Most of the money in a Euromaster Cen 150 part is decided before a cutter touches metal. Wall thickness, pocket depth, corner radii, and hole depth all set how many tools the job needs and how slowly the machine has to run. A design review at the quoting stage costs nothing and often removes 20–40% of cycle time.

Start with corner radii. A 6 mm deep pocket with 2 mm internal corners forces a small end mill that must run at reduced feed and light depth of cut. Open that radius to 4 mm and a 8 mm cutter does the same work in fewer passes. Deep cavities have the same problem: past about 4× diameter, tool deflection and chatter climb fast, so feed rates drop.

Check hole depth too. A Ø5 mm hole 40 mm deep needs a long, thin drill that wanders and breaks. If the function allows, cap depth at 5× diameter or drill from both sides. Threads work the same way: a M3 thread 12 mm deep is slow and risky, while 6 mm of full thread holds just as well in most housings.

Finally, look for features you can move to a second operation or a standard insert. Pressed-in bushings, dowel pins, and keyed inserts often replace a tight machined bore and cut both cycle time and scrap risk.

• 1
  Internal corner radiusKeep at ≥ 1/3 of pocket depth so a larger cutter can reach the floor.
• 2
  Pocket depthStay under 4× cutter diameter; deeper means pecking, smaller tools, and chatter.
• 3
  Hole depthUnder 5× diameter avoids long-series drills and wandering.
• 4
  UndercutsReplace with a bolt-on insert or a T-slot where the load allows.

Material choice changes both the stock price and the minutes on the spindle. In our shop, 6061-T6 aluminium cuts at high surface speed with good chip evacuation, while 17-4PH stainless runs at roughly a third of that speed and eats more inserts. On a Euromaster Cen 150 bracket, moving from 17-4PH to 6061-T6 can halve cycle time if the load case allows it.

Ask what the part actually needs. Corrosion resistance, fatigue life, weight, and temperature set the floor. If a 6061-T6 housing meets the load and the environment, there is no reason to pay for 7075 or 17-4PH. If strength is the driver, 7075-T6 gives about twice the yield of 6061 at a moderate premium and still machines reasonably well.

Stock shape matters as much as alloy. A near-net blank that follows the part outline removes less metal and shortens roughing. Standard bar and plate sizes reduce waste and lead time because the mill does not have to cut a special size. We buy standard lengths where the design allows it and pass that saving on.

Do not forget heat treatment and stress relief. A part machined from pre-hardened stock may need fewer operations, but it cuts slower. A part machined soft and then hardened can distort, forcing a finishing pass after heat treat. Pick the sequence that matches the tolerance, not the one that looks cheapest on the material line.

• 1
  Aluminium 6061-T6Default for housings and brackets; fast to cut, weldable, good corrosion resistance.
• 2
  Aluminium 7075-T6Use when yield strength matters; about twice 6061, still machinable.
• 3
  Stainless 303 / 304303 machines better; 304 holds up in wet or food-contact service.
• 4
  17-4PH (SUS630)High strength and corrosion resistance, but slow cutting and higher tool wear.

A blanket tolerance note is the most common cost trap we see. When the title block says ±0.005 mm and Ra 0.4 μm on every surface, the shop has to inspect and finish surfaces that never touch anything. That adds grinding, polishing, and CMM time to features that only need to clear a bolt head.

Go feature by feature. Bearing bores, seal grooves, and mating faces earn a tight band. Clearance holes, outer profiles, and non-sealing faces do not. On a typical Cen 150 housing, two bores might need ±0.005 mm while the rest can sit at ±0.05 mm or looser. That single change can remove a finishing operation and a full inspection pass.

Surface finish works the same way. As-machined at Ra 1.6–3.2 μm is fine for most internal faces. Ra 0.8–1.6 μm suits sealing and sliding contact. Ra 0.2–0.8 μm is for optical, sealing-critical, or bearing surfaces and needs slower feeds, finer tools, and often a second operation. Specify it only where a drawing callout or a functional test demands it.

Remember that tolerance and finish interact. A tight bore with a rough finish may still leak. A loose bore with a fine finish may still not locate. Decide which one the function needs, then set the other one loose.

• 1
  Bearing and seal boresHold ±0.005 mm and Ra 0.8 μm or finer; these carry the function.
• 2
  Mating faces±0.02 mm and Ra 1.6 μm is usually enough for a gasket or O-ring.
• 3
  Clearance holes±0.1 mm is standard; no reason to tighten a bolt hole.
• 4
  Cosmetic facesAs-machined finish is fine unless the part is customer-visible.

Tip 4 is setup count. Every time a part moves to a new fixture or a new machine, the shop charges for loading, indicating, and proving the first cut. A three-setup part costs far more than a two-setup part, even with the same cycle time. Design features so they can be reached from fewer directions, and let the shop use 5-axis or mill-turn where it removes a whole operation.

Tip 5 is batch size. Setup cost is fixed, so five parts carry the full setup on each unit while fifty parts spread it thin. If the design is stable, order a batch that covers a few months of demand rather than re-ordering monthly. We run from one prototype up to 10,000+ part runs, so the quantity is yours to choose, but the rate curve is real.

Tip 6 is post-processing. Anodizing, plating, and bead blasting each add handling, racking, and sometimes re-masking. If a surface is internal and never seen, leave it as machined. If a colour anodize is only for brand look, one colour and one masking scheme keeps the price down. Laser marking has a practical floor: keep character height at 1.5 mm or more so it reads cleanly without a second pass.

Tip 7 is how you quote. Send a STEP file with the material, quantity, tolerance callouts, and finish notes, and ask for setup, run time, material, and finish as separate lines. A single lump-sum number hides where the money goes. With a broken-out quote you can see whether the bore tolerance or the batch size is the real driver and change the one that matters.

• 1
  Fewer setupsEach extra setup adds fixturing, indicating, and first-article time.
• 2
  Batch quantityLarger runs dilute fixed setup cost across more units.
• 3
  Finish only what showsInternal, non-functional surfaces can stay as machined.
• 4
  Itemized quoteSeparate lines let you target the biggest cost driver.
