Copper conducts heat away from the cut almost as fast as it conducts current. The heat that would soften a steel chip and let it break instead travels into the tool and the workpiece. Tools stay cool enough to last, but the chip stays ductile. It stretches, folds and wraps around the cutter rather than snapping off. That is the root of most copper scrap.

The second problem is built-up edge. Soft copper welds itself to the cutting edge under pressure. The edge grows a lump, cuts slightly oversize, then sheds the lump and cuts undersize. On a Ø12 mm bore held to ±0.005 mm, that cycle alone can eat your entire tolerance band. Sharp uncoated carbide, positive rake and a heavy flood of coolant break the cycle.

A third issue is that copper work-hardens less than stainless but still moves. Thin walls, long slender shafts and large flat panels relieve internal stress when you remove material. A busbar that measures flat on the machine can bow 0.05 mm overnight. Shops that know this rough close, let the part rest, then finish.

• 1
  Cutting speedHigher surface speed than steel, often 200–400 m/min in carbide for C110.
• 2
  Feed per toothLight and consistent, so the edge cuts rather than rubs.
• 3
  CoolantHeavy flood or high-pressure through-tool, not mist.
• 4
  Tool geometrySharp, polished flutes with high rake; avoid heavy coatings that round the edge.

A shop quoting ±0.005 mm on copper is not lying, but the number applies to specific features. On a rigid setup with a stable alloy, a bored hole or a milled pocket can hold that band. On a 300 mm long, 3 mm thick copper strip, the same shop cannot promise it. Ask which features carry the tight callout and how they will verify them.

Surface finish and tolerance trade against each other. Electrical contacts often need Ra 0.2–0.8 μm to keep contact resistance low, which means a finishing pass with a fresh edge and a light depth of cut. That is slower than a roughing cut, and the quote should reflect the extra pass. If a price looks unusually low for a contact surface, ask what finish they planned.

For most copper parts, Ra 0.8–1.6 μm is a sensible default. It machines quickly, deburrs cleanly and takes plating or silver coating without pitting. Push to Ra 0.2–0.8 μm only where the drawing or the electrical spec demands it, because inspection time rises with the surface requirement.

• 1
  Best caseBored holes, flat faces on rigid fixtures: ±0.005 mm.
• 2
  Typical caseMilled profiles and turned diameters: ±0.013 mm.
• 3
  Difficult caseLong thin walls and unsupported spans: discuss before quoting.

Start with the alloy list. A copper CNC machining service that lists C101, C110, C36000 and beryllium copper in one sentence has probably cut all of them. A shop that says 'copper' with no grade is quoting from a catalogue, not from the floor. Send your grade and temper in the RFQ and see whether the reply mentions it.

Next, ask about the finishing sequence. Copper oxidises and fingerprints easily. If parts need silver or gold plating, electroless nickel or a clear anti-tarnish coat, the machining shop and the finisher must agree on handling, packaging and masking. Shops that plate in-house control that handoff. Shops that outsource need to describe how they protect the surface in transit.

Third, ask what the inspection report contains. Dimensional data with a CMM report, material certificate and finish measurement is standard for regulated work. A shop that inspects 100% before shipment and shares reports on request is easier to audit than one that only ships a packing list.

Fourth, check certifications against your industry. ISO 9001:2015 covers general quality systems. IATF 16949:2016 matters for automotive and EV parts. ISO 13485:2016 matters for medical devices. ISO 27001:2022 matters when your drawings themselves are sensitive. A supplier with all four is set up to handle regulated work.

Fifth, ask about scale. Copper prototypes and 10,000-part runs need different planning. A shop that runs from one prototype to 10,000+ part runs without a minimum order quantity will handle both, but ask how they hold the process stable across a run that large.

The most expensive trap is quoting a copper part as if it were aluminium. The cycle time looks similar on paper, but the deburring, the chip evacuation and the finishing pass add hours. If a quote comes back 30% under the others with no explanation, ask what operations they included.

The second trap is ignoring oxygen content. C101 oxygen-free copper and ordinary C110 look identical on a drawing. If your part runs in a vacuum or carries RF current, oxygen content changes performance. Specify the grade and ask for the material certificate before production, not after.

The third trap is thin-wall geometry sent to a shop without a DFM review. A 0.8 mm copper wall with a tight internal radius will deflect under normal clamping. A supplier that offers a free DFM analysis within 12 hours will flag this before the tool hits the metal. One that accepts the drawing without comment is not doing you a favour.

The fourth trap is packaging. Bare copper parts scratch and tarnish in transit. Ask how they bag, separate and cushion finished surfaces. On visible parts, this is the difference between a passing incoming inspection and a rejected lot.
