Most machined parts only have to fit. A gas part has to seal. That single difference changes how you plan the process, how you measure, and which machine you put the job on. A valve body with a perfect outer profile will still fail if the seat face has a chatter mark 0.01 mm deep.

The features that matter are small and specific. The seat, the O-ring groove, the diaphragm clamp face and the thread root all sit inside the gas path. Each one needs a controlled surface finish and a defined radius. Sharp internal corners are stress risers and leak paths, so drawings for gas work usually call out a corner radius rather than a sharp intersection.

This is where gas CNC machining services differ from a shop that mostly cuts brackets. The cutting strategy has to protect the sealing face: lighter finishing passes, sharp tooling, and a fixturing plan that does not clamp directly on the surface being sealed. Burrs at a port edge are not cosmetic. They can break off downstream and jam a regulator.

Pressure class drives the rest. A part rated for a high-pressure pipeline needs thicker walls, deeper threads and tighter bore tolerance than a low-pressure instrument line. Tell the shop the working pressure and the test pressure before quoting, not after.

• 1
  Sealing features come firstSeat, groove, clamp face and thread root set the acceptance criteria.
• 2
  Corner radii are specified, not defaultedSharp internal corners concentrate stress and create leak paths.
• 3
  Never clamp on a sealing surfaceFixture on a non-critical face or use a soft jaw with a machined pocket.

General CNC work is often quoted at ±0.05 mm. Gas work usually lands at ±0.005 mm on the sealing features, with the rest of the part held looser. That split matters for cost. If you tolerance the whole part at ±0.005 mm, the shop has to slow down everywhere and your price goes up for no benefit.

Surface finish is the second lever. A static O-ring seal typically works at Ra 0.8–1.6 μm, a dynamic seat or a metal-to-metal seal wants Ra 0.2–0.8 μm. As-machined surfaces at Ra 1.6–3.2 μm are fine for non-sealing exterior faces. Put the finish callout only where gas touches metal.

Ask how the shop verifies the finish. A profilometer trace on the actual seat is worth more than a generic statement about machine capability. For a batch of 500 valve bodies, you want to know whether the trace was taken on the first part, the last part, or both.

Tolerance and finish interact with material. 316L stainless work-hardens, so a heavy finishing pass can tear the surface instead of smoothing it. Aluminium 6061 cuts cleanly but galls against a dull tool. The right feed and speed depend on the alloy, and that is a shop-floor decision.

• 1
  Split your tolerances±0.005 mm on sealing features, looser elsewhere.
• 2
  Match finish to the seal typeRa 0.2–0.8 μm for metal-to-metal, Ra 0.8–1.6 μm for static O-rings.
• 3
  Ask for the trace, not the claimProfilometer data on the seat beats a capability statement.

Stainless covers most gas work. 316 and 316L handle corrosive and marine-adjacent media, 304 works for dry inert gas, 17-4PH brings strength where a valve stem has to resist wear. Brass C36000 machines fast and is common in instrument fittings, but it is not the right call for ammonia service.

Aluminium 6061-T6 and 6082 appear in regulator housings and manifolds where weight matters. Anodizing follows, and the type of anodize changes the surface: hardcoat gives wear resistance, conductive anodize keeps electrical continuity for grounding. Tell the shop which one your assembly needs.

Hydrogen is its own case. High-pressure hydrogen embrittles some high-strength steels, so material selection is a design decision, not a shop-floor substitution. Bring the alloy and the pressure class to the quote. If a supplier swaps 316L for 303 because it machines faster, you have a corrosion problem waiting.

Plastics show up in low-pressure and medical gas paths: PEEK for chemical resistance, PTFE for seals, POM for insulators. These cut differently. PEEK needs sharp tooling and low cutting temperature or it chips at the edge.

• 1
  316L for corrosive media304 for dry inert gas, 17-4PH where a stem needs wear resistance.
• 2
  Anodize type mattersHardcoat for wear, conductive anodize when the housing must ground.
• 3
  Do not let a shop swap alloysA faster-machining substitute can change corrosion behaviour.

Certificates are only useful when the scope covers your product. ISO 9001:2015 is the baseline. IATF 16949:2016 matters if the gas part sits in a vehicle or an EV thermal system. ISO 13485:2016 applies to medical gas delivery devices, and ISO 27001:2022 covers how your drawings and CAD files are handled. Ask for the certificate scope page, not just the logo.

Inspection is where gas parts separate from general machining. A workable flow is a raw material check on arrival, in-process monitoring at each critical operation, and a final inspection before shipment. For sealing features, that means dimensional data plus a visual check under magnification.

Request the report format early. A first article report with CMM data and a material certificate is standard for a new gas part. Some buyers also want a pressure or leak test result, and that is usually a separate service. Settle who performs it and who owns the fixture before the order starts.

Traceability closes the loop. Lot numbers on the material cert should connect to the finished parts. Without that link, a field failure cannot be traced back to a heat of steel.

• 1
  Read the scope, not the badgeIATF 16949 and ISO 13485 apply to specific product families.
• 2
  Plan the inspection flowMaterial check, in-process monitoring, final inspection, reports on request.
• 3
  Agree on leak testing ownershipDecide who tests, with what fixture, and who signs the result.

A quote should come back with a DFM note, not just a number. For gas parts, the useful feedback is about wall thickness, corner radius, thread depth and whether a feature can be machined without a second setup. That analysis usually arrives within a day if the shop has engineering staff on the quoting desk.

Order size is flexible in both directions. Some shops push a minimum quantity that does not fit a qualification build. Others will run one prototype and then scale to a 10,000-part production run on the same process. Ask directly whether the prototype and production parts come off the same machine class.

Schedule risk is worth quantifying. Ask what share of past orders shipped late. A shop tracking its own late-delivery rate below 2 percent is managing capacity, not guessing. For a gas part, a late valve body can stall an entire assembly line.

Pricing structure matters as much as price. A quote that bundles tooling, fixturing and inspection into one line hides where cost sits. Ask for the breakdown so you can see whether the sealing-feature work is priced realistically or subsidised by a loose tolerance elsewhere.

• 1
  Demand a DFM noteWall thickness, radii and setup count should be commented on, not ignored.
• 2
  Confirm prototype and production share a processOtherwise your qualification data does not carry over.
• 3
  Ask for the cost breakdownTooling, fixturing, machining and inspection should be separable lines.
