A made precision cnc machining service lives or dies on whether the shop can hold the tolerance it quotes. ±0.005 mm (±0.0002 in) is a real number, but it applies to specific features, not to the whole part at once. On a 200 mm aluminum housing, a tight bore is a normal day. The same callout across a 900 mm thin-wall plate is a different job, because thermal drift and tool deflection start to matter more than the machine's positioning accuracy.

Ask the shop which features the tolerance applies to and how they will verify them. A useful answer names the machine, the workholding and the measuring instrument. A vague answer repeats the number back to you. We quote ±0.005 mm on critical features and state a looser general tolerance for everything else, so both sides know where the risk sits.

Material changes the answer too. Aluminum 6061 and 7075 cut cleanly and hold size well. Stainless 316 and 17-4PH work-harden, so light passes and sharp tooling matter more than spindle speed. Titanium TC4 (Ti-6Al-4V) and Inconel move during and after cutting, which pushes some dimensions into a second operation.

Surface finish runs alongside tolerance. As-machined is Ra 1.6–3.2 μm, a high-finish cut gets Ra 0.8–1.6 μm, and fine finishing reaches Ra 0.2–0.8 μm. If your print calls for Ra 0.4 μm on a sealing face, say so at quote time. It changes the tool path and often the price.

• 1
  Tight featuresName them on the drawing so the shop can plan the setup.
• 2
  Loose featuresA stated general tolerance keeps cost down.
• 3
  Thin wallsBelow 1 mm, expect extra operations and stress relief.

A precision claim is only as good as the measurement behind it. Every shop says it inspects. Fewer will tell you the sequence. Ours runs a raw material check on receipt, in-process monitoring during cutting, and a final inspection before shipment, with 100% inspection of parts before they leave the floor.

Documentation is where suppliers separate. For a first article, ask for dimensional results on the callouts you care about, not a pass stamp. For production runs, ask whether inspection is sampling or full. Sampling is normal for a stable process on a loose print; it is a bad fit for a medical implant or a safety bracket.

Gauge choice matters as much as frequency. A caliper reads to 0.02 mm on a good day, so it cannot confirm a ±0.005 mm bore. That needs a CMM, a bore gauge or a micrometer depending on the feature. If a supplier quotes a tight tolerance and measures with a caliper, the tolerance is a promise, not a capability.

Keep the paper trail tied to the part. Lot numbers, material certificates and inspection records should follow the shipment. For regulated buyers this is not optional, and asking early saves a scramble later.

• 1
  First articleRequest dimensional results on critical callouts.
• 2
  ProductionAgree on sampling or full inspection in writing.
• 3
  TraceabilityMaterial certs and lot numbers with the shipment.

Geometry decides which machine your part runs on, and the machine decides the price. A shop with only 3-axis mills will quote you a fixture-heavy process for a part that a 5-axis center cuts in two setups. That is not dishonesty, it is a capability gap showing up in your price.

We run 127 high-precision CNC machines across three wholly-owned plants, including 16 simultaneous 5-axis machining centers, 12 four-axis mills, 27 three-axis machines and 16 mill-turn centers. Maximum processing size is 4,000 mm, with large-travel machines at 4,000 × 400 × 150 mm and medium machines at 750 × 1,150 × 550 mm and 600 × 600 × 600 mm. Compact cells at 500 × 500 × 450 mm and 500 × 310 × 200 mm handle small, high-mix work, and a Ø400 mm rotary table covers round parts.

5-axis earns its cost on parts with angled faces, deep pockets or features on five sides. Mill-turn suits shafts, bushings and fittings that would otherwise need two machines and two fixtures. If your part is a flat plate with holes, 3-axis is cheaper and just as accurate.

Size is the other filter. Long extrusion profiles, frame rails and manifold blocks need travel that small shops do not have. Check the envelope before you check the price.

• 1
  Angled features5-axis cuts them without extra fixtures.
• 2
  Round partsMill-turn removes a second setup.
• 3
  Flat plates3-axis is the low-cost answer.

Lead time is a chain, and the clock starts before cutting. We return a quotation and free DFM analysis within 12 hours. Production can start within 24 hours of approval, and parts ship in 3–5 days. Historical late-delivery probability is below 2%. Those numbers assume the drawing is final and the material is in stock.

Ask what happens when a drawing is not final. A good supplier flags the problem in the DFM pass: a wall too thin to hold, a thread too close to an edge, a tolerance that cannot be inspected. Catching that before the first cut is worth more than a fast spindle.

MOQ is where small buyers get filtered out. We run no minimum order quantity, from one prototype to 10,000+ part runs. That matters when you need three brackets for a test rig and a 5,000-piece run six months later from the same process.

Confidentiality belongs in this check too. Uploads are secure and confidential, and an NDA is available on request. If your drawings sit under an export or IP restriction, settle that before the RFQ, not after.

• 1
  12 hoursQuotation and free DFM analysis.
• 2
  24 hoursProduction start after approval.
• 3
  3–5 daysTypical shipping window for parts.
• 4
  No MOQOne prototype or 10,000+ part runs.

Certificates are not decoration, but they are not interchangeable either. We hold ISO 9001:2015 for quality management, IATF 16949:2016 for automotive, ISO 13485:2016 for medical devices, and ISO 27001:2022 for information security. If your part is a medical instrument housing, ISO 13485 is the one your quality team will ask about. If it is an EV bracket, IATF 16949 matters more.

Ask which certificate applies to the process that will run your part. A certificate held by a trading arm does not cover a job cut in a different building. We work out of three wholly-owned plants, with facilities in Dongguan, China and a Singapore factory at No.3 Joo Koon Circle, Singapore 629032.

Material coverage is the quieter check. A shop that stocks 6061 and 304 will quote everything else with a material surcharge and a longer lead time. Our regular range includes aluminum 6061, 7075, 2024 and ADC12; stainless 303, 316L, 17-4PH and 440C; steel 1018, 4140 and 4340; copper and brass C101, C110 and C36000; titanium TA2, TC4 (Ti-6Al-4V), Inconel and magnesium AZ31B.

Finishing is part of the same question. Anodizing, plating, powder coating, black oxide, bead blasting and laser marking can all be arranged, so you are not shipping parts to a second vendor and hoping the two schedules line up.

• 1
  AerospaceTitanium and Inconel parts with full inspection data.
• 2
  Automotive and EVIATF 16949 process control for production runs.
• 3
  MedicalISO 13485 documentation for device components.

The most expensive mistake is quoting on a drawing that is not ready. A missing general tolerance block, an unclear datum scheme or a thread callout with no class forces the shop to guess, and guesses get priced as risk. Fix the drawing before you shop the job.

Second is treating price as the only column. A quote that is 20% lower often carries a looser inspection plan, a longer queue or a material substitution you did not approve. Ask what is included: DFM, first article, inspection report, finishing, packaging.

Third is splitting a part across vendors. If the machining shop does not do anodizing, the parts travel, wait and sometimes get reworked. Finishing under the same roof keeps the schedule and the accountability in one place.

Fourth is ignoring the confidentiality question until after the RFQ. If drawings are sensitive, ask about secure upload and an NDA on the first contact. It costs nothing and removes the awkward conversation later.

• 1
  Price onlyCompare what is included, not just the number.
• 2
  Split vendorsMachining and finishing in one place shortens the chain.
• 3
  Late NDARaise confidentiality before drawings move.
