A 3-axis mill moves the tool in X, Y and Z. The workpiece stays bolted to the table, so any feature on a side face needs a second setup. A 4-axis machine bolts the part to a rotary table instead. That table turns the workpiece about one linear axis, and the spindle reaches the newly exposed face without anyone touching the clamps.

The rotary axis is usually the A-axis, turning about X. On a horizontal mill it may be the B-axis, turning about Y. Both do the same job: they index the part to an angle and hold it there while the tool cuts. A few machines interpolate rotary motion during the cut. Most production work indexes between cuts instead.

Where the fourth axis earns its cost is the setup count. One rotary fixture replaces three or four vises and angle plates. Every time a part moves between fixtures, the stack of small errors grows. Turning the part in place removes those resets. It also keeps the operator away from a re-clamped, half-finished part, which is where most scrapped parts come from.

There is a limit worth stating up front. The fourth axis rotates about one line only. A hole on the end face and a slot on the side are both reachable. A hole angled 30° off the end face, on the same part, needs a second setup or a different machine. That boundary decides most machine choices more than tolerance does.

The term covers two different machines, and buyers often mix them up. A 4-axis mill is a vertical or horizontal machining center with a rotary table. The part turns about a horizontal axis; the spindle stays vertical or horizontal. This is the right machine for a block with features on four sides.

A turning center with a live tool and a C-axis is the other family. The part spins about Z, and a driven tool cuts off-axis features while the part is still in the chuck. Lathe people often call this 4-axis turning. It is the better answer for a shaft with milled flats, cross holes or a slot near the shoulder.

Cost per part separates them. A mill with a rotary table needs a fixture and a tombstone or a chuck, and cycle time includes indexing moves. A live-tool lathe keeps the part in one chucking, so concentricity between the turned diameter and the milled feature stays tight without a second operation.

Pick by part geometry, not by habit. If the outside is a surface of revolution, start with the lathe. If the part is box-like or a plate, start with the mill. Mixing the two means extra handling and extra error.

On a rigid 4-axis setup we hold ±0.005 mm (±0.0002 in) on critical features. That number is not a property of the machine alone. It is what the whole chain delivers: spindle, fixture, material, tool, and thermal state.

Rotary table error shows up as angular deviation. A 15 arc-second table is off by about 0.000 07 mm per millimeter of part radius. At a 100 mm radius, that is roughly 0.007 mm of position error at the feature. Small parts tolerate a cheaper table; large parts do not.

Chuck runout and part sag are the bigger risk on long work. A shaft held at one end deflects under cutting load, so the feature nearest the chuck cuts to size and the far end drifts. Supporting the free end with a tailstock or a steady rest fixes most of it.

Surface finish follows the same logic. We hold Ra 1.6-3.2 μm as-machined, Ra 0.8-1.6 μm with a finishing pass, and Ra 0.2-0.8 μm on fine work. A rotary axis helps because the tool stays in one engagement direction around the part. Fewer entry marks, fewer witness lines.

The rotary centerline is the new datum. If the part is not centered on that line, every indexed feature shifts by twice the offset. Touch off the rotary center, then set the work offset from it. Do not set the offset from a vise jaw and assume the table is centered.

Clamping force matters more than on a flat table. A three-jaw chuck on a thin-wall ring will ovalize it. The part cuts round, then springs back when the jaws open. A bored soft jaw or a collet closer spreads the load and keeps the wall round.

Balance the fixture before running at speed. An off-center tombstones or an unbalanced chuck puts a load on the table bearings at every index. Keep the fixture mass close to the centerline, and keep RPM conservative during rotary moves.

Program the index moves as rapid-free zones. Retract the tool clear of the part envelope before the table turns. A single missed clearance plane is the most common crash on a 4-axis machine, and it usually costs a fixture and an operator's afternoon.

Keep the rotary as a positioning axis unless the job truly needs simultaneous motion. Index, lock, cut, index. This is simpler to prove out and easier to inspect. Simultaneous 4-axis toolpaths need CAM support and a post processor that outputs the rotary word correctly.

Watch the rotary direction and the shortest path. A 350° move and a -10° move end at the same place but take very different time. Set the post to pick the short way unless a full rotation is needed for a continuous cut.

Coolant and chip evacuation change when the part turns. Chips fall off a vertical face but sit in a pocket that has rotated to the bottom. Aim the coolant at the cut, and add a dwell or an air blast for blind pockets that hold chips.

Prove the first part with the rotary locked and a single index at a time. Once the offsets are right, run the full cycle. This is slower on the first part and much faster on the next fifty.

Aluminium is the easy case. Grades 6061, 6061-T6, 2024, 5052, 5083, 6063, 6082, 7075 and ADC12 all cut well on a rotary table at high spindle speed. The light chips clear easily, so index moves stay clean.

Stainless and steel need more care. Grades 303, 304, 316, 316L, 420, 430, 431, 440C and 17-4PH (SUS630) work harden if the tool rubs. Keep the feed per tooth up, and avoid dwelling on an indexed face. The same rule applies to 1018, 1045, 4130, 4140, 4340, A36 and tool steel.

Titanium and nickel alloys are the slow end. TA1, TA2, TC4 (Ti-6Al-4V), Inconel and magnesium AZ31B or AZ91D generate heat at the cutting edge. Rotary work helps because the tool stays in cut around a diameter, but the speeds stay low.

Finishing options are broad: anodizing (clear, colour, hardcoat, conductive), electroless nickel, zinc, silver and gold plating, powder coating, black oxide, bead blasting, tumbling, brushing and polishing, plus laser marking with a minimum character height of 1.5 mm.
