Precision Stainless Steel CNC Factory: How to Choose One

• 1
  Key takeaways
• 2
  Stainless steel CNC factory comparison checklist
• 3
  Why the stainless grade decides everything downstream
• 4
  What a stainless steel CNC factory must have on the floor
• 5
  Reading tolerance claims without getting fooled
• 6
  Certifications and inspection: what to verify
• 7
  Lead time, order size and what a quote should contain
• 8
  Seven steps to qualify a stainless steel CNC factory

Stainless is not one material. A stainless steel CNC factory that treats 303 and 316L as interchangeable will give you a quote that looks cheap and a part that fails inspection. Austenitic grades such as 303, 304 and 316L work-harden as the tool rubs. Feed rates that are too light will polish the surface instead of cutting it, and the next pass will squeal.

Martensitic and precipitation-hardening grades behave the opposite way. 420, 440C and 17-4PH (SUS630) arrive in a soft condition and get heat treated after machining. That means the factory has to leave grinding stock or plan a second operation. If your drawing calls for 17-4PH at H900 and the supplier quotes a single machining pass, the tolerance will move after aging.

Duplex and 316L parts for marine or medical use also bring chloride pitting into the picture. Surface finish matters as much as chemistry. A Ra 0.8–1.6 μm finish on a 316L fitting resists pitting better than a rough as-machined surface at Ra 1.6–3.2 μm, even when both parts come off the same machine.

So the first question in any supplier review is not about machine count. It is which grades the factory keeps in stock and how it adjusts speeds, feeds and tooling for each family. Ask for the cutting parameters they used on a comparable job. A vague answer here predicts a vague answer everywhere else.

• 1
  303Free-machining austenitic. Good for shafts and fittings, not for welding.
• 2
  304 / 316LCorrosion resistance first. Expect slower cycle times and more tool wear.
• 3
  17-4PH (SUS630)Machine soft, age hard. Plan a finishing pass after heat treatment.
• 4
  440C / 420Hardened wear parts. Grinding stock is usually required.

Three-axis mills with rigid fixtures still cut most stainless parts. The question is when that stops being true. Parts with features on four or five faces, deep pockets with thin walls, or ports at compound angles need either multiple fixtures or a simultaneous 5-axis center. Every extra setup adds stack-up error and handling time.

A factory with 16 simultaneous 5-axis machining centers can hold a part in one setup and reach the underside without re-clamping. That matters for valve bodies, manifold blocks and implant housings where a 0.02 mm shift between setups ruins a sealing face. It also shortens the process, because one operator runs one cycle instead of three.

Size matters too. Stainless parts up to 4,000 mm long need a machine with matching travel. At GreatLight the largest envelope is 4,000 × 400 × 150 mm, with medium cells at 750 × 1,150 × 550 mm and compact cells at 500 × 500 × 450 mm. A Ø400 mm rotary table covers round flanges and ring parts in a single chucking.

None of this helps if the spindle is worn. Ask when the machine was last calibrated and how ballbar or laser interferometer results are recorded. A factory that tracks calibration dates keeps tolerance stable across a production run, not just on the first article.

• 1
  One setup beats threeFewer clampings means less stack-up error on sealing faces.
• 2
  Check the travel envelopeA 4,000 mm part will not fit a 600 mm machine, no matter the axis count.
• 3
  Rotary table sizeØ400 mm covers most flanges and ring geometries.

Every supplier page says ±0.005 mm. The number is meaningless without a feature size attached. Holding ±0.005 mm on a 20 mm bore in 303 is routine on a good machine. Holding the same tolerance across a 500 mm 316L housing is a different problem, because thermal growth and tool deflection scale with the cut.

Ask for the tolerance split per feature. A realistic quote separates critical dimensions, general dimensions and non-critical surfaces. If the whole drawing gets one blanket tolerance, either the supplier has not read the print or is planning to over-machine everything and charge for it.

Surface finish belongs in the same conversation. A sealing face at Ra 0.2–0.8 μm may need a separate finishing pass or a lapping operation. General machined surfaces at Ra 1.6–3.2 μm come straight off the cutter. When the drawing mixes both, the quote should show two operations, not one blended line item.

The practical test is to send one part with a known tight feature and ask how they plan to measure it. If the answer is calipers, the tolerance claim is marketing. If the answer names a CMM, a bore gauge or a profilometer, the claim has a method behind it.

• 1
  Feature size matters
• 2
  Split the tolerancesCritical, general and cosmetic surfaces should be quoted separately.
• 3
  Finish is an operationRa 0.2–0.8 μm usually needs its own pass, not a faster feed.

Certificates are a starting filter, not proof. ISO 9001:2015 tells you the factory has a documented quality system. If you build automotive parts, you need IATF 16949:2016. Medical device work points to ISO 13485:2016. Data-handling clauses matter when drawings are sensitive, and ISO 27001:2022 covers that side.

Then check the inspection flow. Raw material should be verified against the mill certificate before cutting starts. In-process checks catch drift before a batch is finished. Final inspection before shipment should be 100% on critical features, with reports available on request. Ask what happens when a dimension trends out of tolerance mid-run.

A qualification rate of 99.99% is only credible if the factory can describe how it is measured. That means first-article inspection records, tool-wear logs and a clear non-conformance process. If a supplier cannot explain how a rejected part is handled, the rate on the website is a number, not a practice.

For overseas buyers, add one more item: how the factory stores and transmits your files. Uploads should be treated as confidential, and an NDA should be available on request before you send the STEP file. This costs nothing to ask and filters out suppliers who treat drawings casually.

• 1
  Match the certificate to the industryISO 9001 for general work, IATF 16949 for automotive, ISO 13485 for medical.
• 2
  Inspection at three pointsRaw material, in-process and final, with reports on request.
• 3
  NDA before the STEP fileConfidentiality should be settled before drawings change hands.

Lead time is the number buyers compare first and understand least. Ask when the clock starts. At GreatLight, quotation and free DFM analysis come back within 12 hours, production can start within 24 hours, and parts ship in 3–5 days. Each of those is measured from a different event, so a supplier quoting a single delivery number is hiding the rest.

Order size flexibility is the second filter. A factory that only runs 10,000-piece batches cannot help with a design iteration. No minimum order quantity means one prototype and a 10,000+ part run go through the same process. That is useful when you need three versions of a manifold before committing to a tool.

The quote itself should be itemized. Material grade, machining operations, finish, inspection level and any secondary process belong on separate lines. Blended pricing hides the finishing cost, which is often 20–30% of a stainless part. You cannot negotiate what you cannot see.

One more number worth requesting: historical late-delivery probability. A figure below 2% is a useful benchmark, but only if the factory can say how it tracks on-time shipments. If there is no recording method, the percentage is decoration.

• 1
  Define the clockQuote time, production start and ship date are three different dates.
• 2
  Check MOQ earlyNo MOQ supports prototyping; high MOQ slows design iteration.
• 3
  Itemize the quoteMaterial, machining, finish and inspection on separate lines.
