A wood CNC machine is a gantry or bed router driven by a controller that reads G-code. The controller sends pulses to servo or stepper motors, which move the spindle in X, Y and Z. The spindle spins a fluted cutter at 12,000 to 24,000 rpm on most wood routers. The cutter edge shears fibers as the tool path advances.

The cutting action is not a saw blade. It is a rotating edge that removes chips one pass at a time. Depth of cut, feed rate and spindle speed must be balanced. Too fast and the tool burns the edge. Too slow and it rubs, which dulls the edge and tears the grain.

Chip load is the number that matters. It is the thickness of material each flute removes per revolution. For a 6 mm two-flute cutter in hardwood, a chip load of 0.2 to 0.3 mm per tooth is a common starting point. When chip load drops below roughly 0.1 mm, the tool rubs instead of cuts.

The controller also handles acceleration. A heavy gantry cannot reverse direction instantly. The post processor limits acceleration so corners do not overshoot. This is why a machine rated at 20 m/min rarely holds that speed through tight radii.

• 1
  Chip load drives edge qualityKeep it above 0.1 mm per tooth to avoid rubbing and burning.
• 2
  Spindle speed is not feed rateRaising rpm without raising feed just adds heat.
• 3
  Acceleration limits corner accuracyTight radii force the controller to slow down.

Cutting and profiling separate parts from a sheet. A nested router cuts cabinet sides, door panels and jig plates from a 1,220 × 2,440 mm sheet. The cutter follows the outline, leaving tabs so the part does not shift. Tabs are cut last by hand or with a finishing pass.

Drilling and boring place holes for dowels, hinges, screws and shelf pins. A router with a boring aggregate or a small end mill can drill vertical holes. Depth control matters because chip evacuation is poor in a blind hole. Peck drilling in 3 to 5 mm steps clears chips and keeps the hole on size.

Grooving and pocketing remove material inside the part outline. A T-slot, a cable channel or a recessed handle all fall here. A roughing pass leaves 0.3 to 0.5 mm of stock, then a finishing pass cleans the floor and walls. This two-step routine controls wall taper.

Engraving and V-carving cut shallow decorative or functional marks. A 60° or 90° V-bit follows letter and logo geometry. Depth is set by line width, not by a fixed Z value. Minimum legible stroke width on wood is about 0.4 mm, and sanding after engraving can blur it.

Edge profiling rounds or chamfers the part edge in the same setup. A radius cutter follows the outline and leaves a consistent roundover. This avoids a second manual router pass and keeps the profile aligned to the part edge.

Contour and 3D surfacing cut curved shapes such as chair backs and mold plugs. A ball-nose cutter steps over the surface at 5 to 10 percent of its diameter. Smaller stepover improves finish but multiplies cycle time. This is where a router is slower than a milling machine.

Finally, the machine prepares edges for banding or assembly. It can cut a glue pocket, a rabbet or a dowel slot so the next station aligns. Every one of these operations comes from the same G-code file, which is the real advantage of the process.

• 1
  Cutting and profilingNested parts from sheet stock, held by tabs.
• 2
  Drilling and boringHinge, dowel and shelf-pin holes with peck cycles.
• 3
  Grooving and pocketingRough 0.3 to 0.5 mm, then finish.
• 4
  Engraving and 3D surfacingShallow marks and curved forms.

The machine frame can position to ±0.05 mm on a rigid router. The wood cannot. Solid timber moves as moisture changes. A 300 mm oak panel can grow or shrink 1 to 2 mm across the grain when relative humidity shifts by 20 percent. That movement exceeds the machine error by an order of magnitude.

Sheet goods behave better. MDF and plywood are dimensionally stable in the plane of the sheet, so a nested router can hold ±0.2 mm on hole position and outline. Thickness varies more than length or width. A nominal 18 mm MDF sheet may measure 17.6 to 18.3 mm.

Grain direction affects the cut, not the position. Cutting across the grain leaves a fuzzy edge on the exit side. Climb cutting, where the cutter tooth enters at maximum chip thickness, reduces tear-out on the top face. On a router, climb cutting is standard for the finishing pass.

When we machine wood-faced or composite parts for fixtures and tooling, we hold ±0.005 mm on the metal inserts and ±0.1 mm on the wood body. The tight tolerance sits on the insert, not the timber. That split is the practical rule.

• 1
  Machine positioning: ±0.05 mmAchievable on a rigid router frame.
• 2
  Sheet goods: ±0.2 mmStable in-plane, variable in thickness.
• 3
  Solid timber: ±1 to 2 mmDominated by moisture movement.
• 4
  Metal inserts: ±0.005 mmPut the tight callout on the metal, not the wood.

Routing wins on flat parts with moderate depth. If the part fits on a 1,220 × 2,440 mm sheet and the deepest feature is under 50 mm, a 3-axis router is the cheapest way to make it. Panel furniture, jigs, signage and enclosures all fit this pattern.

Routing loses on deep 3D contours, hard metals and parts that need five-sided access. A router cannot reach under a flange without a fourth or fifth axis. Deep cavities need long tools, which deflect. On steel or titanium, spindle speed and rigidity are wrong for the job, and a milling machine takes over.

Material also decides. Medium-density fiberboard, plywood, hardwood and some plastics cut cleanly on a router. Carbon fiber and glass-filled plastics wear carbide quickly and need dust extraction and tool changes. Aluminum can be routed with the right cutter, but chip evacuation and cutting fluid change the setup.

The honest rule: if the part is mostly 2D and the tolerance sits at ±0.2 mm or looser, route it. If the tolerance is tighter, the geometry is 3D, or the material is metal, use a milling machine. We run both, so we can tell you which one your part belongs on.

• 1
  Route itFlat, 2D, ±0.2 mm or looser, sheet stock.
• 2
  Mill itDeep 3D, five-sided access, metal, tight tolerance.
• 3
  Check the toolAbrasive composites need different carbide grades.
