Matching Tolerances of Bearings and Shafts, Bearings and Holes

A bearing works only if the fit around it is right. Too loose and the ring creeps; too tight and the raceway is squeezed out of round. This page explains how shaft and housing fits are chosen, what changes them, and when the standard tables are the wrong tool.

±0.005 mm toleranceISO 286 fits100% inspection
Matching tolerances of bearings and shafts, bearings and holes
The problem

What a Bearing Fit Actually Does

A rolling bearing is a finished precision component. The inner ring is made to a tolerance class, the outer ring to a tolerance class, and neither is meant to be reworked. What the machine shop controls is the shaft diameter and the housing bore. Those two dimensions decide how the rings sit, and the ring that carries the rotating load must not slip on its seat.

Creep is the slow failure everyone forgets. If the inner ring turns on a shaft that is too small, the ring face polishes the shaft, wear debris enters the grease, and the bearing fails long before its rating life. If the fit is too tight, the inner ring grows and the radial internal clearance drops. The balls get pinched, friction rises, and the bearing runs hot.

So matching tolerances of bearings and shafts is not about hitting one number. It is about picking an interference or clearance band that matches the load, the speed, and the temperature the assembly will see. Get the direction of that band wrong and no amount of bearing quality will save the design.

  • 1
    Rotating load ringNeeds interference so it cannot creep.
  • 2
    Stationary load ringCan be a light fit, sometimes a small clearance.
  • 3
    Split housingUsually a looser outer fit than a solid one.
Mechanism

How Interference Changes Internal Geometry

When you press an inner ring onto a shaft, the ring bore is stretched. The ring does not stay round in the free state; it follows the shaft. Every micrometre of interference becomes a small reduction in radial internal clearance. On a 30 mm bore bearing with a few micrometres of interference, that loss is modest. On a thin-section bearing, it can eat most of the clearance class you paid for.

The outer ring behaves the same way in reverse. A tight housing bore compresses the outer ring and closes the clearance further. That is why a bearing that is tight on both rings can feel smooth by hand and still seize after ten minutes of running. The clearance was already gone before the temperature rose.

Heat adds to this. A steel shaft grows about 11 × 10⁻⁶ per °C. A 40 mm shaft that runs 40 °C above ambient grows roughly 0.018 mm. If the housing is aluminium and grows faster, the outer fit loosens while the inner fit tightens. The fit you measure at 20 °C is not the fit you get at operating temperature.

None of this is a reason to avoid interference. It is a reason to start from the clearance class you need, then work back to the fit that keeps it.

Selection logic

Reading the Shaft and Housing Tables Correctly

ISO 286 gives you letters and numbers: h, j, k, m for shafts, H, J, K, M for holes. Lowercase is a shaft, uppercase is a hole. The number is the tolerance grade, and smaller numbers mean a tighter band. A shaft marked k5 has a tighter band than k6, but both are usually interference fits on a nominal bearing bore.

The first question is which ring rotates relative to the load. Not which part spins. A shaft can spin while the load direction stays fixed, and in that case the inner ring sees a rotating load. But if the load rotates with the shaft, the inner ring sees a stationary load and the outer ring may be the one that needs the interference. Engineers get this backwards more often than any other point on the page.

The second question is how much interference the bearing can take. Bearing catalogs list the recommended shaft and housing tolerances for each series and load case. Those tables already account for the clearance loss. If your application is unusual, such as a thin-walled housing or a plastic housing, the catalog values are a starting point and not an answer.

The third question is what the shop can actually hold. A k5 band on a 30 mm shaft spans only a few micrometres. If the lathe and grinder cannot hold that band repeatably, a nominally correct fit becomes random in production. That is a process question, not a design question.

  • 1
    Lowercase letterShaft tolerance, for example k6.
  • 2
    Uppercase letterHole tolerance, for example H7.
  • 3
    Smaller grade numberTighter tolerance band.
  • 4
    Catalog tableAlready includes clearance loss.
Shop practice

Machining and Measuring the Seat

Turning a bearing seat is not the same as turning a general diameter. The seat usually needs grinding if the band is tight. Turning alone can hold ±0.005 mm on a good machine, but the surface finish matters too. A turned seat at Ra 1.6–3.2 μm is fine for a light fit. A ground seat at Ra 0.2–0.8 μm is what you want under an interference fit, because a rough surface loses metal during assembly and the fit loosens.

Measure the seat, not the shaft end. A shaft can be perfectly round at the outboard end and tapered near the shoulder. Use a micrometer at three positions along the seat and two directions at each position. Record the numbers. A single reading at one spot tells you almost nothing about whether the ring will seat properly.

For housings, check roundness as well as diameter. A three-jaw chuck can leave a triangular bore that a two-point bore gauge will not see. A tight housing that is out of round pinches the outer ring in three places and the bearing runs rough.

Assembly matters at this stage too. Press fits should be done with an arbor press or a controlled temperature difference, not a hammer. Heating a bearing above roughly 120 °C can change its heat treatment and its dimensions. If you need a large interference, heat the housing or cool the shaft, and stay inside the bearing maker's limits.

