Every supplier quotes a tolerance. Few explain where it applies. A shop can hold ±0.005 mm on a 20 mm bore in aluminium and still miss it on a 300 mm frame with thin walls. Before you accept a number, ask which feature it covers, what material was used, and whether the part was measured at 20 °C. Thermal growth alone moves a 300 mm aluminium part by several micrometres over a 10 °C shop swing.

For most brackets, housings and manifolds, ±0.05 mm is enough and keeps the price down. Tighten to ±0.005 mm only where the function needs it: bearing seats, dowel holes, mating pilots, optical mounts. Each tight feature adds inspection time and can force a temperature-controlled cut.

Surface finish follows the same logic. Ra 1.6–3.2 μm is normal as-machined output. Ra 0.8–1.6 μm needs a finishing pass with a sharp tool and lighter feed. Ra 0.2–0.8 μm usually means a separate operation, so specify it only on sealing faces or sliding surfaces.

A useful check: send a drawing with one tight bore and three loose features. See if the quote separates them. If every dimension is priced the same, the shop is not reading the tolerance block.

• 1
  ±0.005 mmGeneral tight limit on stable setups in aluminium and brass.
• 2
  ±0.05 mmTypical functional tolerance for brackets and housings.
• 3
  Ra 0.8–1.6 μmStandard fine finish after a finishing pass.
• 4
  Ra 0.2–0.8 μmReserve for seals, journals and sliding faces.

A five-axis machine tilts the tool or the part so the cutter reaches angled faces without re-fixturing. On a part with holes on four sides, that removes three setups, three chances of location error, and the labour to build the fixtures. On a simple plate with one machined face, it changes nothing except the hourly rate.

The real gain shows on parts that are hard to hold. A thin-walled aerospace bracket can be cut from a solid billet with the tool kept short and stiff, because the rotary table presents each face to the spindle. Deep cavities get better chip evacuation when the part tilts. Tool life improves on titanium and Inconel when the cutter enters at the correct angle instead of rubbing.

Capacity is the other half of the question. A supplier with 16 simultaneous five-axis centers and 127 CNC machines in total can absorb a rush job without pushing your delivery. A shop with one five-axis machine and a full schedule will quote long lead times or subcontract, and subcontracting is where tolerance and schedule control get lost.

Ask how the shop proves the machine. Rotary axes drift, and a machine that has not been checked recently will cut tapered bores. A ballbar or test-cut report on the specific machine is a fair request for critical work.

• 1
  Use 5-axis whenAngled faces, deep pockets, multi-side holes, thin walls, hard alloys.
• 2
  Stay 3-axis whenFlat plates, simple profiles, high volume, price-driven parts.
• 3
  Ask forTest-cut or ballbar report on the machine that will run your part.

Lead time is set by two things: how fast the shop can review your files, and how many setups the part needs. A clean 3D model with a defined datum scheme can be reviewed and priced in hours. A 2D drawing with missing tolerances takes days of emails before anyone can quote.

A practical benchmark for UK buyers working with an overseas supplier: quotation and free DFM analysis within 12 hours, production start within 24 hours, and parts shipping in 3–5 days on standard work. Historical late-delivery probability below 2% is the number to ask about. Any supplier tracking this has a real scheduling system.

MOQ is where prototyping stalls. If a shop will not run one part, you cannot validate the design before committing to tooling. No minimum order quantity, from one prototype to 10,000+ part runs on the same floor, keeps the transition from prototype to production simple because the process and the inspection method stay the same.

Watch the quote itself. A price with no material grade, no finish, no tolerance statement and no inspection note is not a quote. It is a placeholder that will grow after the first part is cut.

• 1
  Files that quote fastSTEP model, clear datum, tolerance block filled in.
• 2
  Files that stallMissing radii, undefined finish, notes like 'machine to fit'.
• 3
  Ask forQuote, DFM notes, material cert and inspection plan in one reply.

