Most supplier lists look the same. The differences show up when you put a real drawing in front of them. Start with three numbers from your own part: the tightest tolerance, the largest overall dimension, and the smallest internal feature. Those three numbers eliminate most shops before price even enters the conversation.

Tolerance drives the machine choice. A ±0.005 mm callout on a bore or a bearing seat needs a machine with good thermal behavior, sharp tooling and a controlled inspection loop. On the same part, a general ±0.1 mm profile can run on a three-axis mill without much ceremony. Sending both features to the same shop is fine, but the quote should reflect the difference.

Size is the second filter. GreatLight runs a 4,000 mm maximum processing size, with one envelope of 4,000 × 400 × 150 mm for long frames and rails. Medium work fits 750 × 1,150 × 550 mm or 600 × 600 × 600 mm. Compact housings and fittings run on 500 × 500 × 450 mm and 500 × 310 × 200 mm machines.

If your part has angled faces, deep pockets or undercuts, ask how the shop reaches them. A simultaneous 5-axis center machines a contoured surface in one setup. Repositioning the part on a three-axis machine can work, but each new setup adds stack-up error, and that error lands on the tolerance you care about.

The quote is built from the process route. Milling, turning, mill-turn, EDM, grinding and finishing each add a line. A part that looks simple can still need a second operation for a cross-hole, a thread or a flat that a single spindle cannot reach.

Finish callouts move the number more than most buyers expect. As-machined surfaces sit around Ra 1.6–3.2 μm and come straight off the tool. A high-finish requirement of Ra 0.8–1.6 μm usually means a finishing pass with a smaller stepover. Fine finish at Ra 0.2–0.8 μm may need grinding, lapping or polishing after machining, which adds handling and inspection steps.

Material choice sets tool wear and cutting strategy. Aluminium grades such as 6061-T6, 7075 and 6082 cut quickly and hold a good finish. Stainless 316L and 17-4PH work-harden, so feeds and speeds need care to avoid a glazed surface. Titanium TC4 (Ti-6Al-4V) and Inconel demand slower cutting and more tool changes, and that shows up in cycle time.

Ask for the route in writing. A quote that lists operations, machines and inspection points tells you where the risk sits. A single line item that says 'CNC machining' does not.

• 1
  One setup if you canFewer setups mean less stack-up error on tight features.
• 2
  Match finish to functionSealing faces and bearing seats need the fine callout; covers usually do not.
• 3
  Flag hard materials earlyTitanium and Inconel change tooling and cycle time, so they change the quote.

Certificates are not decoration. Each one answers a different question. ISO 9001:2015 covers a quality management system across general production. IATF 16949:2016 is the automotive and EV standard, with its own emphasis on traceability and change control. ISO 13485:2016 applies to medical device manufacturing. ISO 27001:2022 covers information security, which matters when your CAD files leave your network.

Match the certificate to the sector your part ships into, not to the shop's marketing page. A robotics bracket may only need ISO 9001. A brake or powertrain component usually needs IATF 16949. A surgical instrument housing needs ISO 13485. If your drawings and models are sensitive, ISO 27001 is the one that speaks to how they are stored and shared.

Inspection is the other half. Ask what happens between raw material and the shipping box. At GreatLight, incoming material is checked, in-process dimensions are monitored, and every part is inspected before shipment. Reports are available on request. A 99.99% qualification rate sounds impressive on a slide, but the useful question is which features are measured and with what instrument.

For tight work, ask for a first article inspection report on the initial run. It shows the actual measured values against your nominal dimensions and tolerances. That single document tells you more about a shop than any equipment list.

Lead time claims are easy to make and hard to verify. Ask for the sequence instead of a single number: when the quote arrives, when production starts, when parts ship. GreatLight quotes and returns free DFM analysis within 12 hours, can start production within 24 hours, and ships parts in 3–5 days. Historical late-delivery probability sits below 2%.

MOQ is a signal about how a shop organizes work. A supplier with no minimum order quantity can take one prototype and then scale to 10,000+ part runs without changing the process plan. If a shop pushes a tooling fee before it will cut a sample, you are looking at a different production model, and the prototype may not represent the final part.

The quotingscope matters too. A good quote separates material, machining time, finishing, inspection and any special tooling. If finishing is bundled into one number, you cannot tell whether anodizing or bead blasting is driving cost. Ask for the split before you compare two suppliers.

Confidentiality belongs in this section as well. Uploads should be treated as secure and confidential, and an NDA should be available on request. If a supplier will not sign one, that tells you something about how they handle customer drawings.

Machining is the right route when you need dense, load-bearing geometry with tight tolerances and a defined surface finish. Bearing housings, manifolds, brackets, heat sinks, robot joints and medical instrument bodies all fall into this group. The material can be aluminium, stainless, steel, copper alloys, titanium or engineering plastics such as POM and PEEK.

It is the wrong route when the part is a thin, large panel with simple bends. Sheet metal fabrication is faster and cheaper there. Die casting wins on high-volume parts with stable geometry and moderate tolerance. Vacuum casting and 3D printing make sense for early concept shapes where surface finish and material properties are secondary.

Many projects use more than one route, and that is normal. A housing might start as a machined prototype, move to die casting for volume, and come back to machining for the sealing face. A supplier that runs several processes can advise on the switch instead of defending one method.

The practical test is simple. If the function depends on a dimension that must be held within a few microns, or on a material with specific mechanical properties, machining is usually the answer. If the function depends on a folded edge and a paint finish, it probably is not.
