A supplier can hit ±0.005 mm on one part and miss it on the next fifty. The difference is usually thermal drift, worn tooling, or a fixture that shifts when the operator reloads it. Ask what changes between the first article and the last part of a run.

Repeatability comes from three things: a machine that holds its geometry, a fixture that locates the part the same way every cycle, and a measurement loop that catches drift before the whole batch is cut. A shop with 16 simultaneous 5-axis centers and a Ø400 mm rotary table can hold position on complex angles, but only if the workholding is planned for it.

For parts with bores, bearing seats, or mating faces, roundness and position matter as much as size. A 0.005 mm diameter tolerance means little if the bore is oval. Ask which features are checked with a CMM and which are checked with hand tools. On a 10,000-part order, the answer tells you how much of the quality claim is real.

One practical test: send a drawing with two or three tight features and a wider tolerance on everything else. See if the quote separates them or treats the whole part as one precision class. Shops that quote by feature understand where cost lives.

• 1
  First article vs last partAsk for measurements at the start and end of the run, not just the start.
• 2
  Feature-level quotingTight features should be priced and inspected separately from loose ones.
• 3
  Metrology listCMM for position and form, micrometers and bore gauges for size.

Final inspection catches bad parts. In-process inspection prevents them. The difference shows up in scrap rate and in how quickly a problem is found. A shop that monitors dimensions during machining can stop a drift within a few parts. A shop that checks at the end finds it after the whole batch is finished.

Raw material is the first gate. Hardness, grade, and condition should be checked before the first cut, because a bad bar of 7075 or 17-4PH will machine to the wrong size no matter how good the program is. The second gate is in-process monitoring on critical dimensions. The third gate is final inspection before shipment.

Ask what happens when a dimension drifts out of tolerance. Is the batch quarantined, reworked, or shipped with a deviation note? A supplier with 100% inspection before shipment and reports on request will have a clear answer. If the answer is vague, the process is vague.

Inspection reports should be readable by your quality team, not just a checkbox. Dimension, nominal, actual, and the tool used. If a report cannot be matched to the drawing, it does not help you accept the parts.

• 1
  Three gatesRaw material check, in-process monitoring, final inspection before shipment.
• 2
  Deviation handlingAsk how out-of-tolerance parts are quarantined and what you are told.
• 3
  Report formatDimension, nominal, actual, tool. Traceable to the drawing revision.

A certificate is a scope document, not a badge. ISO 9001:2015 covers a general quality system. IATF 16949:2016 adds automotive production requirements, including traceability and failure analysis. ISO 13485:2016 is written for medical devices. ISO 27001:2022 covers information security, which matters if your CAD files are confidential.

Match the certificate to the part, not to the company. An automotive bracket on a production line needs IATF 16949. A surgical instrument housing needs ISO 13485 and a clean handling routine. A prototype for an aerospace bracket can run under ISO 9001, but the inspection plan still needs to be clear.

Check the scope statement. Some certificates list only certain processes or locations. If your part is machined in Dongguan but the certificate covers a different site, ask which site will run the work. A supplier with three wholly-owned plants should be able to tell you exactly where your parts will be cut.

ISO 27001 is often overlooked by buyers. It covers how your drawings, models, and revision history are stored and who can open them. For defense-adjacent or unreleased consumer products, that matters as much as dimensional quality.

• 1
  Match the scopeConfirm the certificate covers the process and the plant that will run your parts.
• 2
  Industry fitIATF 16949 for auto, ISO 13485 for medical, ISO 9001 as the base.
• 3
  Data securityISO 27001 and an NDA when your files are confidential.

A quote of 3–5 days for parts is useful only if it applies to your order size and geometry. A simple turned part and a 5-axis housing with deep pockets do not share a schedule. Ask for the lead time by operation: material, machining, finishing, inspection.

MOQ is the other half. No minimum order quantity sounds generous, but it also means the shop must make money on small runs through setup efficiency. That is a good sign if the shop is set up for it. A shop that runs from one prototype to 10,000+ part runs has to be good at both changeover and repeat production.

Historical late-delivery probability below 2% is a more useful number than a best-case date. It tells you how the shop performs across many orders, not just the easy ones. Ask how that figure is tracked and whether it includes finishing delays.

Setup risk is where small orders go wrong. If the first article is approved but the fixture is not documented, the second run starts from scratch. Ask whether the setup sheet travels with the job.

• 1
  Lead time by stepGet separate estimates for material, machining, finishing, and inspection.
• 2
  MOQ realityOne-off and 10,000-part capability are different skills; confirm both.
• 3
  Late rateA below-2% late probability is more honest than a single promised date.

A quotation and free DFM analysis within 12 hours is only valuable if the DFM feedback is specific. Look for comments on wall thickness, tool access, minimum internal radii, and datum selection. General notes like "part looks machinable" add nothing.

Compare quotes on the same basis. Material grade, finish callout, tolerance class, inspection level, and quantity. A low price that omits finishing or inspection is not a lower price. It is a different scope.

Ask whether the shop will flag features that drive cost. A 0.5 mm internal radius in a 40 mm deep pocket needs a small tool and a slow feed. If the design can use a 2 mm radius, the part may cost less without losing function. A supplier that points this out is reading your drawing, not just pricing it.

Production can start within 24 hours once the design is frozen and material is in house. Use the quote stage to test communication speed. Slow, vague answers at quoting usually repeat at production.

• 1
  Specific DFMComments on radii, wall thickness, tool access, and datums, not general praise.
• 2
  Same-scope quotesCompare material, finish, tolerance, inspection, and quantity line by line.
• 3
  Cost driversA shop that flags expensive features is reviewing the design.