Certificates are a filter, not a guarantee. What matters is which certificate matches your industry and whether the shop can show the paperwork trail behind your part. ISO 9001:2015 covers general quality systems. IATF 16949:2016 applies to automotive and EV work. ISO 13485:2016 is the one that matters for medical devices. ISO 27001:2022 covers information security, which is relevant when you send proprietary CAD files.

Inspection is the part buyers forget to specify. A supplier running 100% inspection before shipment should be able to describe the three stages: raw material check, in-process monitoring, and final inspection. Ask for the report format before the order, not after. Reports on request should mean a dimensional report with the actual measured values and the gauge used, not a stamped sheet.

Material traceability starts with the mill certificate. For stainless 316L, 17-4PH or Ti-6Al-4V used in medical or aerospace parts, the heat number on the certificate should match the batch used for your parts. On request, that link should be documented.

For confidential work, uploads should be secure and confidential, and an NDA should be available on request. Get it signed before you release the model, especially for defence-adjacent or medical programs.

• 1
  ISO 9001:2015Baseline for industrial and general engineering work.
• 2
  IATF 16949:2016Required for automotive and EV production parts.
• 3
  ISO 13485:2016Medical device components and instruments.
• 4
  ISO 27001:2022CAD and data handling security.

The supplier should machine your material regularly, not occasionally. Aluminium 6061-T6, 6082 and 7075 cover most brackets and housings. Stainless 303, 304, 316L and 17-4PH cover food, marine and medical parts. Steels 1045, 4140 and 4340 handle shafts and structural work. Titanium TC4, Inconel and magnesium AZ31B need slower cutting data and more attention to heat.

Plastics are a separate skill set. PEEK, POM and PC machine well with sharp tooling and light passes, but they move after cutting. A supplier who machines plastics daily will know to leave stock and take a finishing pass rather than chase a dimension on a part that is still relaxing.

Finishing often decides whether the part is usable. Anodizing in clear, colour, hardcoat or conductive form, electroless nickel, zinc, silver and gold plating, powder coating, black oxide, bead blasting, tumbling, brushing and polishing are all standard secondary steps. Laser marking needs a minimum character height of 1.5 mm to stay legible.

Ask whether finishing is done in-house or sent out. Outsourced finishing adds days to the schedule and a second party to the tolerance chain. In-house or tightly controlled partner finishing keeps the schedule and the surface spec under one roof.

• 1
  Aluminium6061, 6061-T6, 2024, 5052, 5083, 6063, 6082, 7075, ADC12.
• 2
  Stainless303, 304, 316, 316L, 420, 430, 431, 440C, 17-4PH.
• 3
  Titanium and specialTA1, TA2, TC4 (Ti-6Al-4V), Inconel, magnesium AZ31B / AZ91D.
• 4
  PlasticsABS, PC, PMMA, POM, PA, PEEK, PP, HDPE, carbon fibre.

Two quotes for the same part can differ by 40% and both can be honest. The difference sits in setup count, stock removal, inspection level and finishing. A part designed with a 5 mm corner radius instead of a sharp internal corner can be cut with a larger cutter, faster, with less tool wear. That single change often saves more than any negotiation.

Deep pockets and thin floors are the expensive features. A pocket deeper than four times the cutter diameter forces a long, slender tool that must run slowly to avoid chatter. If the design allows a wider pocket or a relieved floor, cycle time drops and the finish improves.

Tooling cost only appears at volume. For a few hundred parts, machining is usually cheaper than die casting. Past several thousand parts a year, a casting or forging blank with a finishing cut can beat solid machining on cost per part. Ask the supplier to price both routes when you are near that line.

Finally, price the inspection. A fully documented dimensional report on every part costs money. Decide which features actually need reporting and let the rest run to the drawing tolerance.

• 1
  Cheap to machineGenerous radii, open pockets, standard stock sizes, loose non-critical faces.
• 2
  Expensive to machineSharp internal corners, deep narrow slots, thin floors, tight features far apart.
• 3
  Decision pointMachining below a few thousand parts per year; casting above it.
