5 Essential CNC Max Tips to Slash Production Costs

Most of the cost in a machined part is fixed the moment the drawing is released. Tool selection, the number of setups, and cycle time all follow from geometry. Once a design reaches the machine, the shop can only trim a few percent. Changing the drawing is where the real money sits.

The cheapest change is a corner radius. A pocket with a 0.1 mm internal corner needs a custom-ground tool and slower feed rates; a 0.5 mm radius runs with standard tooling. In aluminum, radii between 0.5 mm and 3 mm cover most pockets without extra cost. Deep pockets with a depth-to-width ratio above 4:1 force long, thin tools that chatter, so the shop has to reduce feed.

Wall thickness is the second lever. Aluminum walls below 0.5 mm vibrate and often need two or three finishing passes. A wall of 1.5–3 mm machines cleanly in one pass and still holds stiffness. Stainless steel behaves better at 1–2 mm because it work-hardens and deflects less than thin aluminum.

• 1
  Standard radiiSpecify 0.5–3 mm internal corners instead of sharp or sub-0.2 mm corners.
• 2
  Wall thickness1.5–3 mm for aluminum, 1–2 mm for stainless steel.
• 3
  Tolerance zonesMark only the features that need tight limits, not the whole drawing.
• 4
  AccessLeave room for the tool holder; undersized openings block the cutter.

Every extra decimal place adds inspection time and machine time. Going from ±0.1 mm to ±0.01 mm on a feature can double or triple the cycle time for that operation, because the shop has to take lighter cuts, control temperature, and measure more often. In most assemblies only a small share of dimensions actually drive fit or function.

A practical approach is to sort features into three groups. Critical fits get tight limits. Datum and mounting faces get medium limits. Clearance holes and cosmetic surfaces get general limits. A drawing with three tolerance classes costs less to make than one with a single tight limit applied everywhere, and it is easier for the shop to inspect correctly.

GreatLight holds ±0.005 mm where the function demands it and inspects 100% of parts before shipment. That capability is not free, so it should be pointed at the features that need it. Our engineers review drawings and flag limits that look tighter than the application requires.

Material is often the largest single line in a machined part quote. The choice affects price twice: once at the bar or plate, and again in how fast the cutter can run. A free-machining grade can cut cycle time by a third compared with a tougher alloy that was chosen out of habit.

Aluminum 6061-T6 is the default for structural parts because it machines fast, welds, and anodizes well. Switch to 7075 when you need higher strength, but expect slower speeds and higher tool wear. For stainless, 303 turns easily and suits shafts and fittings; 304 and 316 resist corrosion better but work-harden, so feeds and speeds must be dialed in. 17-4PH gives high strength after heat treatment and is common in aerospace and medical work.

Stock shape matters as much as grade. A part cut from bar stock near net shape wastes less metal than one carved from a thick plate. When a design allows a standard plate thickness instead of a custom size, both material cost and lead time drop.

• 1
  Aluminum6061-T6 for general parts; 7075 when strength outweighs cycle time.
• 2
  Stainless303 for machinability, 304/316 for corrosion, 17-4PH for strength.
• 3
  Steel1018 and 1045 for general work, 4140 when toughness is needed.
• 4
  TitaniumTi-6Al-4V and Inconel cut slowly; reserve them for real need.

Five-axis machining is usually sold on complex geometry. The bigger saving is setup reduction. Every time a part moves to a new fixture, you add load and unload time, you add a chance of runout, and you add inspection. A part with features on four faces can often be finished in a single 5-axis setup, which removes two or three of those steps.

The gain shows up on parts with angled holes, contoured faces, or pockets that open onto more than one side. On a simple flat bracket, a 3-axis machine is faster and cheaper, so a shop that pushes 5-axis work for everything is not helping you. The right question is how many setups the part needs, not how many axes the machine has.

GreatLight runs 16 simultaneous 5-axis machining centers, 12 four-axis mills, 27 three-axis machines, and 16 mill-turn centers. Mill-turn is worth asking about when a part is round with milled flats or cross-holes, because turning and milling happen without a second fixture. Maximum processing size is 4,000 mm, with travels from 500 × 310 × 200 mm up to 4,000 × 400 × 150 mm.

A low hourly rate means little if the first article is wrong or the tenth shipment is late. Ask what happens between raw material and final inspection. A shop that checks incoming stock, monitors in-process, and inspects before shipment catches problems early, when rework is cheap. Scrap found at final inspection is expensive for everyone.

Certifications are a useful filter. ISO 9001:2015 covers general quality systems. IATF 16949:2016 applies to automotive work. ISO 13485:2016 covers medical devices. ISO 27001:2022 covers information security, which matters if your drawings are sensitive. If your industry needs one of these, confirm the shop holds it before you send files.

Also check capacity range. A shop that can only run small parts will outsource your large housing, and you lose visibility. GreatLight has 127 high-precision CNC machines across three wholly-owned plants totaling 7,600 m², with 150 technicians and 15 years in business. That range covers prototypes and 10,000+ part runs without changing suppliers mid-program.

• 1
  Inspection planRaw material check, in-process monitoring, final inspection.
• 2
  ReportingAsk for dimensional reports on critical features.
• 3
  CertificationsMatch the list to your industry requirements.
• 4
  Capacity fitConfirm the shop can make your largest and smallest parts.

Setup is a fixed cost per run. Spreading it over more parts lowers unit price, but only up to the point where you are paying for inventory you do not need yet. A good rule is to order enough to cover demand plus a reasonable buffer, and to keep the same revision in one run so the setup is not repeated.

Timing matters too. When a shop has capacity and material in stock, a run starts faster. When your order arrives during a peak and needs a special alloy, it waits. Sending the drawing early for a DFM review costs nothing and often removes a feature that would have added a week.

At GreatLight, quotation and a free DFM analysis come back within 12 hours. Production can start within 24 hours, and parts ship in 3–5 days. There is no minimum order quantity, so a single prototype and a 10,000+ part run go through the same process. Historical late-delivery probability is below 2%.
