Roughly 70% of the cost of a machined part is fixed before a tool touches metal. Geometry decides setup count, tool access, and cycle time. If a pocket has a 0.8 mm internal corner and the part is 80 mm deep, the shop has to reach in with a small, flexible end mill. Feed rates drop, chatter risk rises, and the part may need a second operation to clean the corner. A 3 mm corner radius on the same pocket lets a stiffer tool run at full depth.

Wall thickness is the second lever. On aluminium, 1.5 mm unsupported walls cut cleanly. Below 1 mm, the wall deflects under cutting force and the finish goes wavy. Adding a rib or a lightening pocket in the right place keeps the part stiff without adding mass. This is where a DFM review pays for itself. We return DFM notes with every quote, usually within 12 hours, and the changes are optional.

Material grade is a cost and precision decision at the same time. Free-machining grades such as 303 stainless or 6061-T6 aluminium cut faster, hold tighter tolerances, and produce better finishes. Higher-strength grades such as 7075, 17-4PH, or Ti-6Al-4V resist deformation and wear but machine 2–4× slower and put more heat into the tool. Pick the lowest grade that meets the load case, not the highest grade you can name.

Heat treatment position matters too. Machining a part in the annealed state and hardening afterwards is often cheaper, but distortion during quench can move a ±0.02 mm bore out of tolerance. For tight bores in hardened steel, machine after heat treatment with carbide or grind the bore as a separate operation. Decide the sequence at the quoting stage, not after the first parts fail inspection.

• 1
  Corner radiusKeep internal radii at least equal to the deepest tool you can reach.
• 2
  Datum planDefine two datums that stay accessible through every setup.
• 3
  Material gradeChoose for the load case, then confirm machinability.

A drawing that calls ±0.005 mm on every dimension costs far more than one that applies that band to three features. Tight tolerances force slower passes, more frequent tool changes, and sometimes a temperature-controlled room. On a 100 mm aluminium bracket, general dimensions at ±0.1 mm and a bearing bore at ±0.01 mm is a normal split. The bore earns the tight band; the mounting holes do not.

Tolerance stack-up is the usual reason engineers over-tighten. If three features chain together to locate a sensor, the stack decides the real requirement, not each individual dimension. Work out the stack first, then assign a band to each link. Often the chain can be shortened so only one feature needs a tight tolerance, which removes a grinding or jig-boring operation.

Geometric callouts behave differently from linear tolerances. Flatness, perpendicularity, and concentricity cannot be achieved by a machine alone if the setup is wrong. A 0.01 mm perpendicularity callout on a face machined in the same setup as its datum is straightforward. The same callout on a face machined in a second setup depends on fixture repeatability, which is a harder problem to control.

We hold ±0.005 mm when the feature and the drawing justify it, and we say so when they do not. If a callout will add a grinding step without changing function, that is worth a conversation before the order is released. The cheapest tolerance is the one a part does not need.

• 1
  Apply tight bands to critical features only
• 2
  Resolve the stack-up before assigning limits
• 3
  Keep GD&T datums in the same setup when possible

The right process removes operations. A part with features on five faces can run on a simultaneous 5-axis center in one setup, which removes two re-clampings and the datum error that comes with them. Our 5-axis centers take work up to 4,000 × 400 × 150 mm on the large travel machines, and compact 500 × 500 × 450 mm machines handle smaller prismatic parts with a Ø400 mm rotary table.

Some geometry suits mill-turn better. A shaft with a turned OD, a milled flat, and cross-drilled holes is one operation on a mill-turn center and three operations on separate lathes and mills. Each transfer adds handling, a new datum, and queue time. The trade-off is that mill-turn tooling is less rigid for deep milling, so long pockets may still go to a vertical mill.

3-axis milling stays the cheapest option for flat parts with simple features. Do not route a bracket to a 5-axis machine just because the machine is available. If the part has three or fewer faces of work and no compound angles, 3-axis with two setups is usually faster and cheaper. The decision rule is simple: count the faces, count the compound angles, then choose the machine.

Finishing follows the same logic. Anodizing, electroless nickel, bead blasting, and laser marking are all available, but each adds a step and a handling risk. Laser marking has a minimum character height of 1.5 mm, so a 0.8 mm part number will fail or need a different method. List finishes in the order they matter to function.

• 1
  5-axisUse when features span four or more faces or include compound angles.
• 2
  Mill-turnUse when turned and milled features share a datum.
• 3
  3-axisKeep flat, simple parts here to hold the lowest unit cost.

The lowest quote is not always the lowest cost. Ask what the quote includes. Does it cover material certification, first-article inspection, and a final report on critical dimensions? Does it assume a single setup or three? A quote that leaves inspection out will come back as an extra line item, and the comparison you made no longer holds.

Certification scope matters as much as the certificate list. ISO 9001:2015 covers general quality management. IATF 16949:2016 applies to automotive production. ISO 13485:2016 applies to medical devices. ISO 27001:2022 covers information security, which matters if your CAD files and BOMs are commercially sensitive. Match the scope to your industry and keep the NDA on file if the design is not public.

Capacity decides whether the shop can hold your schedule. A supplier with one machine and a full queue cannot recover from a tool break. We run 127 high-precision CNC machines across three wholly-owned plants, with 16 five-axis centers, 12 four-axis mills, 27 three-axis machines, and 16 mill-turn centers. That spread gives room to move a job between machines when something goes wrong.

Lead time and MOQ are the last filters. No minimum order quantity means a single prototype and a 10,000-part run go through the same process. Production can start within 24 hours of an approved drawing, and parts ship in 3–5 days. If a supplier cannot state its late-delivery rate, ask how it tracks on-time performance. We track ours and keep the historical late-delivery probability below 2%.

• 1
  Quote scopeConfirm material, inspection, and finishing are inside the number.
• 2
  Cert scopeMatch IATF, ISO 13485, or ISO 27001 to your industry.
• 3
  Machine spreadMore machines means more room to recover from a break.
