Micro machining is not standard milling scaled down. The usual line is a feature smaller than 1 mm: slots 0.3 mm wide, holes 0.2 mm across, walls 0.15 mm thick. At that scale the cutting tool is often 0.1–0.5 mm in diameter, and the chip looks like dust.

That changes the physics. A 0.2 mm end mill deflects under very light load. Heat stays near the tip because there is little material to carry it away. Chip evacuation fails easily, so the tool recuts its own debris and snaps. A shop offering micro cnc machining services needs high spindle speed, low runout holders, and a way to clear chips with air or mist.

Common parts include medical needles and implant components, optical housings, fuel injector nozzles, sensor bodies, and connector pins for electronics. Materials range from 6061 and 7075 aluminium to 316L stainless, Ti-6Al-4V, and PEEK. Each behaves differently at small depths of cut, so the shop should be able to name the material it cuts best.

A tolerance figure means nothing without a size range and a feature type. ±0.005 mm on a 10 mm aluminium bracket is a different problem from ±0.005 mm on a 200 mm steel plate, where thermal drift alone can eat the budget. Ask the supplier to state the part envelope and the feature the number applies to.

Finish follows the same rule. Ra 0.2–0.8 μm is realistic on aluminium and brass with sharp tooling and light finishing passes. On 316L or Ti-6Al-4V, the same target needs slower feeds, more tool changes, and often a secondary operation such as polishing or bead blasting. If a quote promises Ra 0.2 μm on titanium with no extra step, ask how.

The practical test is a capability sample. Send a part with the tightest feature on your drawing and ask for a first article report. A shop that can hold the number on a sample can usually repeat it. A shop that cannot will explain why after the order, not before.

Most micro machining failures come from the setup, not the program. A 0.3 mm slot cut in a part held in a standard vise will close up when you release the vise, because the clamping force bends the thin wall. Micro vises, vacuum chucks, and wax or adhesive fixturing hold the part without crushing it.

Tool runout matters just as much. A holder with 10 μm of runout puts the entire load on one flute of a 0.2 mm cutter. High-speed spindles with shrink-fit or hydraulic holders keep runout low and let the shop run higher rpm without chatter. Ask what holder they use for tools below 0.5 mm.

Tool life is short at this scale. A micro end mill may cut for 20–40 minutes before it needs changing, and wear shows up as a size drift before the tool breaks. Shops that log tool changes and measure the first part after each change hold tolerance better than shops that run until a tool snaps.

For a prototype, the schedule that matters is quote turn and first-cut turn. Ask when the DFM feedback arrives, when the material is cut, and when the first part ships. A supplier that returns a quotation and free DFM analysis within 12 hours and can start production within 24 hours is set up for prototype work. Parts typically ship in 3–5 days.

MOQ is the other gate. Micro features often mean low volumes, sometimes a single part. A shop with no minimum order quantity can quote one prototype and a 10,000+ part run on the same equipment, which removes the awkward step of finding a second supplier later.

Read the quote line by line. Check whether tooling, fixturing, inspection and finishing are included or listed separately. A low unit price with tooling excluded is not a low price. Ask for the material certificate, the inspection report, and the finish spec in writing before you approve the order.

Certifications tell you which systems the shop already runs. ISO 9001:2015 covers general quality management. IATF 16949:2016 is the automotive standard. ISO 13485:2016 applies to medical device work. ISO 27001:2022 covers information security, which matters when your drawings are sensitive.

Confidentiality should be a process, not a promise. Uploads should be handled as secure and confidential, and a non-disclosure agreement should be available on request. For defense, medical, or unreleased consumer products, confirm who can see the files and where they are stored.

Quality signals are easy to spot on a shop tour or in a video call: a temperature-controlled metrology room, a vision measuring system for small features, a tool crib with logged micro cutters, and 100% inspection before shipment. If the shop cannot show how it measures a 0.2 mm hole, the tolerance claim is unverified.
