A 3-axis CNC milling machine moves the cutter in three linear directions. X and Y position the tool across the table, Z controls depth. The spindle axis stays vertical, so the tool always approaches the workpiece from one direction.

That single approach direction defines everything else. Any surface you can see from straight above the part, the tool can reach. Undercuts, side holes, and pockets that open sideways stay invisible to the cutter unless you re-fixture the part.

This is why 3-axis work is usually described as 2.5D. A pocket may have three different floor depths, but each depth is still reached from above. True 3D contours appear only when the Z height changes continuously along a curved path, which a ball nose tool can follow in fine stepovers.

Depth of cut, stepover, and feed rate all scale with tool diameter. A 10 mm end mill might run 0.5 mm radial stepover on a finishing pass and 3 mm on a roughing pass. Push past those numbers and the tool deflects, the wall tapers, and the dimension drifts.

So the first question on any new part is simple. Can every feature be reached from one spindle direction? If yes, 3-axis is usually the cheapest and fastest route. If no, you are looking at extra setups or a different machine class.

The cutting edge does not scrape material away. It shears it. Each tooth of the cutter presses into the workpiece until the local stress exceeds the material yield strength, and a chip slides up the rake face.

That chip carries most of the heat with it. On aluminum, cutting speeds of 200–500 m/min are common because the material conducts heat away quickly and the chip leaves fast. On 316 stainless, the same tool might run 60–120 m/min to keep the edge alive.

Heat that stays in the part causes problems. Thin walls grow during cutting, then shrink after cooling, so a bore measured hot can come back undersized. Rough the part, let it cool, then take a light finishing pass.

Tool coatings matter here. TiAlN and AlTiN hold up at higher temperatures, which suits steel and stainless. Uncoated carbide is often the better choice for aluminum because coatings can dull the sharp edge and cause built-up edge.

Feeds and speeds are not fixed values. They come from the tool supplier's data and get adjusted by sound, chip color, and surface finish. A screaming tool is usually running too fast or too light.

A machine that holds ±0.005 mm is only as good as its setup. If the vise lifts the part 0.02 mm when it closes, that error goes straight into the part.

For flat plates, a machine vise with parallel jaws works well. For thin parts, use soft jaws machined to the part profile, or clamp down onto a sacrificial tab. A part that rings when tapped is not held firmly enough.

For the second side, flip the part against a stop or use a fixture plate with dowel pins. Relying on the vise jaw to relocate the part usually costs you 0.05 mm or more in position error.

Coolant choice also affects the setup. Flood coolant controls heat but can move thin parts. Air blast or minimum quantity lubrication often works better on plastics and thin aluminum, though it removes less heat.

We check setups before the first cut. A dial indicator on the stock, a quick probe pass, and a test cut on scrap material catch most problems before a batch is ruined.

Corner radius is the first thing to fix. A cutter cannot cut a sharp internal corner, so the radius in the drawing becomes the radius of the tool. Draw 1 mm corners and the shop must use a small tool, run slower, and charge more.

Pocket depth is the second. A pocket deeper than about four times the tool diameter needs a long, thin tool that deflects. Keep depth under three times the diameter where the design allows.

Threads and hole sizes should come from standard tooling. A 6.8 mm hole for an M8 tap is standard. A 6.5 mm hole forces a custom drill and slows the cycle.

Wall thickness matters too. Below 1 mm, the wall vibrates and the finish suffers. If the part needs a thin wall, add a temporary rib or leave stock for a finishing pass after the rest of the part is done.

Tolerances should be tight only where they function. Calling out ±0.005 mm on every dimension multiplies inspection time without improving the part. Put tight tolerance on the mating features and let the rest run general.

Fillet every internal corner you can. It spreads stress, helps the tool, and usually costs nothing.

Chip shape is the fastest indicator. Aluminum should produce short, curled chips that break cleanly. Long stringy chips mean the feed is too low for the speed. Fine powder means the tool is rubbing, not cutting.

Sound is next. A stable cut has a steady hum. A rhythmic knock usually points to chatter, which comes from tool overhang, weak workholding, or a speed that matches a natural frequency of the setup.

Surface finish tells you the rest. A Ra 1.6–3.2 μm as-machined finish is normal for a roughing-plus-finishing cycle. Getting to Ra 0.8–1.6 μm takes a lighter finishing pass and a sharper tool. Below Ra 0.8 μm, most shops move to a different process or a polishing step.

Measurement closes the loop. A caliper is fine for rough checks, but bores and mating features need a micrometer or a bore gauge. For production runs, a coordinate measuring machine confirms the first part and spot-checks the rest.
