrong. A part with six faces and four tolerance callouts may run 40 minutes of actual cutting but spend three hours moving between fixtures, vises and machines. Every move carries a re-clamp, a re-probe, and a scrap risk.

Collapsing five setups into one removes most of that overhead. It also removes the error that creeps in each time a part is re-clamped. When a bore and a mating face are cut in the same setup, the position between them depends on the machine's accuracy, not on how well a vise repeated. That is where a ±0.005 mm callout becomes achievable instead of optimistic.

There is a second-order gain that is easy to miss. Fewer setups means fewer WIP piles on the floor. Parts move from raw stock to finished in one flow, so the queue time between operations disappears. For a 200-piece run, the calendar time often matters more than the unit price.

CNC totally change your production most clearly on parts that would otherwise need three or more operations. If a part already runs on one 3-axis setup with a simple vise, moving it to a 5-axis center buys nothing and costs more per hour.

• 1
  Count setups before you count minutesThree setups usually cost more than the cutting tool does.
• 2
  Re-clamping adds errorEach clamp repeats within its own tolerance, and those add up.
• 3
  Less WIP means shorter flowParts stop waiting in a queue between operations.

Hard, gummy, or expensive materials reward the single-setup approach most. Titanium Ti-6Al-4V and Inconel cut slowly and work-harden if the tool rubs. A tilted cutter keeps the engagement constant, which reduces rubbing and lets the insert last longer. On 17-4PH stainless and 7075 aluminium the gain is mostly in feature position rather than tool life.

Thin-walled parts are a separate case. A wall 0.8 mm thick will deflect under cutting force no matter how many axes you have. Five-axis helps here only if it lets you approach the wall from both sides without re-fixturing, which spreads the load. Otherwise the answer is a support fixture or a different process.

Very large parts hit a different limit. Our largest travel is 4,000 × 400 × 150 mm on the large frame, and rotary tables top out at Ø400 mm. A part longer than that cannot spin on a trunnion. It can still be machined on a 4-axis mill with the part indexed, or on a large 3-axis machine with multiple setups.

Soft plastics behave differently again. PEEK and POM machine cleanly, but they move with temperature and clamp pressure. On these parts the axis count matters less than the fixturing and the coolant strategy. A 3-axis machine with a well-designed soft jaw often beats a 5-axis machine with a generic vise.

• 1
  Good fitTitanium, Inconel, 17-4PH, complex contoured surfaces, angled ports.
• 2
  Poor fitFlat plates, simple turned parts, thin walls without support.
• 3
  Size limit4,000 mm max travel; Ø400 mm max rotary table.

We start with the drawing, not the machine list. The first question is how many distinct tool directions the part needs. If the answer is one, it runs on a 3-axis machine. Two or three directions on a part that fits a rotary table usually go to a 4-axis mill. Only when the part needs four or more directions, or a continuously tilting tool path, do we quote 5-axis.

The second question is tolerance stack. If two features on opposite faces carry a tight position callout, cutting them in one setup removes the fixture from the error chain. That alone can justify the higher hourly rate. If the callouts are loose, a second setup is cheaper.

The third question is volume. For one prototype, programming time dominates, so a simpler process is often faster to first part. For a 10,000-piece run, a purpose-built fixture on a 3-axis machine can beat 5-axis on cycle time. We quote both when the answer is close.

Our shop runs 127 high-precision CNC machines, including 16 simultaneous 5-axis machining centers, 12 four-axis mills, 27 three-axis machines and 16 mill-turn centers. That mix matters because it lets us match the process to the part instead of forcing every job onto the newest machine.

• 1
  Count tool directionsOne direction, 3-axis. Two or three, 4-axis. Four or more, 5-axis.
• 2
  Check the tolerance chainTight cross-face position favors one setup.
• 3
  Match process to volumePrototypes favor simple setups; long runs favor dedicated fixtures.

A process change is only real if you can measure it. We inspect 100% of parts before shipment, starting with a raw material check, then in-process monitoring, then a final inspection. Reports are available on request. On a first article, we compare the CMM result against the drawing and flag every callout that is close to its limit.

For multi-axis work, the useful check is feature-to-feature position across faces that were once cut in separate setups. If the old process held ±0.05 mm between a bore and a mating face, and the new one holds ±0.01 mm, that change shows up in the report and in the assembly fit.

Surface finish is the second measurable item. A tilted cutter usually improves the floor finish on contoured surfaces. We record Ra on the drawing callouts so you can see whether the change moved the number. Typical bands are Ra 0.2–0.8 μm for fine finishing, Ra 0.8–1.6 μm for high-quality finishing, and Ra 1.6–3.2 μm as-machined.

Qualification rate across our production runs sits at 99.99%. That number is a shop average, not a promise for a specific part. The honest way to read it is as a sign that the process control is in place, not as a guarantee on your drawing.

• 1
  Inspect across facesThe gain from one setup shows up as tighter feature-to-feature position.
• 2
  Record the finishCompare measured Ra against the drawing callout, not against memory.
• 3
  Ask for the reportInspection reports are available on request.