  • 1
    Ground seatRa 0.2–0.8 μm for interference fits.
  • 2
    Three positionsMicrometer along and around the seat.
  • 3
    Roundness checkTwo-point gauges miss three-lobed bores.
  • 4
    No hammerUse press or controlled temperature.
Boundaries

When the Standard Fit Tables Do Not Apply

The catalog tables assume a solid steel shaft and a rigid, thick-walled housing. Change either and the numbers shift. A hollow shaft deflects more under the same interference, so the effective grip is lower. A thin aluminium housing expands faster than a steel outer ring, so the outer fit loosens when the assembly warms up.

Plastic and composite housings are a separate case. Their creep behaviour means an interference fit relaxes over time, and the outer ring can start to turn. A common answer is a metal insert or a retaining compound, but that is a design decision that has to be made before the parts are cut.

Very small bearings are another boundary. Below about 10 mm bore, the ring section is thin and a normal k6 fit can distort the raceway. Very large bearings go the other way: the interference needed to prevent creep becomes large, and the clearance loss has to be added back into the bearing selection.

High-speed spindles sit at the edge of all this. The fit has to hold the ring at low speed and stay safe at 20,000 rpm, where centrifugal growth and heat both change the geometry. That is a case for a specialist, not a general table.

Verification

Checking the Fit Before You Cut Metal

A few minutes of checking saves a scrapped shaft. First, confirm the bearing part number and its tolerance class. A P6 bearing and a P0 bearing of the same size do not have the same bore deviation, so the same shaft fit does not produce the same result.

Second, calculate the clearance loss. Take the interference you expect, convert it to a diameter change on the ring, and subtract it from the radial internal clearance. If the remaining clearance is below the minimum for your speed and load, the design is too tight.

Third, look at the temperature. Estimate the running temperature of the shaft, the housing, and the bearing. If the difference between them is more than about 20 °C, the cold fit is not the working fit.

Fourth, decide how you will inspect. For a k5 or m5 seat, a hand micrometer is not enough on the shop floor. A bench gauge or a comparator with a setting master gives repeatable readings. Write the inspection method on the drawing so the next batch is made the same way.

Finally, test one assembly before the full run. Press one bearing onto one shaft, check the drag torque, and run it for a short period. The feel by hand is a weak signal, but a change in drag torque after a few minutes tells you the clearance is closing. That is a real failure mode caught early.

Reference

Typical Shaft and Housing Fit Choices by Load Case

Values are common practice for solid steel shafts and cast iron or steel housings. Always confirm against the bearing maker's catalog for the exact series.

Load caseShaft fitHousing fitNote
Inner ring rotating, light loadk5 / k6H7Most common motor shaft case
Inner ring rotating, heavy loadm5 / m6H7Shock loads, gearbox input
Outer ring rotatingh6 / j6K6 / M6Wheel hubs, idler pulleys
Stationary both ringsj6 / h6H7 / J7Light duty, low speed
High speed, light loadj5 / k5H6 / J6Watch clearance loss
Split housingk6H7 / H8Clamp must not pinch the ring
Thin-section bearingj5 / j6J6 / H7Keep interference small
High temperature risek5G7Recheck hot clearance

The Rule to Remember

If the load rotates relative to the ring, put the interference on that ring and keep the other side light. If both rings see rotating load, split the difference and check the hot clearance before you release the drawing.

FAQs

Common Questions on Bearing Fits

Can I use a reamed hole instead of a ground bore for a bearing housing?

A reamed hole can work for a light fit in a soft material, but reaming does not correct position or roundness. For an H7 housing in steel or cast iron, boring and then fine boring or grinding gives a more predictable result. If the housing is aluminium and lightly loaded, a reamed H7 bore is often acceptable, but check roundness before you press the bearing in.

How much interference is too much?

There is no single number, because it depends on the bearing section and the clearance class. The practical limit is the point where the clearance loss pushes the residual radial internal clearance below the minimum for your speed and load. The bearing catalog gives that limit for each series. If you are outside the catalog range, calculate the loss or ask the bearing maker.

Does a tighter fit always mean a better hold?

No. A tighter fit does hold the ring better against creep, but it also removes clearance and can distort the raceway. On thin-section bearings, an over-tight fit causes more failures than creep does. The right fit is the loosest one that still prevents slip under the worst load case.

What surface finish should a bearing seat have?

For an interference fit, aim for Ra 0.2–0.8 μm, usually a ground finish. A rougher turned seat at Ra 1.6–3.2 μm is acceptable for clearance or light transition fits. The risk with a rough seat under interference is that the peaks shear off during assembly, the fit loosens, and the ring starts to creep.

Should the housing or the shaft be heated for assembly?

Heat the part with the larger mass and the looser constraint, usually the housing. Keep the bearing itself below about 120 °C. If you heat a bearing above that, its dimensions and heat treatment can change. For a small interference, a press is simpler and safer than heat.

How do I check a fit on the shop floor without a CMM?

Use a micrometer with a setting master for shafts and a bore gauge for housings. Take readings at three positions along the seat and two directions at each. Compare against the drawing limits. For tight bands, a comparator gives better repeatability than a hand micrometer, especially when several operators are measuring the same batch.
